# Technical Documentation: microsoft/windows-rs > โ„น๏ธ **Provenance:** Multi-Tier Ingestion ยท [CodeWiki Reference](https://codewiki.google/github.com/microsoft/windows-rs) ### Overview (`docs/readme.md`) `windows-rs` provides Rust crates for Windows APIs, from COM support and system services to UI and raw bindings. Prefer the focused crates below when they cover the functionality you need. For additional APIs, [`windows-bindgen`](crates/windows-bindgen.md) can generate a minimal project-specific binding, while [`windows`](crates/windows.md) and [`windows-sys`](crates/windows-sys.md) provide broad API coverage behind feature flags for binary applications. Reusable libraries should avoid the `windows` and `windows-sys` umbrella crates. They add dependency weight and version churn, and several libraries can bring incompatible versions of the same large crate into one dependency tree. Prefer the focused crates for shared Windows types and generate any remaining private bindings with `windows-bindgen`. Each crate page covers usage and maintenance. Generated API documentation is available on [docs.rs](https://docs.rs). ## Crates ### Core types and interop | Crate | Description | | --- | --- | | [windows-core](crates/windows-core.md) | COM and WinRT types, traits, and authoring macros. | | [windows-result](crates/windows-result.md) | Windows error handling and propagation. | | [windows-strings](crates/windows-strings.md) | Windows string types, conversions, and macros. | | [windows-link](crates/windows-link.md) | Links C-style functions without import libraries. | ### Values and collections | Crate | Description | | --- | --- | | [windows-collections](crates/windows-collections.md) | WinRT collections. | | [windows-numerics](crates/windows-numerics.md) | Graphics vectors and matrices. | | [windows-reference](crates/windows-reference.md) | Implementation of WinRT `IReference`. | | [windows-time](crates/windows-time.md) | WinRT `DateTime` and `TimeSpan` types. | ### Async and threading | Crate | Description | | --- | --- | | [windows-future](crates/windows-future.md) | WinRT asynchronous operations as Rust futures. | | [windows-threading](crates/windows-threading.md) | Safe wrapper over the Win32 thread pool. | ### System services | Crate | Description | | --- | --- | | [windows-registry](crates/windows-registry.md) | Safe Windows registry access. | | [windows-services](crates/windows-services.md) | Support for authoring Windows services. | | [windows-version](crates/windows-version.md) | Queries the Windows version at runtime. | ### UI and graphics | Crate | Description | | --- | --- | | [windows-reactor](crates/windows-reactor.md) | Declarative UI library backed by WinUI 3. | | [windows-canvas](crates/windows-canvas.md) | 2D graphics built on Direct2D. | | [windows-composition](crates/windows-composition.md) | Windows composition visuals. | | [windows-webview](crates/windows-webview.md) | Safe wrapper around the WebView2 browser control. | | [windows-window](crates/windows-window.md) | Window creation and message dispatch. | | [windows-pickers](crates/windows-pickers.md) | Windows file and folder pickers. | | [windows-animation](crates/windows-animation.md) | Wrapper around the Windows Animation Manager. | | [windows-reactor-setup](crates/windows-reactor-setup.md) | Stages the Windows App Runtime. | ### Code generation and metadata | Crate | Description | | --- | --- | | [windows-clang](crates/windows-clang.md) | Generates RDL from C and C++ headers using libclang. | | [windows-default](crates/windows-default.md) | Embedded Windows metadata for build tools. | | [windows-metadata](crates/windows-metadata.md) | Reads and writes ECMA-335 metadata. | | [windows-rdl](crates/windows-rdl.md) | Parses RDL and generates ECMA-335 metadata. | | [cppwinrt](crates/cppwinrt.md) | Packages the C++/WinRT compiler. | ### Macro implementation These crates implement macros exported by `windows-core`. Applications should use the `windows-core` exports rather than depend on them directly. | Crate | Description | | --- | --- | | [windows-implement](crates/windows-implement.md) | Implements the `#[implement]` macro. | | [windows-interface](crates/windows-interface.md) | Implements the `#[interface]` macro. | ### Windows API bindings Use `windows-bindgen` when the focused crates above do not cover the APIs you need. Binary applications may instead prefer the convenience of the pre-generated `windows` or `windows-sys` umbrella crate. | Crate | Description | | --- | --- | | [windows-bindgen](crates/windows-bindgen.md) | Generates Rust bindings from Windows metadata. | | [windows](crates/windows.md) | Typed bindings for C-style, COM, and WinRT APIs. | | [windows-sys](crates/windows-sys.md) | Raw bindings for C-style Windows APIs. | --- ### Overview (`metadata/win32/readme.md`) # Win32 metadata snapshot This directory holds the **canonical RDL snapshot** of the Win32 API surface that [`windows-clang`](../../crates/libs/clang/readme.md) scrapes from the Windows SDK headers. The whole API lives in a **single flat `Windows.Win32` namespace**, split **one file per defining header** - e.g. `wingdi.rdl` holds exactly the declarations `wingdi.h` defines - written in the human-readable [RDL](../../crates/libs/rdl/readme.md) text format. The partitioning follows the source (the clang cursor's defining header), not a hand-curated namespace layout. The merged binary `Windows.Win32.winmd` that downstream tooling consumes is *not* checked in (winmd is a binary format, and `*.winmd` is git-ignored). This text snapshot is committed instead so the API surface can be browsed directly and so changes show up as readable diffs in pull requests - the same reason the generated `windows` and `windows-sys` crates are committed. ## Generated - do not edit by hand These files are produced by `tool-win32`: ```sh cargo run -p tool-win32 ``` Re-run the tool after changing the manifest (the `const` slices in `crates/tools/win32/src/main.rs`), the hand-authored vocabulary seed (`metadata/metadata.rdl`), or the scraper, and commit the resulting diff. Hand edits will be overwritten on the next run - the tool clears the generated partitions in this directory and re-emits the whole closure. The seed lives one level up (`metadata/metadata.rdl`) so it survives that clear. See [`docs/crates/windows-clang.md`](../../docs/crates/windows-clang.md) for the scraper design - how the metadata matches the SDK headers, header partitioning, and the documented deviations from the reference - and [`docs/crates/windows-rdl.md`](../../docs/crates/windows-rdl.md) for the winmd artifact and layout of the in-house metadata pipeline that replaces the external `win32metadata` project. --- ### Overview (`crates/libs/animation/readme.md`) ## windows-animation Windows Animation wraps the Windows Animation Manager (`IUIAnimationManager`) for variable interpolation, transitions, and storyboards. It does not depend on a UI or rendering framework. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-animation.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-animation] version = "0.100" ``` ```rust,no_run use windows_animation::*; fn main() -> Result<()> { let manager = Manager::new()?; let opacity = manager.create_variable(0.0)?; // Animate from 0.0 to 1.0 over half a second. let library = TransitionLibrary::new()?; let fade_in = library.linear(0.5, 1.0)?; let storyboard = manager.create_storyboard()?; storyboard.add_transition(&opacity, &fade_in)?; storyboard.schedule(0.0)?; // Each frame, advance the clock and read the current value. manager.update(0.25)?; let value = opacity.value()?; assert!((0.0..=1.0).contains(&value)); Ok(()) } ``` --- ### Overview (`crates/libs/bindgen/readme.md`) ## windows-bindgen The [windows-bindgen](https://crates.io/crates/windows-bindgen) crate generates Rust bindings from Windows metadata. * [Guide](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-bindgen.md) Add the generator as a build dependency and the generated code's runtime dependency: ```toml [dependencies.windows-link] version = "0.100" [build-dependencies.windows-bindgen] version = "0.100" ``` Generate a flat file in `OUT_DIR` from `build.rs`: ```rust,no_run use std::path::Path; fn main() { let out_dir = std::env::var("OUT_DIR").unwrap(); windows_bindgen::builder() .output(Path::new(&out_dir).join("bindings.rs")) .filter("GetTickCount") .flat() .sys() .write(); } ``` Filters name the functions, constants, or types you need. Signature dependencies are included automatically. See the [guide] for qualified names, member filters, and filter files. Use the generated bindings from `src/main.rs`: ```rust,ignore mod bindings { include!(concat!(env!("OUT_DIR"), "/bindings.rs")); } fn main() { unsafe { println!("{}", bindings::GetTickCount()); } } ``` For a published library, generate and commit `src/bindings.rs` from a separate tool instead of running the generator in consumer builds. Formatting is best effort; install `rustfmt` when generating checked-in source. [guide]: https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-bindgen.md#select-apis --- ### Overview (`crates/libs/canvas/readme.md`) ## windows-canvas Windows Canvas wraps Direct2D, Direct3D 11, DXGI, DirectWrite, and WIC for 2D drawing. The core crate is host-neutral. Enable `system` for the typed `windows-window` swap-chain helper, `reactor` for Canvas controls in Reactor, and `composition` to draw into Composition surfaces. The `system` and `reactor` host adapters can coexist unless `composition` selects their incompatible Composition backends. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-canvas.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-canvas] version = "0.100" ``` ```rust,no_run use windows_canvas::*; fn main() -> Result<()> { let device = GpuDevice::new_warp()?; let mut swap_chain = device.create_swap_chain(640, 480)?; let session = swap_chain.begin_draw()?; session.clear(ColorF::CORNFLOWER_BLUE); let brush = session.create_solid_brush(ColorF::rgb(1.0, 0.5, 0.0))?; session.fill_rect(&Rect::new(20.0, 20.0, 200.0, 120.0), &brush); drop(session); swap_chain.present()?; Ok(()) } ``` --- ### Overview (`crates/libs/clang/readme.md`) ## windows-clang The [windows-clang](https://crates.io/crates/windows-clang) crate extracts declarations from C and C++ source with libclang and emits [RDL](https://crates.io/crates/windows-rdl). It is the header-facing stage of the Windows metadata pipeline: ```text headers -> windows-clang -> RDL -> windows-rdl -> WinMD ``` Add the crate to your Cargo.toml: ```toml [dependencies.windows-clang] version = "0.100" ``` For ordinary header-to-RDL generation, configure and run the high-level builder: ```rust,no_run windows_clang::clang() .input("Example.h") .args(["-x", "c++", "--target=x86_64-pc-windows-msvc"]) .reference_default() .namespace("Example") .library("example.dll") .output("Example.rdl") .write() .unwrap(); ``` The builder reads inputs and references, invokes the extractor, emits RDL, and writes the output. Use [`Input`][input], `extract`, and `EmitOptions` directly when a generator needs to inspect or combine immutable snapshots before emission. The caller owns libclang installation, compiler arguments, package versions, import-library discovery, architecture merging, output promotion, and RDL-to-WinMD compilation. See the [crate documentation][docs] for both APIs and the extraction model. [input]: https://docs.rs/windows-clang/latest/windows_clang/struct.Input.html [docs]: https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-clang.md --- ### Overview (`crates/libs/collections/readme.md`) ## windows-collections The [windows-collections](https://crates.io/crates/windows-collections) crate implements Windows collection interfaces for Rust collections. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-collections.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-collections] version = "0.100" ``` ```rust use windows_collections::*; let numbers = IIterable::::from(vec![1, 2, 3]); for value in numbers { println!("{value}"); } ``` --- ### Overview (`crates/libs/composition/readme.md`) ## windows-composition Windows Composition wraps the retained-mode Windows composition engine for standalone windows and WinUI 3 applications. The default `system` feature hosts Composition in a `windows-window` window. Use the `reactor` feature for a Composition host inside Reactor, with default features disabled. The stacks are mutually exclusive. Both support Canvas drawing surfaces through `windows-canvas[composition]`; select Canvas's matching `system` or `reactor` feature. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-composition.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-composition] version = "0.100" ``` ```rust,no_run use windows_composition::*; fn build(compositor: &Compositor) -> SpriteVisual { let visual = compositor.create_sprite_visual(); visual.set_size(200.0, 120.0); let brush = compositor.create_color_brush(CompositionColor::rgb(0, 120, 215)); visual.set_brush(&brush); visual } ``` --- ### Overview (`crates/libs/core/readme.md`) ## windows-core The [windows-core](https://crates.io/crates/windows-core) crate provides COM and WinRT types, traits, and macros for the windows-* family of crates. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-core.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-core] version = "0.100" ``` Use the core types as needed: ```rust use windows_core::{h, Result, HRESULT, HSTRING}; // WinRT reference-counted strings. let name: &HSTRING = h!("Windows.Foundation.Uri"); assert_eq!(name, &HSTRING::from("Windows.Foundation.Uri")); // HRESULT-based results. fn check(code: HRESULT) -> Result<()> { code.ok() } assert!(check(HRESULT(0)).is_ok()); assert!(check(HRESULT(-2147467259)).is_err()); ``` `create_instance` activates an in-process COM class and returns a requested interface. The application must initialize the calling thread for COM before using it. Use `init_mta` for apartment-agnostic code. UI threads that require a single-threaded apartment can hold the value returned by `init_sta` for the lifetime of their COM objects. --- ### Overview (`crates/libs/cppwinrt/readme.md`) ## cppwinrt The [cppwinrt](https://crates.io/crates/cppwinrt) crate bundles the C++/WinRT compiler for use in Rust. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/cppwinrt.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.cppwinrt] version = "0.100" ``` Use `cppwinrt` function as needed: ```rust,ignore println!("{}", cppwinrt::cppwinrt(["-help"])); ``` --- ### Overview (`crates/libs/default/readme.md`) ## windows-default The [windows-default](https://crates.io/crates/windows-default) crate provides the default metadata for Windows APIs as embedded byte slices. Build tools can use `WINRT` and `WIN32` without locating or distributing separate `.winmd` files. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-default.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-default] version = "0.100" ``` ```rust use windows_default::{WIN32, WINRT}; assert!(!WINRT.is_empty()); assert!(!WIN32.is_empty()); ``` --- ### Overview (`crates/libs/future/readme.md`) ## windows-future The [windows-future](https://crates.io/crates/windows-future) crate adapts WinRT asynchronous operations to Rust futures. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-future.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-future] version = "0.100" ``` Use the Windows async types as needed: ```rust,no_run use windows_future::*; // This result will be available immediately. let ready = IAsyncOperation::ready(Ok(123)); assert_eq!(ready.join().unwrap(), 123); let ready = IAsyncOperation::spawn(|| { // Some lengthy operation goes here... Ok(456) }); assert_eq!(ready.join().unwrap(), 456); ``` --- ### Overview (`crates/libs/implement/readme.md`) ## windows-implement The [windows-implement](https://crates.io/crates/windows-implement) crate provides the `#[implement]` macro for implementing COM and WinRT interfaces in Rust. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-implement.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies] windows-core = "0.100" windows-implement = "0.100" ``` ```rust use windows_core::{IUnknown, interface}; use windows_implement::implement; #[interface("57f61c8b-b400-4035-a7c2-abbddf9e3559")] unsafe trait IValue: IUnknown { fn get(&self) -> u32; } #[implement(IValue)] struct Value(u32); impl IValue_Impl for Value_Impl { unsafe fn get(&self) -> u32 { self.0 } } let value: IValue = Value(42).into(); assert_eq!(unsafe { value.get() }, 42); ``` --- ### Overview (`crates/libs/interface/readme.md`) ## windows-interface The [windows-interface](https://crates.io/crates/windows-interface) crate provides the `#[interface]` macro for declaring COM interfaces in Rust. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-interface.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies] windows-core = "0.100" windows-interface = "0.100" ``` ```rust use windows_core::IUnknown; use windows_interface::interface; #[interface("57f61c8b-b400-4035-a7c2-abbddf9e3559")] unsafe trait IValue: IUnknown { fn get(&self) -> u32; } ``` --- ### Overview (`crates/libs/link/readme.md`) ## windows-link The [windows-link](https://crates.io/crates/windows-link) crate provides the `link` macro that simplifies linking. The `link` macro uses `raw-dylib` and thus does not require import lib files. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-link.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-link] version = "0.100" ``` Use the `link` macro to import functions and their matching function-pointer types. Here the loader functions are linked normally while `MessageBoxA` is resolved at runtime: ```rust,no_run use std::ffi::c_void; use windows_link::link; link!("kernel32.dll" "system" fn LoadLibraryA(name: *const u8) -> *mut c_void); link!("kernel32.dll" "system" fn GetProcAddress( library: *mut c_void, name: *const u8, ) -> *mut c_void); link!("user32.dll" "system" fn MessageBoxA( hwnd: *mut c_void, text: *const u8, caption: *const u8, kind: u32, ) -> i32); unsafe { let module = LoadLibraryA(b"user32.dll\0".as_ptr()); let address = GetProcAddress(module, b"MessageBoxA\0".as_ptr()); if !address.is_null() { let message_box: MessageBoxA = std::mem::transmute(address); message_box( std::ptr::null_mut(), b"text\0".as_ptr(), b"caption\0".as_ptr(), 0, ); } } ``` --- ### Overview (`crates/libs/metadata/readme.md`) ## windows-metadata The [windows-metadata](https://crates.io/crates/windows-metadata) crate reads and writes the ECMA-335 metadata format used by .NET, WinRT, and Win32 metadata. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-metadata.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-metadata] version = "0.100" ``` Query a type with the metadata reader: ```rust,no_run use windows_metadata::*; let index = reader::Index::read("Windows.winmd").unwrap(); let def = index.expect("Windows.Foundation", "Point"); assert_eq!(def.namespace(), "Windows.Foundation"); assert_eq!(def.name(), "Point"); let extends = def.extends().unwrap(); assert_eq!(extends.namespace(), "System"); assert_eq!(extends.name(), "ValueType"); let fields: Vec<_> = def.fields().collect(); assert_eq!(fields.len(), 2); assert_eq!(fields[0].name(), "X"); assert_eq!(fields[1].name(), "Y"); assert_eq!(fields[0].ty(), Type::F32); assert_eq!(fields[1].ty(), Type::F32); ``` --- ### Overview (`crates/libs/numerics/readme.md`) ## windows-numerics The [windows-numerics](https://crates.io/crates/windows-numerics) crate provides Windows vector, matrix, plane, and quaternion types. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-numerics.md) These are the same graphics math types used by composition, Direct2D, and Direct3D APIs, so values flow into those APIs without conversion. Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-numerics] version = "0.100" ``` Use the vector and matrix types as needed: ```rust use windows_numerics::*; let a = Vector2::new(3.0, 4.0); assert_eq!(a.length(), 5.0); let b = Vector3::new(1.0, 0.0, 0.0); let c = Vector3::new(0.0, 1.0, 0.0); assert_eq!(b.cross(&c), Vector3::new(0.0, 0.0, 1.0)); let transform = Matrix3x2::translation(10.0, 20.0); assert_eq!(transform.m31, 10.0); assert_eq!(transform.m32, 20.0); ``` --- ### Overview (`crates/libs/pickers/readme.md`) ## windows-pickers Windows Pickers provides file and folder pickers backed by the Windows Common Item Dialog. It supports standalone Windows applications and components built with `windows-reactor`. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-pickers.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies] windows-pickers = "0.100" windows-window = "0.100" ``` ```rust,no_run # #[cfg(feature = "system")] # mod example { use windows_pickers::{OpenFilePicker, Result}; use windows_window::Window; fn pick_rust_file(window: &Window) -> Result<()> { let path = OpenFilePicker::new() .title("Open a Rust source file") .filter_extensions("Rust source", ["rs"]) .filter_all() .show(window)?; if let Some(path) = path { println!("{}", path.display()); } Ok(()) } # } ``` The calling thread must be a COM single-threaded apartment (STA). Cancellation returns `Ok(None)`; other Windows failures are returned as errors. --- ### Overview (`crates/libs/rdl/readme.md`) ## windows-rdl The [windows-rdl](https://crates.io/crates/windows-rdl) crate compiles **RDL** (Rust Definition Language) - a Rust-like text format for describing Windows APIs - into ECMA-335 `.winmd` metadata, and back again. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-rdl.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-rdl] version = "0.100" ``` Use the `reader` to compile `.rdl` source into a `.winmd`, and the `writer` to regenerate canonical `.rdl` from a `.winmd`: ```rust,no_run windows_rdl::reader() .input("example.rdl") .output("example.winmd") .write() .unwrap(); windows_rdl::writer() .input("example.winmd") .output("example.rdl") .write() .unwrap(); ``` --- ### Overview (`crates/libs/reactor-setup/readme.md`) ## windows-reactor-setup Windows Reactor Setup stages the Windows App SDK runtime files needed by a [`windows-reactor`](https://crates.io/crates/windows-reactor) application that runs fully self-contained. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-reactor-setup.md) Add it as a build dependency: ```toml [build-dependencies] windows-reactor-setup = "0.100" ``` Call the setup function from `build.rs`: ```rust,no_run windows_reactor_setup::as_self_contained(); ``` Runtime extraction caches are separate for each target architecture and are reused only after successful extraction and required-file checks. Download, extraction, and copy errors fail the build rather than leaving it to succeed with missing runtime files. --- ### Overview (`crates/libs/reactor/readme.md`) ## windows-reactor Windows Reactor is a typed declarative UI library for building native WinUI 3 applications in Rust. Components own Rust state, describe the current view, and receive typed messages from controls. Add Reactor to `Cargo.toml`: ```toml [dependencies.windows-reactor] version = "0.100" ``` ```rust,no_run use windows_reactor::*; #[derive(Clone, Copy)] enum Message { Increment, Reset, } struct Counter { count: i32, } impl Component for Counter { type Input = (); type Message = Message; fn create(_input: &(), _context: &ComponentContext) -> Self { Self { count: 0 } } fn update(&mut self, message: Message, _context: &ComponentContext) { match message { Message::Increment => self.count += 1, Message::Reset => self.count = 0, } } fn view(&self, _input: &(), context: &mut ViewContext) -> View { let content = StackPanel::new().spacing(8.0).children(( format!("Count: {}", self.count), Button::new() .on_click(context.message(Message::Increment)) .content("Increment"), Button::new() .on_click(context.message(Message::Reset)) .content("Reset"), )); context.window_frame("Counter", content) } } fn main() { App::run_component::(()).unwrap(); } ``` Run with `cargo run`. Applications use the default features and an installed Windows App SDK runtime. See the [setup guide][setup] for runtime prerequisites and self-contained deployment. The [getting-started guide][guide] covers editable state, child components, background work, images, and application windows. Browse the [samples] for complete applications and focused examples. [setup]: https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-reactor-setup.md [guide]: https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-reactor.md [samples]: https://github.com/microsoft/windows-rs/tree/master/crates/samples/reactor --- ### Overview (`crates/libs/reference/readme.md`) ## windows-reference The [windows-reference](https://crates.io/crates/windows-reference) crate implements `IReference` for boxed Windows values. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-reference.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-reference] version = "0.100" ``` ```rust use windows_reference::*; let value = IReference::::from(42); assert_eq!(value.Value().unwrap(), 42); ``` --- ### Overview (`crates/libs/registry/readme.md`) ## windows-registry The [windows-registry](https://crates.io/crates/windows-registry) crate reads and writes the Windows registry. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-registry.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-registry] version = "0.100" ``` ```rust,no_run use windows_registry::*; fn main() -> Result<()> { let key = CURRENT_USER.create(r"software\windows-rs")?; key.set_u32("number", 123)?; key.set_string("name", "Rust")?; println!("{}", key.get_u32("number")?); println!("{}", key.get_string("name")?); Ok(()) } ``` --- ### Overview (`crates/libs/result/readme.md`) ## windows-result The [windows-result](https://crates.io/crates/windows-result) crate provides Windows error types for Win32, COM, and WinRT APIs. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-result.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-result] version = "0.100" ``` Use the `HRESULT`, `Error`, and specialized `Result` types as needed: ```rust use windows_result::*; const S_OK: HRESULT = HRESULT(0); const ERROR_CANCELLED: WIN32_ERROR = WIN32_ERROR(1223); const E_CANCELLED: HRESULT = ERROR_CANCELLED.to_hresult(); fn main() -> Result<()> { S_OK.ok()?; let e = Error::new(E_CANCELLED, "test message"); assert_eq!(e.code(), E_CANCELLED); assert_eq!(e.message(), "test message"); Ok(()) } ``` --- ### Overview (`crates/libs/services/readme.md`) ## windows-services The [windows-services](https://crates.io/crates/windows-services) crate implements Windows service processes. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-services.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-services] version = "0.100" ``` ```rust,no_run windows_services::Service::new() .can_pause() .can_stop() .run(|_service, _command| {}) .unwrap(); ``` --- ### Overview (`crates/libs/strings/readme.md`) ## windows-strings The [windows-strings](https://crates.io/crates/windows-strings) crate provides Windows string types and literals. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-strings.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-strings] version = "0.100" ``` Use the Windows string types as needed: ```rust use windows_strings::*; const A: PCSTR = s!("ansi"); const W: PCWSTR = w!("wide"); fn main() { let b = BSTR::from("bstr"); let h = HSTRING::from("hstring"); assert_eq!(b, "bstr"); assert_eq!(h, "hstring"); assert_eq!(unsafe { A.to_string().unwrap() }, "ansi"); assert_eq!(unsafe { W.to_string().unwrap() }, "wide"); } ``` --- ### Overview (`crates/libs/sys/readme.md`) ## windows-sys The `windows-sys` crate provides raw Windows API declarations, structs, and constants without wrappers or helper traits. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-sys.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-sys] version = "0.100" features = [ "handleapi", "synchapi", "winuser", ] ``` Make use of any Windows APIs as needed: ```rust,no_run use windows_sys::{core::*, Win32::*}; unsafe { let event = CreateEventW(std::ptr::null_mut(), 1, 0, std::ptr::null()); SetEvent(event); WaitForSingleObject(event, 0); CloseHandle(event); MessageBoxA(0 as _, s!("Ansi"), s!("Caption"), MB_OK as u32); MessageBoxW(0 as _, w!("Wide"), w!("Caption"), MB_OK as u32); } ``` --- ### Overview (`crates/libs/threading/readme.md`) ## windows-threading The [windows-threading](https://crates.io/crates/windows-threading) crate wraps the Windows thread pool. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-threading.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-threading] version = "0.100" ``` Submit work to the default pool: ```rust,no_run windows_threading::submit(|| { println!("thread: {}", windows_threading::thread_id()); loop { println!("."); windows_threading::sleep(1000); } }); ``` Process an iterator in parallel: ```rust,no_run let counter = std::sync::RwLock::::new(0); windows_threading::for_each(0..10, |value| { println!("thread: {}, value: {value}", windows_threading::thread_id()); let mut counter = counter.write().unwrap(); *counter += value; }); assert_eq!(*counter.read().unwrap(), 45); ``` --- ### Overview (`crates/libs/time/readme.md`) ## windows-time The [windows-time](https://crates.io/crates/windows-time) crate provides Windows `TimeSpan` and `DateTime` values with Rust constructors, arithmetic, and `std::time` conversions. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-time.md) `TimeSpan` is a duration and `DateTime` is a point in time. Both use 100-nanosecond ticks. Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-time] version = "0.100" ``` Use the time types as needed: ```rust use windows_time::*; let span = TimeSpan::from_minutes(90); assert_eq!(span.whole_seconds(), 5400); let start = DateTime::from_unix_secs(1_000_000_000); let later = start.checked_add(span).unwrap(); assert_eq!(later.unix_secs(), 1_000_005_400); ``` --- ### Overview (`crates/libs/version/readme.md`) ## windows-version The [windows-version](https://crates.io/crates/windows-version) crate reads the Windows version without relying on the application manifest. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-version.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-version] version = "0.100" ``` ```rust,no_run use windows_version::*; println!("Current version: {:?}", OsVersion::current()); if is_server() { println!("Running on a Windows Server release."); } if OsVersion::current() >= OsVersion::new(10, 0, 0, 12345) { println!("Can use a feature available on this version or later.") } ``` --- ### Overview (`crates/libs/webview/readme.md`) ## windows-webview Windows WebView wraps the [WebView2](https://aka.ms/webview2) COM APIs to host Microsoft Edge (Chromium) in a window. The crate has no default UI framework. Enable `system` for a complete `windows-window` host or `reactor` for a WebView2 control in a Reactor view. Enable both when an application uses both host types. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-webview.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies] windows-webview = { version = "0.100", features = ["system"] } ``` `WebViewWindowBuilder::run` owns the COM apartment, parent window, WebView2 environment and controller, resize handling, shutdown order, and the application's `windows-window` message loop: ```rust,ignore use windows_webview::*; fn main() -> Result<()> { WebViewWindow::new("WebView2") .size(1000, 700) .run(|host| { host.webview() .navigate("https://github.com/microsoft/windows-rs")?; Ok(()) }) } ``` Use `WebViewHost::builder` when another framework owns the parent HWND and message loop. It chains environment and controller creation into one callback and returns one host object for the framework to retain. The [`raw-window`](../../samples/webview/raw-window) sample shows the raw HWND contract. The [`reactor`](../../samples/webview/reactor) sample embeds WebView2 in a Reactor view, while [`reactor-window`](../../samples/webview/reactor-window) uses Reactor controls to drive a WebView hosted in a separate `windows-window`. --- ### Overview (`crates/libs/window/readme.md`) ## windows-window The [windows-window](https://crates.io/crates/windows-window) crate provides basic window creation and message-loop support for Canvas, WebView2, and custom rendering. * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows-window.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows-window] version = "0.100" ``` ```rust,no_run use windows_window::*; fn main() -> Result<()> { let window = Window::new("Hello") .client_size(800, 600) .on_resize(|width, height| { println!("resized to {width} x {height}"); }) .on_close(|| { println!("release HWND-hosted resources here"); }) .quit_on_close(true) .create()?; // `window.hwnd()` can be handed to windows-canvas, WebView2, Direct2D, etc. println!("created window {:?}", window.hwnd()); run(); Ok(()) } ``` --- ### Overview (`crates/libs/windows/readme.md`) ## windows The [windows](https://crates.io/crates/windows) crate provides Rust bindings for Win32, COM, and WinRT APIs generated from [Windows metadata](https://github.com/microsoft/windows-rs/tree/master/crates/libs/default). * [Getting started](https://github.com/microsoft/windows-rs/blob/master/docs/crates/windows.md) Start by adding the following to your Cargo.toml file: ```toml [dependencies.windows] version = "0.100" features = [ "Data_Xml_Dom", "handleapi", "synchapi", "winuser", ] ``` Make use of any Windows APIs as needed: ```rust,no_run use windows::{core::*, Data::Xml::Dom::*, Win32::*}; fn main() -> Result<()> { let doc = XmlDocument::new()?; doc.LoadXml(h!("hello world"))?; let root = doc.DocumentElement()?; assert!(root.NodeName()? == "html"); assert!(root.InnerText()? == "hello world"); unsafe { let event = CreateEventW(None, true, false, None); if event.is_null() { return Err(Error::from_thread()); } SetEvent(event).ok()?; WaitForSingleObject(event, 0); CloseHandle(event).ok()?; MessageBoxA(None, s!("Ansi"), s!("Caption"), MB_OK as u32); MessageBoxW(None, w!("Wide"), w!("Caption"), MB_OK as u32); } Ok(()) } ``` --- ### Overview (`crates/tests/bench/readme.md`) # test_bench A side-by-side WinRT projection benchmark. Three consumers call the identical Rust WinRT component, so every per-call delta is projection cost. | Consumer | Column | Projection | | --- | --- | --- | | `rust` | windows-rs | The generated windows-rs projection. | | `cpp` | cppwinrt | The header-only C++/WinRT projection. | | `cswinrt2` | CsWinRT 2 | The stable C#/WinRT projection with RCW-backed managed classes. | The `cswinrt` project is a focused CsWinRT 3.0 preview probe rather than a benchmark column. The preview package builds on plain `net10.0`, but it does not contain the `WinRT.Interop` assembly that its delegate marshaller loads. The probe fails at the first event subscription and its Cargo test remains ignored until a complete preview ships. The component (`component` -> `bench_component.dll`) is a real WinRT component: RDL -> winmd -> windows-bindgen -> `#[implement]`, activated registration-free via `DllGetActivationFactory`. It exposes one activatable class, `Bench.Widget`, with scalar, string, metadata `Object`, nullable reference, async, event, vector, map, and view operations. A non-default `INonDefault` interface provides the QueryInterface fixture, and `LiveCount` reports native ownership balance. ## Running ```powershell # Full run (10,000,000 iterations, median of three runs by default) crates/tests/bench/run.ps1 # Quick run crates/tests/bench/run.ps1 -Iterations 100000 -Runs 1 ``` `run.ps1` builds the component first so its metadata writer does not race a consumer build, builds the three consumers, stages `bench_component.dll` as `Bench.dll`, and prints median throughput, memory, and leak values. The lower native result and the CsWinRT result are bold. Each consumer also has a `cargo test` that runs the same path with a small iteration count, so CI exercises the matrix wherever the .NET SDK and MSVC toolchain are present. ## Results Measured on August 5, 2026 with .NET SDK 10.0.302 and CsWinRT 2.3.1. Times are milliseconds for 10,000,000 operations (median of three runs); `Error` uses 1,000,000 operations. Lower is better. | Metric | C++/WinRT | windows-rs | CsWinRT 2 | | --- | ---: | ---: | ---: | | Create | 624 | 567 | 11,075 | | Int32 | 25 | 24 | 45 | | String | 298 | 291 | 1,588 | | Add | 14 | 17 | 25 | | Interface | 14 | 17 | 64 | | Object | 141 | 138 | 1,205 | | Event | 219 | 218 | 929 | | AddRemove | 353 | 781 | 24,526 | | Vector | 119 | 121 | 254 | | IterateVector | 1,287 | 129 | 4,516 | | GetMany | 2 | 2 | 183 | | Map | 722 | 579 | 17,012 | | Lookup | 219 | 183 | 297 | | VectorView | 19 | 24 | 139 | | MapView | 152 | 167 | 246 | | Reference | 2,323 | 766 | 24,049 | | Async | 579 | 490 | 54,547 | | Error | 21,263 | 7 | 2,858 | | Memory (bytes/object) | 8 | 8 | 296 | | Leak (live objects) | 0 | 0 | 0 | ## Metrics | Metric | What it measures | | --- | --- | | Create | Activate a fresh `Widget`. | | Int32 | Set and get the `Int32` property. | | String | Set and get the `String` property, including HSTRING conversion. | | Add | Call a method with two `Int32` arguments and a return value. | | Interface | Acquire `INonDefault` once, then call `Value` repeatedly. | | Object | Set and get metadata `Object` (`IInspectable`). | | Event | Subscribe one handler and raise `Changed` through `Signal`. | | AddRemove | Subscribe and unsubscribe a `Changed` handler each iteration. | | Vector | Read one element per iteration from an `IVector`. | | IterateVector | Iterate the whole `IVector` for a bounded number of passes. | | GetMany | Copy a vector into caller-owned storage through the public bulk-copy surface. | | Map | Enumerate values from an `IMap`. | | Lookup | Read one value per iteration from an `IMap`. | | VectorView | Read one element per iteration from an `IVectorView`. | | MapView | Read one value per iteration from an `IMapView`. | | Reference | Box and unbox a nullable `Int32` through `IReference`. | | Async | Consume an already-completed `IAsyncOperation`. | | Error | Propagate a failing `HRESULT` with a reduced iteration count. | | Memory | Client-side allocated bytes per retained live object. | | Leak | Component live-instance count above baseline after the run. | The timed bodies use the same loop bounds, inputs, result retention, collection sizes, and reduced error count wherever the public projection surfaces permit. CsWinRT finalization is forced outside affected timers so cleanup does not contaminate the following metric. The `GetMany` row requests the same final result through each public projection. windows-rs and C++/WinRT expose the WinRT `GetMany` method directly. CsWinRT maps `IVector` to `IList`, so its public `CopyTo` adapter loops over `GetAt`. The `Error` row highlights projection error models. Rust observes a failed `HRESULT` as a `Result` branch. C++/WinRT and CsWinRT throw and catch exceptions, so this row uses a reduced loop count. The leak row checks native `AddRef`/`Release` balance. Rust and C++/WinRT release deterministically at scope exit. CsWinRT returns to baseline after `GC.Collect()` and `WaitForPendingFinalizers()` because an RCW retains its native reference until finalization. To add a metric, emit a matching `Name: ms` line from every consumer and add its name to the `$Metrics` array in `run.ps1`. --- ### Overview (`crates/samples/reactor/content-dialog/readme.md`) # ContentDialog default button Run `cargo run -p reactor-content-dialog`. Choose a default button, then press Enter in the dialog. WinUI highlights the default button and normally focuses it when the dialog opens. The result is shown after the dialog closes; Cancel returns `ContentDialogResult::None`. The editor case shows the focus exception: a multiline TextBox receives focus and consumes Enter to insert a line instead of closing the dialog. Tab moves focus to the buttons. `ContentDialogButton::None` removes the default-button designation, not the buttons' own keyboard behavior. A focused button can still respond to Enter. --- ### Overview (`crates/samples/reactor/font-icon/readme.md`) # FontIcon size and foreground Run `cargo run -p reactor-font-icon`. ```rust FontIcon::new() .glyph("\u{E80F}") .font_size(48.0) .foreground(ThemeBrush::PrimaryText) ``` Compare small red and large blue glyphs, a theme-aware foreground, and the native defaults on the same icon. "Toggle theme" switches the window between light and dark. Without a foreground override, the preview inherits its color from the surrounding HyperlinkButton. "Native defaults" removes both overrides, restoring the native font size and inherited foreground. `font_size` accepts finite positive values. `foreground` accepts a `Color` or a `ThemeBrush`. --- ### Overview (`crates/samples/reactor/gallery/readme.md`) # Reactor gallery This sample is the `windows-reactor` port of the WinUI control gallery. It contains 65 destinations across 11 categories: - Basic Input - Collections - Date and Time - Design Guidance - Dialogs and Flyouts - Layout - Media - Menus and Toolbars - Navigation - Status and Info - Text Run it with: ```powershell cargo run -p reactor-gallery ``` The shell uses a generated `TitleBar` and `NavigationView`. The pane lists categories by default. Select a category to open its card grid, then select a card to open the control page. Search replaces the category links with matching control destinations. Back navigation follows the shell's page history. Each control destination is a component under `src/pages/`. Pages use controlled state for live examples such as text input, sliders, selection controls, dialogs, progress indicators, and layout changes. Page-owned state is recreated when a destination is retired and later reopened. Window state, including the selected theme and backdrop material, belongs to the shell and persists across page replacement. For implementation examples, read the compiled page components in [`src/pages/`](src/pages/). The gallery does not duplicate them as display-only source snippets, which can drift from the working examples. The gallery is organized as follows: | File | Purpose | | --- | --- | | `src/shell.rs` | Window visuals, title bar, navigation pane, search, and history | | `src/registry.rs` | Category and destination metadata | | `src/router.rs` | Leaf destination to component mapping | | `src/controls.rs` | Shared page headers, sample cards, card grids, and assets | | `src/pages/` | Category modules and control page components | Bundled images in `assets/` are loaded through `Image::source_file`. Sample cards use WinUI theme brushes so their surfaces follow the selected light, dark, or system theme. The Materials page changes the live window backdrop between Mica, Mica Alt, Acrylic, and a solid background. The gallery uses generated `GridView` selection feedback, `BreadcrumbBar` item-click events, and the `Viewbox` child slot. Flyout, SplitButton, TabView, and InfoBar examples use their native event and ownership contracts rather than substituting pointer handlers. Recording-runtime tests mount the full gallery, replace pages through shell navigation, mount every registered destination, drive representative controlled input, reject events from retired pages, and verify that shell-owned theme and backdrop state survives page replacement. --- ### Overview (`crates/samples/reactor/navigation/readme.md`) # Navigation and multi-window workspace This sample qualifies navigation and window isolation by opening a secondary workspace from the primary at runtime. A `SplitView` hosts the navigation pane and current page through generated typed slots. Each window owns its page, editor text, focus reference, background work, and component queue. The windows share a small application model that broadcasts theme changes and window-lifecycle notifications. Run it with: ```powershell cargo run -p reactor-navigation ``` Try this sequence: 1. Choose **Open secondary window**, then open the editor in each window and enter different text. 2. Move between Home and Editor and confirm each window retains its own text. The window title follows the current page. 3. Change the shared theme and confirm both windows update. 4. Start background work in the secondary window, then choose **Close this window**. 5. Confirm the primary window remains responsive and reports the secondary closure. `ComponentContext::open_window` stages an independent root with the current component publication. After publication, the host registers a pending open and mounts that root in a new Pump. The opener's scope does not own the new Pump. Close requests use the same transactional boundary and are applied only after publication. Each workspace declares its native title from component state. Declarative size configuration remains deferred rather than being hidden in the sample with direct WinUI calls. --- ### Overview (`crates/samples/reactor/number-box/readme.md`) # NumberBox options Run `cargo run -p reactor-number-box`. ```rust NumberBox::new() .small_change(0.25) .spin_button_placement_mode(NumberBoxSpinButtonPlacementMode::Inline) ``` Compare hidden, inline, and compact spinner buttons. The compact popup appears when the control receives focus. Up/Down and the spinner buttons use `small_change`; values remain between 0 and 20. `small_change` accepts finite `f64` values. The step button switches between 0.25 and 2. "Use native defaults" removes both properties from the existing controls, restoring a step of 1 and hidden buttons. The headers identify the custom modes; all three use hidden buttons while the overrides are removed. --- ### Overview (`crates/samples/reactor/startup_perf/readme.md`) # Windows Reactor startup tracing sample This blank app demonstrates TraceLogging events across the Windows Reactor startup lifecycle. It renders one static `TextBlock` in a 1000x1000 window. The app uses the ETW team's `tracelogging` crate to emit TraceLogging events from the `BenchmarkSyntheticApps` provider: - Provider GUID: `FD80D616-E92B-4B2B-9BED-131ADA36A8FD` - Keyword: `0x0000400000000000` - App name: `blank_windows_reactor` - Process name: `blank-windows-reactor.exe` | Event | Location | | --- | --- | | `wWinMainEntry` | Before Windows App SDK bootstrap | | `XamlAppLoaded` | Root component creation | | `WindowLoaded` | First post-commit effect | | `FirstRender` | First `CompositionTarget::Rendering` callback after commit | | `FirstIdle` | Low-priority dispatcher callback after `FirstRender` | | `ProcessStop` | Immediately after the final window closes | Every event includes `AppName`, `Seq`, and `Pid` fields. Run the framework-dependent app with: ```powershell cargo run -p reactor-startup-perf --release ``` ## MSIX package Run these commands from the repository root: 1. Install Windows App Development CLI 0.5.0 or later, or upgrade an existing installation: ```powershell # First installation: winget install Microsoft.WinAppCli --source winget # Existing installation: winget upgrade Microsoft.WinAppCli --source winget winapp --version ``` 2. Build the app and prepare the package layout: ```powershell cargo build -p reactor-startup-perf --release --quiet $work = "target\reactor-startup-msix" $layout = "$work\layout" Remove-Item $layout -Recurse -Force -ErrorAction Ignore New-Item $layout -ItemType Directory | Out-Null Copy-Item ` target\release\blank-windows-reactor.exe ` $layout $output = "$work\blank-windows-reactor_x64.msix" $manifest = "crates\samples\reactor\startup_perf\package\Package.appxmanifest" ``` 3. Create an unsigned package: ```powershell winapp pack $layout --manifest $manifest --output $output --skip-pri ``` To sign without a timestamp, use one `winapp pack` call: ```powershell $certificate = "C:\certificates\package.pfx" $securePassword = Read-Host "Certificate password" -AsSecureString $certificatePassword = [Net.NetworkCredential]::new("", $securePassword).Password winapp pack $layout ` --manifest $manifest ` --output $output ` --skip-pri ` --cert $certificate ` --cert-password $certificatePassword ``` `winapp pack` cannot timestamp a signature. For timestamped signing, package first and then sign: ```powershell $certificate = "C:\certificates\package.pfx" $timestampUrl = "https://timestamp.example.com" $securePassword = Read-Host "Certificate password" -AsSecureString $certificatePassword = [Net.NetworkCredential]::new("", $securePassword).Password winapp pack $layout --manifest $manifest --output $output --skip-pri winapp sign $output ` $certificate ` --password $certificatePassword ` --timestamp $timestampUrl ``` The checked-in manifest uses version `1.0.0.0` and the Microsoft corporate publisher. Update its `Identity` before packaging if either value needs to change. The publisher must exactly match the signing certificate subject. WinApp CLI accepts local and UNC certificate paths, but it passes the path directly to `signtool`; copy the PFX locally first if the signing environment does not allow `signtool` to read the share. Certificate passwords are command-line arguments because WinApp CLI does not provide a secure input or environment-variable option. The package remains framework-dependent. Install `Microsoft.WindowsAppRuntime.2.msix` on the target machine before launching it. --- ### Overview (`crates/samples/reactor/text-block-alignment/readme.md`) # TextBlock alignment Run `cargo run -p reactor-text-block-alignment`. ```rust TextBlock::new() .text("Centered text") .text_alignment(TextAlignment::Center) ``` `text_alignment` positions text within the TextBlock's available width. `horizontal_alignment` positions the TextBlock itself. The sample compares left, centered, and right text in stretched controls with a centered, content-sized control. Resize the window to see the difference. TextBlock and TextBox share Reactor's `TextAlignment` enum. Canvas has a separate `TextAlignment` for DirectWrite; qualify the type or use an import alias when using both crates. Updating or omitting `text_alignment` keeps the native TextBlock. Omitting a previously declared alignment clears its local value and lets WinUI supply the alignment again. --- ### Overview (`crates/samples/reactor/text-box-read-only/readme.md`) # Read-only TextBox Run `cargo run -p reactor-text-box-read-only`. Both fields allow selection and copying without editing. The second uses `text_alignment` to center its text inside the stretched control. Resize the window to see the difference. --- ### Overview (`crates/samples/reactor/translation-transition/readme.md`) # Translation transition Run `cargo run -p reactor-translation-transition`. Open and close the panel, or click again while it is moving to reverse direction. Translation is a visual offset in DIPs; it does not change the space reserved by layout or remove the panel. --- ### Overview (`crates/samples/reactor/virtual/readme.md`) # Virtual task editor This sample qualifies `windows-reactor` virtualization with application behavior rather than static labels. It includes: - keyed row components with controlled `TextBox` and `ToggleSwitch` values; - front insertion, removal, move-to-end, reversal, and a 1,000-item reset; - direct selection input for each keyed row; - validation and queued typed focus; - keyed row effects and cleanup on recycle; - background loading with scope-owned cancellation; - conditional row content; - same-key payload updates and key-changing source resets. Run it with: ```powershell cargo run -p reactor-virtual ``` The same component model has a feature-gated `RecordingRuntime` performance driver. Run it in release mode: ```powershell cargo run -p reactor-virtual --bin reactor-virtual-perf ` --features perf --release -- --samples 500 ``` The driver measures local editing, broad and redundant parent messages, an unchanged root-component memo hit, a forced value-equal root recomposition, 32-row recycle/realize batches, background completion, and a mixed virtual cycle. It reports allocator traffic and median, p95, and p99 Rust-side turn time. It also measures value-equal declaration scaling at 1,000, 10,000, and 100,000 tasks. It does not include WinUI control work, layout, rendering, or presentation. The live driver adds `CompositionTarget::Rendering` frame intervals and host/native phase timing: ```powershell cargo run -p reactor-virtual --bin reactor-virtual-live-perf ` --features perf --release -- --samples 300 cargo run -p reactor-virtual --bin reactor-virtual-live-perf ` --features perf --release -- --baseline --samples 300 ``` The active run moves by 32 virtual indices per frame, alternates selection, edits a controlled row every six frames, and delivers a background completion every 30 frames. The baseline opens the same 1,000-item editor without scheduling those actions. Each command writes a report next to the executable. After the measured frames, the driver also verifies that queued recycle and source-reset work left no retired WinUI shell tokens. A machine that emits no composition frames writes an explicit failure report and exits unsuccessfully after 20 seconds. The durable task title belongs to `TaskEditor`, not the realized row component. A row component is retained across key-stable payload updates, but native virtualization or a source reset may recycle it. Non-empty controlled drafts update that model immediately; a blank validation draft remains row-local and falls back to the last valid model value after recycling. The recording-runtime test enters edit mode, checks queued focus, edits a task, explicitly recycles it, reverses the source, and verifies that its title survives each re-realization with one cleanup per retired row effect. The buttons provide a deterministic manual stress sequence: 1. Select a row, enter edit mode, and change its title. 2. Reverse or move the source and confirm the title remains in the task model. 3. Add and remove rows at the front. 4. Load another 100 rows in the background. 5. Reset to 1,000 rows and repeat edits while scrolling. --- ### Overview (`crates/samples/windows/dcomp/readme.md`) This sample first appeared in Kenny's [DirectComposition course on Pluralsight](https://www.pluralsight.com/courses/directcomposition-in-action). Check it out to learn all about DirectComposition, Direct2D, and DirectWrite, image decoding, and animation. --- ### Overview (`crates/samples/windows/direct3d12/readme.md`) Direct3D --- ### Overview (`crates/samples/windows/spellchecker/readme.md`) # Windows SpellChecker A sample showing how to use the Windows spell-checking API (`ISpellCheckerFactory`, `ISpellChecker`) from the `windows` crate. It checks a line of text from the command line and prints corrections to standard out. ## Running Make sure you have [Rust installed](https://rustup.rs), and then run the following: ```powershell cargo run -- "This is text with a word missspelled!" ``` --- ### Overview (`crates/samples/windows/uiautomation/readme.md`) ## UI Automation A simple example using the new UI Automation API. This sample requires Windows 11. --- ### Overview (`crates/tests/libs/reactor/readme.md`) # Reactor tests `test-reactor` is the home for the new Cargo-based Reactor tests. It lives alongside the existing selftest, integration, and performance crates without depending on their harnesses or Reactor's `test` feature. Add new cases here and migrate existing coverage individually. Remove an old case only after its replacement proves the same behavior; retire old helpers when their consumers are gone. The crate uses the public Reactor API, direct Windows UI Automation, and the Rust standard library. `build.rs` generates only the required native bindings into `OUT_DIR` using `windows-bindgen` and stages the host's private Windows App Runtime using `windows-reactor-setup`. There are no generated test cases, external runners, or dependencies on the `windows` crate. ## Running ```text cargo test -p test-reactor ``` On x64 this runs the automated suite, including live WinUI cases and harness failure checks. It requires an interactive desktop. Cargo deploys the runtime; no machine-wide runtime installation is needed. The first build needs network access to download the pinned runtime packages. Five native drag/drop cases are explicitly ignored; see [Opt-in drag/drop coverage](#opt-in-dragdrop-coverage). Foreground or focus failures do not silently skip tests. Do not interact with other applications while the suite runs. Standard Cargo name filters can select individual cases during development. The crate also runs in the ordinary workspace test command. Other workspace packages can enable Reactor's legacy `test` feature through Cargo feature unification; this fixture still uses only the public application API and real WinUI. The package-only command covers the default-feature build. The `ui` integration target is x64-only. The existing x64 workspace job runs the live suite; x86 and ARM64 build the fixture and run `windows-reactor-setup`'s filesystem and multiprocess tests as part of workspace testing. This is an explicit architecture boundary, not a runtime skip when focus or foreground is unavailable. ## Layout | Location | Purpose | | --- | --- | | `build.rs` | Native binding generation and self-contained runtime deployment | | `src/lib.rs` | Small public-API applications and process-failure probes | | `src/main.rs` | Entry point for the isolated WinUI host | | `tests/ui/main.rs` | Named behavioral tests driven through UI Automation | | `tests/ui/automation.rs` | Scoped lookup, native actions, condition waits, and diagnostics | | `tests/ui/menu.rs` | Button-menu callback, content, attachment, and owner lifetimes | | `tests/ui/process.rs` | Child ownership, deadlines, shutdown, and harness failure checks | | `tests/ui/pointer.rs` | Native mouse injection, owned button cleanup, and physical coordinates | | `src/pointer.rs` | Property-only pointer capture and focus fixtures | | `src/drag/` | Property-only drop target and owned native OLE text source | | `tests/ui/drag.rs` | Opt-in drag negotiation, policy changes, and cancellation | The library contains the application fixtures. Cargo's integration-test harness supplies the host executable's path without filesystem searches or a child mode in the test runner. Keeping the host separate gives WinUI its own main thread and application lifetime. The binary's `test = false` disables its empty unit-test harness, not the behavioral tests. Each UI case launches the Cargo-built `test-reactor` executable in a fresh process. The suite serializes desktop cases even with Cargo's default thread count. UI Automation runs on an MTA worker, while the test thread watches the child and enforces a 30-second deadline, including blocked UIA calls. Success requires completed assertions and a successful exit after closing the fixture's own window. Failure cancels further driver work and terminates the owned child. | Case | Assertion | | --- | --- | | `menu_callback_replacement_and_removal` | An open item's native identity survives callback replacement; invoking it reaches the new callback exactly once. A retired item's invocation does not change the displayed count during a 250 ms observation period. | | `menu_content_replacement_retires_open_items` | Changing content closes the old popup and creates a new item on the same owner. The old item stays inert before and after opening the replacement. | | `menu_reattachment_does_not_revive_retired_items` | Removing and reattaching a menu on the same native owner creates new items without reviving retained providers. | | `menu_owner_replacement_retires_open_items` | Replacing the keyed button closes its popup and changes native owner/item identity. A callback update on the replacement preserves its open item and reaches the current callback. | | `text_box_native_edit_and_controlled_reset` | UIA Value edits reach component state; declarative reset clears the native value; focused Unicode keyboard input reaches both state and the native TextBox. | | `keyed_reorder_moves_only_displaced_children` | Moving the last keyed TextBox to the front keeps every element's native identity and produces the new layout order. The focused TextBox that triggered the reorder is not displaced, so it keeps keyboard focus. | | `early_successful_exit_is_rejected` | Exiting with code zero before the driver finishes is a failure, not a passing test. | | `child_panic_is_reported` | A child panic produces a failed exit and captured stdout and stderr. | | `hung_child_is_terminated` | A ready but unresponsive child times out and is terminated. | | `driver_timeout_cancels_worker` | The supervisor deadline cancels a cooperative driver and reaps its child without consuming the cleanup allowance. | | `driver_timeout_bounds_blocked_worker_cleanup` | The supervisor reaps the child and returns after its cleanup allowance even when the driver remains blocked. | | `pointer_capture_policy_at_mount` / `pointer_capture_policy_added_to_existing_border` | With only the capture policy, movement outside reaches the pressed Border; after release it reaches the outside surface. | | `pointer_focus_policy_at_mount` / `pointer_focus_policy_added_to_existing_border` | With only the release/focus policy, the Border receives direct native pointer focus after release, not on press. | | `pointer_button_is_released_after_driver_failure` | A driver failure while pressing the mouse releases the injected button before the fixture is stopped. | | `text_data_transfers_owned_unicode_memory` | The data source rejects unsupported formats and returns independent, nul-terminated UTF-16 allocations that outlive its COM object. This unit test runs normally. | The driver timeout regressions use the same supervisor as live UI cases, with short private deadlines and synthetic workers rather than COM calls. Each case releases and joins its worker before asserting the outcome. Live cases retain the 30-second deadline and five-second cleanup allowance. The driver uses exact automation IDs, or exact name and control type for menu items, scoped to the child's windows. Repeated entries for the same native element count once; distinct matching elements are an error. Waits inspect current UI state; they do not force layout or synthesize Reactor callbacks. UIA invocation, Value edits, and keyboard input are separate operations. Keyboard injection checks the foreground process, focused element, and modifier keys. Button-menu cases use UIA Invoke to exercise WinUI's menu actions, not synthetic Reactor events. They retain old invoke providers across content, attachment, and owner changes, check popup closure including the submenu entry, and invoke retired providers before and after opening a replacement. Retired invocations must leave both the callback count and the replacement popup unchanged. Current items must deliver the expected key and callback generation exactly once; callback counts are observed for 250 ms to detect extra deliveries. These tests cover button menus. Dropdown, menu-bar, command-bar, and tray surfaces remain in the legacy integration fixture. Pointer cases use `SendInput` with physical virtual-desktop coordinates derived from UIA anchor bounds. The fixture's Border has no UIA peer; short text anchors locate its bare background without clicking the text itself. Guards check foreground ownership, the window under button input, and held buttons/modifiers. The supervisor owns button cleanup, so cancellation or a blocked UIA worker cannot leave cleanup dependent on that worker returning. A case that finishes with an injected button still pressed fails. The policy fixtures install no press/release callbacks on the target. Capture and release are observed through native movement routing, not a stored policy or capture flag. Focus is observed through the target's direct native focus event; setting focus on the baseline button is a separate driver action. Dynamic cases omit the policy entirely at mount, exercise that state, and then enable it while preserving the UIA anchor's identity. They do not set the policy to false initially, since that setter can itself activate a lazy native subscription. Cargo captures driver steps and assertion failures. On a condition timeout the driver also prints the fixture's UI tree. Child stdout and stderr are written to separate files to avoid blocked pipes; failures report the log directory under the system temporary directory. Successful cases remove their logs. The parent deadline still applies if reading the UI tree stalls. ## Opt-in drag/drop coverage The native drag/drop cases are preserved from PR #5115, but are not part of the default automated suite. WinUI does not support this drag/drop path in elevated processes ([microsoft/microsoft-ui-xaml#7690](https://github.com/microsoft/microsoft-ui-xaml/issues/7690)). GitHub-hosted Windows runners run as administrator. The tests use `#[ignore = "..."]` so Cargo reports them as ignored, not passed. Explicitly running them elevated fails before launching a fixture. No runner-specific skip, token manipulation, or automatic elevation change is used. Run the policy and failure-cleanup cases from a non-elevated terminal on an idle interactive desktop: ```text cargo test -p test-reactor --test ui drop_policy -- --ignored cargo test -p test-reactor --test ui drag_source_is_stopped_after_driver_failure -- --ignored ``` The cancellation case also has an unresolved intermittent UIA timeout (`0x80131505`) after cancellation. Keeping the source window and its STA alive across drags has not eliminated that failure. It remains an opt-in regression case, not evidence that cancellation is reliable: ```text cargo test -p test-reactor --test ui cancelled_drag_can_be_restarted -- --ignored --nocapture ``` To run all five opt-in cases, including the unresolved cancellation regression: ```text cargo test -p test-reactor --test ui -- --ignored ``` | Opt-in case | Assertion | | --- | --- | | `drop_policy_at_mount` / `drop_policy_added_to_existing_border` | A callback-free Border accepts native text drags through its policy, including activation after an initially rejected drop. | | `drop_policy_changes_during_drag` | Source feedback follows Copy-to-Move policy changes while hovering; switching back before release produces a Copy drop that reads the text. | | `cancelled_drag_can_be_restarted` | Three cancelled hovers preserve the source's native UIA identity; another drag then drops successfully. Subject to the unresolved timeout above. | | `drag_source_is_stopped_after_driver_failure` | Failure during an accepted OLE hover releases the injected button and reaps the fixture process, including its source thread. | The source is a native window on a dedicated OLE STA in the fixture process. It receives injected input and runs `DoDragDrop`, leaving WinUI free to render policy changes and read dropped data. It advertises only `CF_UNICODETEXT`. Assertions require source-reported hover operations, the final OLE operation, and a text read, not just a Copy cursor. The target has no drag/drop callbacks that could mask policy-only activation. The source window and STA live for the fixture session. Each drag owns its data and feedback objects. Normal shutdown joins the UIA driver before closing the fixture, which stops and joins the source thread. The OLE callback checks cancellation and a 20-second deadline; the existing parent supervisor still bounds blocked native calls. No UIA timeout is retried or treated as success. ## App-process coverage The pilot uses compiler instrumentation and the `llvm-tools` Rust toolchain component, without a Cargo coverage plugin. In a fresh PowerShell session at the repository root: ```powershell $ErrorActionPreference = "Stop" $PSNativeCommandUseErrorActionPreference = $true $target = Join-Path $PWD "target\reactor-ui-coverage" $profiles = Join-Path $target ("profiles-" + [Guid]::NewGuid()) New-Item -ItemType Directory $profiles | Out-Null $env:RUSTFLAGS = "-C instrument-coverage" $env:LLVM_PROFILE_FILE = Join-Path $profiles "%p-%m.profraw" cargo test -p test-reactor --target-dir $target $sysroot = rustc --print sysroot $hostTriple = (rustc -vV | Select-String "^host: ").ToString().Substring(6) $llvm = Join-Path $sysroot "lib\rustlib\$hostTriple\bin" $raw = @(Get-ChildItem $profiles -Filter "*.profraw") & "$llvm\llvm-profdata.exe" merge -sparse $raw.FullName -o "$profiles\ui.profdata" & "$llvm\llvm-cov.exe" show "$target\debug\test-reactor.exe" ` "-instr-profile=$profiles\ui.profdata" ` '--include-filename-regex=native[\\/]+winui[\\/]+(hosting|events)\.rs$' ``` The unique profile directory prevents earlier runs from contributing counts. Child processes inherit the profile pattern, and `%p-%m` separates their output. Report against `test-reactor.exe`, not just the integration-test driver: the native Reactor code runs in the fixture. The source filter above shows the menu callback update and native text setter paths exercised by these cases. This is a pilot path report, not an overall Reactor coverage percentage or a replacement for the core coverage job. Close the PowerShell session afterwards to discard the instrumentation environment. --- ### Overview (`crates/tests/libs/reactor_bench/readme.md`) # Reactor benchmark This benchmark measures Reactor retained updates, component scheduling, lifecycle work, virtualization, and memory attribution without WinUI layout or rendering. ```text cargo run -p test-reactor-bench --release --quiet cargo run -p test-reactor-bench --release --quiet -- --count 4096 --samples 40 --batch 4 cargo run -p test-reactor-bench --release --quiet -- --architecture-gate cargo run -p test-reactor-bench --profile profiling --quiet -- --retained-memory --count 512 ``` The output includes median and p95 update time, allocated bytes and allocation count per update, retained bytes per object, isolated component updates, and retained component-scope memory. Component rows also cover isolated and all-consumer typed-context invalidation, same-type updates, and retained-root type replacement. The recursive component rows build balanced trees, target the deepest leaf, and report retained bytes per scope, update latency, allocations, allocated bytes, and mutation count. The timed updates disable recording-adapter batch validation because that diagnostic intentionally clones the complete adapter state. The `--architecture-gate` mode uses six samples by default and reports: - Keyed no-change and one-property-change updates across two 50,000-object graphs in one timed operation. Reactor enforces a 65,536-object limit per graph. - Controlled 513-node memory fixtures that separate declaration construction, retained graph storage, string properties, events, TreeNode relation shape, and recording-adapter storage. - Root-type replacement and middle-child removal in a 16,384-component graph. Use `--gate-samples` or `--component-count` to override the gate defaults. The `--retained-memory` mode releases benchmark scratch buffers after mounting and reports live retained-graph allocations separately from declarations and adapter state. It prints release layout sizes and additive slot, relation, child-vector, property/event, virtual, and retirement storage for keyed and unkeyed flat trees, a deep chain, relation-heavy controls, TreeNode structural objects, a virtual source, and an active retirement. No-op allocation, changed-update allocation, retained memory, and large-tree scaling are separate gates. --- ### Overview (`crates/tests/libs/reactor_integration/readme.md`) # Reactor public integration tests These isolated executables exercise the public application API without Reactor's `test` feature. Build this package separately from privileged selftests and benchmarks so Cargo does not unify their diagnostic features into this build. ```text cargo check -p test-reactor-integration --all-targets cargo run -p test-reactor-integration --bin application_lifecycle -- replacement cargo run -p test-reactor-integration --bin application_lifecycle -- multiple cargo run -p test-reactor-integration --bin application_lifecycle -- startup-error cargo run -p test-reactor-integration --bin application_menu cargo run -p test-reactor-integration --bin application_menus cargo run -p test-reactor-integration --bin menu_lifetimes -- dropdown cargo run -p test-reactor-integration --bin application_resources -- lifecycle cargo run -p test-reactor-integration --bin application_dispatch -- application cargo run -p test-reactor-integration --bin application_dispatch -- notification cargo run -p test-reactor-integration --bin tray_flyout cargo run -p test-reactor-integration --bin menu_position -- thread-unaware cargo run -p test-reactor-integration --bin canvas_integration cargo run -p test-reactor-integration --bin webview_integration cargo run -p test-reactor-integration --bin window_state cargo run -p test-reactor-integration --bin window_observers cargo run -p test-reactor-integration --bin window_theme cargo run -p test-reactor-integration --bin title_bar ``` Each executable owns its application lifetime and watchdog. The lifecycle fixture covers last-window replacement, multiple-window shutdown, and startup errors. The menu fixture checks application-lifetime work after its Reactor window closes. The application-resource fixtures cover declarative window and icon lifetimes, nested dispatch, and menu replacement and selection. The notification dispatch mode sends interactions and recovery requests to its own callback window during nested component and application updates, and checks that queued events cannot outlive icon removal. The tray-flyout fixture uses an application-owned icon and checks that its menu overlaps the icon's monitor, extends outside that monitor's work area, and closes during application shutdown. It measures menu-item bounds through UI Automation rather than the popup window's shadow bounds, and requires a running Windows shell with a notification area. Companion-crate fixtures exercise Canvas drawing and WebView initialization. The window-state fixture observes size and icon changes through the public window callback and Win32 APIs. The window-observer fixture covers callback replacement without replay, real changes, removal, re-subscription, and independent subscriptions for color scheme, size, and placement. It also covers removal and re-subscription within one drain, handoff from a parent to a child, and replacement of the subscribing child. The title-bar fixture opens a second window from a running application and checks through UI Automation that its `TitleBar` right header keeps the same caption-button inset as the first window. Run `window_theme` on an interactive desktop. It temporarily makes its windows topmost without activation to sample their rendered backgrounds. Run `menu_lifetimes` with `dropdown`, `menubar`, `command`, or `tray` on an interactive desktop. It uses process-scoped UI Automation and notification messages sent to its own icon. Button-menu lifetimes are covered by the named Cargo tests in [`test-reactor`](../reactor/readme.md). The menu-position fixture covers `pmv2`, `unaware`, `system`, and `thread-unaware` DPI modes. It checks exact physical host bounds and restoration of the caller's thread context, including when a duplicate menu request is rejected. Run on a display scaled above 100% to exercise coordinate virtualization. Use `--features self-contained` to run with bundled Windows App SDK dependencies. Otherwise, the Windows App Runtime must be installed. WebView tests also need the WebView2 runtime. --- ### Overview (`crates/tests/libs/reactor_perf/readme.md`) # Reactor stress benchmark `test_reactor_perf` compares windows-reactor with the C# Reactor `StressPerf.ReactorOptimized` workload: - 70 columns x 70 rows = 4,900 `TextBlock` cells; - deterministic `.NET Random(42)` data and update sequence; - a 33 ms update timer; - at least one randomly selected cell per tick, controlled by `--percent`; - cached cell declarations rebuilt only for changed indices; - snapshot-driven root component updates; - phase, frame, allocation, and working-set reporting. Run the live benchmark in release mode: ```powershell cargo run -p test_reactor_perf --release -- --headless --percent 10 --duration 10 ``` The report is written next to the executable as `StressPerf.Reactor.report.txt`. Add `--json` to also write `StressPerf.Reactor.metrics.json`. The in-app frame counter uses `CompositionTarget::Rendering`, matching the C# workload. As with the C# harness, render completion is a better no-admin throughput proxy, and ETW presents are required for a final user-visible frame-rate comparison. --- ### Overview (`crates/tests/libs/reactor_selftest/readme.md`) # Reactor native self-test This executable runs the Reactor WinUI adapter inside the Reactor application host. Generated coverage constructs and clears every schema property and event contract. Handwritten phases cover controlled input, ordered native events, attachments, images, references, pointer injection, retirement, TreeView content, ListView data, and virtualization. ```text cargo run -p test-reactor-selftest --quiet cargo run -p test-reactor-selftest --quiet -- --headless ``` A watchdog terminates the process with an error if WinUI hangs or the application fails to exit. Application lifecycle, menu, Canvas, WebView, and window-state fixtures live in [`test-reactor-integration`](../reactor_integration/readme.md). They use the public application API without enabling Reactor's diagnostic `test` feature. Asynchronous phases wait for native readiness rather than assuming a timer tick is sufficient. The ContentDialog check requests opening before its owner window exists, waits for `Opened`, then calls `Hide` and requires `Closed`. Use assertions for failures in component callbacks. Calling `process::exit` there can run application teardown while callback state is still borrowed. CI also runs the self-test and native library tests in debug mode with `RUSTFLAGS="-D warnings --cfg windows_cast_diagnostics"`. `check_casts.ps1` checks their captured output for unexpected same-pointer `QueryInterface` calls. Its allowlist covers agility checks, canonical COM identity, activation, and known conversions from `IInspectable`; these still require queries even when the returned pointer is unchanged. Review new diagnostics before adding an exception. A clean result covers only the paths exercised by those tests. Run every default Reactor, Composition, and WebView sample long enough to catch startup failures: ```text powershell -File crates\tests\libs\reactor_selftest\run_samples.ps1 ``` The script builds each package independently, captures runtime stdout and stderr, requires the process to remain alive for three seconds, and then closes or terminates that process. Use `-RunSeconds`, `-Family`, or `-Package` to narrow or lengthen a run, and `-KeepLogs` to retain all captured output. Use `-Package` with `-ChangedSince ` to run the named packages plus samples changed between that commit and `HEAD`. Added files and deleted files within surviving packages count as changes; removed packages are not run. `-List` prints the selection without building or launching anything. The comparison commit must be available locally. ## CI PRs and master pushes run the native self-test once, with cast diagnostics, and retain the native regressions, public integration fixtures, deployment checks, isolated feature checks, and public API snapshot. Workspace unit tests and generation checks belong to `test.yml` and `gen.yml`. The smoke gate runs Counter, Gallery, Workbench, the Reactor Composition host, standalone system Composition, and Reactor WebView, plus changed or new samples. PRs compare against their base commit; pushes compare against the previous branch tip, including every commit in the push. Each package is built independently, and GUI processes run serially. Scheduled and manually dispatched runs also enforce coverage floors, repeat the native self-test, and launch every sample. The routine gate targets roughly ten minutes; the exhaustive runs can take longer. CLI tools use pinned `cargo install` versions. The public API tool has a separate cache saved immediately after installation, so a later test failure does not discard the compiled tool. Run the sample selection checks without starting any windows: ```text pwsh -File crates\tests\libs\reactor_selftest\test_samples.ps1 ``` --- ### Code Of Conduct (`docs/code_of_conduct.md`) ## Code of conduct This project has adopted the [Microsoft Open Source Code of Conduct](https://opensource.microsoft.com/codeofconduct/). Resources: - [Microsoft Open Source Code of Conduct](https://opensource.microsoft.com/codeofconduct/) - [Microsoft Code of Conduct FAQ](https://opensource.microsoft.com/codeofconduct/faq/) - Contact [opencode@microsoft.com](mailto:opencode@microsoft.com) with questions or concerns --- ### Contributing (`docs/contributing.md`) ## Contributing This project welcomes contributions and suggestions. Most contributions require you to agree to a Contributor License Agreement (CLA) declaring that you have the right to, and actually do, grant us the rights to use your contribution. For details, visit https://cla.opensource.microsoft.com. When you submit a pull request, a CLA bot will determine whether you need to provide a CLA and decorate the PR appropriately (for example, with a status check or comment). Follow the bot's instructions. You only need to do this once across all repositories using our CLA. This project has adopted the [Microsoft Open Source Code of Conduct](https://opensource.microsoft.com/codeofconduct/). For more information, see the [Code of Conduct FAQ](https://opensource.microsoft.com/codeofconduct/faq/) or contact [opencode@microsoft.com](mailto:opencode@microsoft.com). ## Before Contributing Start by [opening a new issue](https://github.com/microsoft/windows-rs/issues/new/choose) or commenting on [an existing issue](https://github.com/microsoft/windows-rs/issues) to discuss a feature or bug fix. This lets maintainers and contributors agree on an approach before you spend time on a pull request. The [pull request template][pr-template] therefore asks you to refer to an existing issue. [pr-template]: https://github.com/microsoft/windows-rs/blob/master/.github/pull_request_template.md --- ### Dependencies (`docs/dependencies.md`) # Dependencies This page tracks every external SDK, header set, metadata file, and runtime the build and tooling depend on: the version, where it is pinned, how it is obtained, and how the pin is validated. It covers *build/tooling and runtime* dependencies (Windows SDK, WDK, WinRT contracts, libclang, Windows App SDK, WebView2). It does **not** cover the crates.io Rust dependencies in `Cargo.toml`, which are already centralized under `[workspace.dependencies]`. ## The model: one owner, validated by running There is no central version registry. Every external dependency has a single **owning tool** that declares the pin as a `const`, downloads/consumes the artifact at that exact version, and runs in CI (`.github/workflows/gen.yml`) - so *running the tool proves the pin is current*, in one of two ways: - **Generators** (`tool-win32`, `tool-winrt`, `tool-webview`, `tool-reactor-metadata`, `tool-reactor`) regenerate committed artifacts; `gen.yml` runs each then `git diff --exit-code`, so a stale pin produces a diff and fails. - **Validators** (`tool-clang`, and guards inside generators) assert invariants and write nothing; a violation panics loudly, failing the job with a clean tree. When one crate must track a pin another crate owns, the owner reads the peer's constant straight from source with [`helpers::read_str_const`](../crates/tools/helpers/src/lib.rs) and asserts they agree. Pins are never copied - they are read back and checked. `windows-clang` stays a clean libclang library and is **not** a shared home for SDK/runtime versions. ## At a glance | Dependency | Version | Owner (pin) | Obtained by | Validated by | | --- | --- | --- | --- | --- | | libclang | `22.1.8` | `LIBCLANG_VERSION` - `crates/libs/clang/src/provision.rs` | download (NuGet: `libclang.runtime.win-` + `git` sparse checkout of LLVM headers) | `tool-clang` validator + runtime assert | | Windows SDK | `10.0.28000.2270` | `SDK_VERSION` - `crates/tools/win32/src/main.rs` | download (NuGet) | `tool-win32` zero-diff regen | | Windows WDK | `10.0.28000.1839` | `WDK_VERSION` - `crates/tools/win32/src/km.rs` | download (NuGet) | `tool-win32` zero-diff regen | | SDK Contracts (WinRT) | `10.0.28000.2270` | `CONTRACTS_VERSION` - `crates/tools/winrt/src/main.rs` | download (NuGet) | `tool-winrt` zero-diff regen | | WebView2 SDK headers | `1.0.4078.44` | `WEBVIEW2_VERSION` - `crates/tools/webview/src/main.rs` | download (NuGet) | `tool-webview` zero-diff regen | | WinUI / Windows App SDK metadata (`.winmd` files) | `2.5.1` | `WINDOWS_APP_SDK_VERSION` - `crates/tools/reactor-metadata/src/main.rs` | download (NuGet) | `tool-reactor-metadata` zero-diff regen of the committed metadata | | Windows App SDK runtime | `2.5.1` | `RUNTIME_VER` - `crates/libs/reactor-setup/src/lib.rs` | download (NuGet) | `tool-reactor-metadata` guard: `== WINDOWS_APP_SDK_VERSION`, and `reactor.yml` matches | | WebView2 runtime projection | `1.0.4078.44` | `WEBVIEW2_VER` - `crates/libs/reactor-setup/src/lib.rs` | download (NuGet) | `tool-reactor-metadata` guard: `== WEBVIEW2_VERSION` | | LLVM / libclang (CI) | `22.1.8` | `LIBCLANG_VERSION` - `crates/libs/clang/src/provision.rs` | download (NuGet) via `tool-clang path` | `tool-clang`: loads the pin and asserts its version | ## Toolchain: libclang The header scrapers (`tool-win32`, `tool-webview`) parse C/C++ with libclang. The version is pinned because clang's macro-capture behavior drifts across majors, which would silently change the generated metadata. - **Owner:** `provision.rs` declares `LIBCLANG_VERSION = "22.1.8"`. `libclang.dll` comes from the `libclang.runtime.win-` NuGet packages (`dotnet/clangsharp`, .NET Foundation) fetched at that version. The paired clang builtin *resource headers* (needed only for the non-x64 arch passes, to reconcile the aarch64 `__prefetch` builtin) come from a blobless, shallow, sparse `git` checkout of `clang/lib/Headers` at the derived `llvmorg-` tag - so the DLL and headers are the *same* single-const pin and can never drift. - **Obtained:** if `LIBCLANG_PATH` is unset, `ensure_libclang` fetches the pinned `libclang.runtime.win-` package via `nuget_package` (the shared NuGet global cache, same as the SDK/WDK/WebView2 pins) and points `LIBCLANG_PATH` at its `runtimes//native/`; non-x64 passes also fetch the pinned LLVM resource headers via `git`. `LIBCLANG_PATH` / `CLANG_RESOURCE_DIR` override for offline machines. All three scrapers call it, so their `gen.yml` jobs need no LLVM install - they always parse with the pinned `22.1.8`, in CI and on a fresh checkout alike. - **CI:** every workflow self-provisions the pinned libclang from NuGet - no CI job installs LLVM. The `gen.yml` scrapers call `ensure_libclang`; `clippy.yml` loads no libclang at all (`cargo clippy` never parses); and `test.yml`, whose `windows-clang` tests load libclang at runtime, exports `LIBCLANG_PATH` from the same pin via `echo "LIBCLANG_PATH=$(cargo run -q -p tool-clang -- path)" >> "$GITHUB_ENV"`. `tool-clang path` prints `helpers::libclang_dir()`, keeping the `unsafe` `set_var` off the multithreaded test runner. The Linux CI jobs build code that needs no libclang. - **Validated by `tool-clang`:** fetches, loads, and version-asserts the pin (the same provisioning the scrapers run). Writes nothing. - **To update:** bump `LIBCLANG_VERSION` - a single const that drives both the NuGet DLL and the `llvmorg-` git tag for the headers, so there is nothing else to touch. Run `tool-clang` (must pass) and regenerate all metadata. No prebuilt-asset ceiling: the DLL comes from NuGet and the headers from a git tag, both of which track current LLVM. ## Windows SDK, WDK, and WinRT contracts Each feeds an in-house generator producing a committed `.winmd` in `windows-default`. The metadata is embedded for Rust build tools and remains available as files for external tools. Provenance is documented in [`crates/libs/default/readme.md`](../crates/libs/default/readme.md). `windows-bindgen`, `windows-rdl`, and `windows-clang` depend on `windows-default` so their builders can select this metadata without filesystem paths. Binaries linking those crates include both metadata files. | Package | Owner (pin) | Produces | | --- | --- | --- | | `Microsoft.Windows.SDK.CPP[.]` | `SDK_VERSION` - `tool-win32` | um scrape half of `Windows.Win32.winmd` | | `Microsoft.Windows.WDK.x64` | `WDK_VERSION` - `tool-win32` | km scrape half of `Windows.Win32.winmd` | | `Microsoft.Windows.SDK.Contracts` | `CONTRACTS_VERSION` - `tool-winrt` | `Windows.winmd` | - **Obtained:** `windows_clang::nuget_package(id, version)` restores from the NuGet global cache or downloads from nuget.org (`NUGET_PACKAGES` overrides the cache). - **`tool-win32` runs both scrapes**, so the WDK km scrape reuses the same `SDK_VERSION` headers as the um scrape (they share the crate); `WDK_VERSION` is a separate pin in `km.rs`. - The "marketing" include/lib folder nested in each package (e.g. `10.0.28000.0`) is **derived** from the version via `helpers::marketing_dir` (first three components + `.0`), so the version is the single edit - never a second folder constant to keep in sync. - **To update:** bump the owning constant, run `cargo run -p tool-`, and commit the regenerated `.rdl` snapshot(s) and `.winmd`. `CONTRACTS_VERSION` happens to share the `10.0.28000` build number with `SDK_VERSION`, but it is a distinct NuGet package with its own pin - the two are not coupled and can diverge. ## WebView2 WebView2 ships only C/C++ SDK headers, so `windows-webview` is scraped from them. The WinRT `Core` metadata and runtime projection DLL are separate artifacts. | Artifact | Owner / location | Used by | | --- | --- | --- | | `WebView2.h`, `WebView2Interop.h` | `WEBVIEW2_VERSION` - `tool-webview` (downloaded, not vendored) | `tool-webview` -> `webview/src/bindings.rs` | | `Microsoft.Web.WebView2.Core.winmd` | regenerated into `crates/tools/reactor-metadata/winmd/` by `tool-reactor-metadata` at `WEBVIEW2_VERSION` | `tool-webview`, `tool-reactor` | | Runtime projection (`Core.dll`), `WEBVIEW2_VER` | `crates/libs/reactor-setup/src/lib.rs` | self-contained apps | | Evergreen runtime | `.github/workflows/webview.yml` | CI test host | - **Headers are downloaded, not vendored:** `tool-webview` fetches the pinned NuGet package via `nuget_package` and parses the headers from it. A bump is a one-line `WEBVIEW2_VERSION` edit. - **Pinned libclang:** like `tool-win32`, `tool-webview` calls `ensure_libclang` + `assert_libclang_version`, so it parses with the exact pinned `22.1.8` (its `gen.yml` job needs no LLVM install - only the SDK include paths for the system headers `WebView2.h` pulls in). - **Runtime projection:** bump `WEBVIEW2_VER` in `reactor-setup`; it must equal `WEBVIEW2_VERSION` - `tool-reactor-metadata` asserts this. - **`Core.winmd`** is refreshed into the shared Reactor metadata by `tool-reactor-metadata` at `WEBVIEW2_VERSION` (see below). For the full pipeline and COM<->WinRT bridge, see [windows-webview](crates/windows-webview.md). ## WinUI / Windows App SDK `windows-reactor` is generated from WinUI / Windows App SDK `.winmd`; `windows-reactor-setup` stages the matching runtime so reactor apps run. Metadata and runtime are two faces of one release, tied to a single number. **Metadata is regenerated, not hand-copied.** `tool-reactor-metadata` owns `WINDOWS_APP_SDK_VERSION = "2.5.1"`. On every run it downloads the umbrella `Microsoft.WindowsAppSDK` metapackage at that version, reads the exact component versions (Foundation / InteractiveExperiences / WinUI) pinned in its nuspec, downloads each component, and copies their `.winmd` - plus `Microsoft.Web.WebView2.Core.winmd` at `WEBVIEW2_VERSION` - into the committed metadata at `crates/tools/reactor-metadata/winmd/`. `gen.yml` re-runs the tool and fails on any diff, so the metadata provably matches the pin. (`extras.winmd` in that directory is generated by `tool-reactor-metadata` from `Windows.Win32.winmd`, not a package.) The metadata stays committed because `tool-reactor`, `tool-webview`, and `tool-composition` read it. | Artifact | Owner / location | Used by | | --- | --- | --- | | WinUI / Windows App SDK `.winmd` + `WebView2.Core.winmd` | regenerated into `crates/tools/reactor-metadata/winmd/` at `WINDOWS_APP_SDK_VERSION` | `tool-reactor-metadata`, `tool-reactor`, `tool-webview`, `tool-composition` | | `Microsoft.WindowsAppSDK.Runtime`, `RUNTIME_VER` | `crates/libs/reactor-setup/src/lib.rs` | app runtime deploy | | `app.manifest`, `runtime.txt` | `crates/libs/reactor-setup/assets/` (committed) | runtime staging | | Runtime installer | `.github/workflows/reactor.yml` | CI test host | `windows-reactor-setup` is a published runtime helper with no generated artifact, so its pins can't be proven by regen. Instead **`tool-reactor-metadata` guards them** on every run, asserting (and failing loudly on drift) that: - `WINDOWS_APP_SDK_VERSION` (metadata) equals `RUNTIME_VER` (runtime) - one number drives both; - `WEBVIEW2_VER` equals `WEBVIEW2_VERSION`, so the staged WebView2 runtime matches the ABI the bindings target; and - `reactor.yml`'s installer URL installs `RUNTIME_VER` (`.../windowsappsdk///`), so CI's self-tests exercise the runtime apps ship. - **To update metadata + runtime:** bump `WINDOWS_APP_SDK_VERSION` (`tool-reactor-metadata`) and `RUNTIME_VER` (`reactor-setup`) together, update the `reactor.yml` installer URL, then run `cargo run -p tool-reactor-metadata` and commit the refreshed metadata. The guard enforces the version agreement; the regen enforces the metadata. - `assets/app.manifest` is a **generated activation asset with no committed generator** - `app.manifest` transforms the App SDK `package.appxfragment` files into SxS fusion format (source versions in its header). It is forward-compatible, so refreshed only when the reactor control set needs newly-moved classes, not on every bump. - `resources.pri` is staged from the App SDK runtime package only for self-contained deployment via `as_self_contained`; framework-dependent staging does not copy it. See [windows-reactor](crates/windows-reactor.md) and [windows-reactor-setup](crates/windows-reactor-setup.md). ## Download mechanisms Two independent NuGet paths, both using `https://www.nuget.org/api/v2/package/{id}/{version}`: - **`windows_clang::nuget_package`** - used by the scraping/codegen tools (`tool-win32`, `tool-winrt`, `tool-webview`, `tool-reactor-metadata`). Restores into the NuGet global cache (`NUGET_PACKAGES` overrides), else downloads via bundled `curl`/`tar`. Layout-agnostic - each caller indexes the subtree it needs. - **`reactor-setup`'s staging** - runs in the `build.rs` of every consuming app to stage the App SDK runtime and WebView2 projection. Dependency-free (std + the `curl.exe`/`tar.exe` shipped with Windows), which is why it does not reuse `nuget_package`. ## The `tool-*` / pin pairing | Tool | Proves | How | | --- | --- | --- | | `tool-win32` | `SDK_VERSION`, `WDK_VERSION` | zero-diff regen of `Windows.Win32.winmd` (um + km scrapes and their merge) | | `tool-winrt` | `CONTRACTS_VERSION` | zero-diff regen of `Windows.winmd` | | `tool-webview` | `WEBVIEW2_VERSION` | zero-diff regen of `webview/src/bindings.rs` | | `tool-clang` | `LIBCLANG_VERSION` (drives NuGet DLL + `llvmorg-` header tag) | pure-check assertion | | `tool-reactor-metadata` | `WINDOWS_APP_SDK_VERSION`; reactor-setup sync | zero-diff regen of the winmd files; guard reads reactor-setup constants | | `tool-reactor` | Reactor schema and WinUI projection | zero-diff regen of declarations, native code, bindings, canvas bridge bindings, and live coverage | All cross-file reads go through `helpers::read_str_const`, so each pin is declared once by its owner and read back everywhere else. --- ### Security (`docs/security.md`) ## Security Microsoft takes the security of our software products and services seriously, which includes all source code repositories managed through our GitHub organizations, which include [Microsoft](https://github.com/Microsoft), [Azure](https://github.com/Azure), [DotNet](https://github.com/dotnet), [AspNet](https://github.com/aspnet), [Xamarin](https://github.com/xamarin), and [many more](https://opensource.microsoft.com/). If you believe you have found a security vulnerability in any Microsoft-owned repository that meets Microsoft's [definition](https://docs.microsoft.com/en-us/previous-versions/tn-archive/cc751383(v=technet.10)) of a security vulnerability, please report it to us as described below. ## Reporting Security Issues **Please do not report security vulnerabilities through public GitHub issues.** Instead, please report them to the Microsoft Security Response Center (MSRC) at [https://msrc.microsoft.com/create-report](https://msrc.microsoft.com/create-report). If you prefer to submit without logging in, send email to [secure@microsoft.com](mailto:secure@microsoft.com). If possible, encrypt your message with our PGP key; please download it from the the [Microsoft Security Response Center PGP Key page](https://www.microsoft.com/en-us/msrc/pgp-key-msrc). You should receive a response within 24 hours. If for some reason you do not, please follow up via email to ensure we received your original message. Additional information can be found at [microsoft.com/msrc](https://www.microsoft.com/msrc). Please include the requested information listed below (as much as you can provide) to help us better understand the nature and scope of the possible issue: * Type of issue (e.g. buffer overflow, SQL injection, cross-site scripting, etc.) * Full paths of source file(s) related to the manifestation of the issue * The location of the affected source code (tag/branch/commit or direct URL) * Any special configuration required to reproduce the issue * Step-by-step instructions to reproduce the issue * Proof-of-concept or exploit code (if possible) * Impact of the issue, including how an attacker might exploit the issue This information will help us triage your report more quickly. If you are reporting for a bug bounty, more complete reports can contribute to a higher bounty award. Please visit our [Microsoft Bug Bounty Program](https://microsoft.com/msrc/bounty) page for more details about our active programs. ## Preferred Languages We prefer all communications to be in English. ## Policy Microsoft follows the principle of [Coordinated Vulnerability Disclosure](https://www.microsoft.com/en-us/msrc/cvd). --- ### Crates Cppwinrt (`docs/crates/cppwinrt.md`) # cppwinrt > The C++/WinRT compiler, bundled for use from Rust. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/cppwinrt) - ๐Ÿ“– [docs.rs](https://docs.rs/cppwinrt) - ๐Ÿš€ [Getting started](../../crates/libs/cppwinrt/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/cppwinrt) `cppwinrt` packages the [C++/WinRT](https://github.com/microsoft/cppwinrt) compiler so it can be invoked from a Rust build. It is a thin wrapper that runs the bundled `cppwinrt.exe` with the arguments you provide, returning its output. This is primarily useful for interop scenarios that also generate C++/WinRT projection headers. Rust code should prefer a focused crate or `windows-bindgen` implementation support. Binary applications can use the broad [`windows`](windows.md) projection when convenient. Use `cppwinrt` when a Rust build also compiles C++ that consumes or implements WinRT types. Start with the crate [README](../../crates/libs/cppwinrt/readme.md) for setup and the help invocation. The bundled executable runs only on Windows. ## First workflow: generate headers for a C++ build 1. Produce or obtain the component winmd. 2. Choose an output directory owned by the build, normally `OUT_DIR`. 3. Invoke `cppwinrt::cppwinrt` with `-in` for the component metadata and any reference metadata, then `-out` for the include directory. 4. Add that directory to the C++ compiler's include paths. 5. Link the libraries required by the generated C++ and the component. `crates/samples/robot/component_cpp/build.rs` is the component example. It compiles `src/robot.rdl` with [`windows-rdl`](windows-rdl.md), passes `robot.winmd` and the default metadata directory to C++/WinRT, then compiles `component.cpp` as C++20. The matching `robot/client_cpp/build.rs` consumes the component's winmd and compiles a C++ client. ## Input and output model `cppwinrt(args)` accepts any iterator of values convertible to `OsStr`, so paths do not need UTF-8 conversion. The arguments are passed unchanged to the bundled compiler. On success the function returns standard output as a `String`; on failure it panics with standard error. The wrapper copies `cppwinrt.exe` to a unique temporary path for each call, runs it synchronously, and removes the executable afterward. C++/WinRT itself writes the requested projection output. Call `cppwinrt(["-help"])` for the option set supported by the bundled compiler version. ## Integration and pitfalls - `windows-rdl` can compile a component's reviewable RDL contract to the winmd consumed here. - `windows-default` contains the standard winmd files, but C++/WinRT expects input paths. The robot samples pass the crate directory containing those files. - `windows-bindgen` is the Rust projection counterpart when both Rust and C++ consume one contract. - Gate build-script use to Windows with the MSVC environment when the build also invokes MSVC. - Add `rerun-if-changed` directives for component metadata and C++ sources. Generated headers alone do not tell Cargo when to rerun the build script. - The wrapper panics on compiler failure and does not return a structured status. Supply only validated arguments and let the build fail visibly. - Do not assume options from a newer standalone C++/WinRT release. Check the bundled compiler's `-help` output. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `cppwinrt`**. ### How it's built Packages the prebuilt `cppwinrt.exe`. `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/cppwinrt.txt` and supplies the `CoCreateGuid` call used for temporary directory names. ### Testing Run `cargo test -p cppwinrt`; see also the workspace test crates. --- ### Crates Windows Animation (`docs/crates/windows-animation.md`) # windows-animation > A safe wrapper around the Windows Animation Manager (`IUIAnimationManager`). - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-animation) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-animation) - ๐Ÿš€ [Getting started](../../crates/libs/animation/readme.md) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples/animation) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/animation) ## When to use it Use `windows-animation` when a Windows application needs time-based interpolation for values that it will draw or apply itself. It works well with immediate-mode rendering: advance the manager on each frame, read each `Variable`, and use the values in a canvas, Direct2D, Direct3D, or DirectComposition scene. The crate does not create a timer, request frames, draw content, or update a UI property. For retained WinUI visuals in [`windows-reactor`](windows-reactor.md), Reactor's Composition transitions usually fit better because the compositor owns their frame updates. ## Prerequisites Initialize COM on the thread that creates the animation objects. For a console or rendering thread, `windows_core::init_mta()` is suitable, as shown by the samples. A UI thread may use its existing apartment. Use one monotonic time origin for scheduling and updates. The README contains dependency setup and a minimal storyboard. The workflow below focuses on integrating animation into a real frame loop. ## First workflow: drive a rendered property 1. Create one `Manager` and one `TransitionLibrary`. 2. Create a `Variable` for each scalar property, using the current rendered value as its initial value. 3. Build a transition and schedule it at an absolute time from the application's animation clock. 4. On every requested frame, sample that clock and call `Manager::update(time)` once. 5. Read all variables, draw or apply the values, and request another frame while animation remains active. For example, the per-frame portion of a renderer can be kept separate from transition setup: ```rust,no_run use windows_animation::{Manager, Result, Variable}; fn draw_frame(manager: &Manager, x: &Variable, now: f64) -> Result { manager.update(now)?; let x = x.value()?; // Use `x` in the renderer for this frame. Ok(x) } ``` `now` is an absolute timestamp in the same time domain used when scheduling, not elapsed time since the previous frame. Supplying deltas makes the animation clock stall or move incorrectly. ## Core API and lifecycle `Manager` coordinates variables, transitions, and storyboards. Reuse it for values updated from the same frame clock. `Variable` holds the current interpolated `f64`. `TransitionLibrary` creates transition descriptions. `Transition` and `Storyboard` are retained COM-backed values and can be cloned. There are two scheduling paths: - `Manager::schedule_transition` applies one transition to one variable at an absolute start time. - `Manager::create_storyboard` creates a group that can coordinate several variables or sequence transitions before scheduling the group. Keep the `Manager` and every `Variable` needed by rendering alive for the animation lifetime. Propagate the `windows_core::Result` from creation, scheduling, updates, and value reads; COM initialization and invalid transition parameters are reported through those results. ## Transition choices | API | Use it for | | --- | --- | | `linear(duration, final_value)` | Constant-rate movement to a value. | | `accelerate_decelerate(...)` | Ease-in and ease-out movement. | | `instantaneous(final_value)` | A scheduled jump without interpolation. | Acceleration and deceleration are ratios of total duration and must sum to <= 1.0. Durations and final values use `f64`. For direct scheduling: ```rust,no_run use windows_animation::*; fn retarget(manager: &Manager, library: &TransitionLibrary, x: &Variable, now: f64) -> Result<()> { let transition = library.accelerate_decelerate(0.25, 320.0, 0.3, 0.3)?; manager.schedule_transition(x, &transition, now) } ``` ## Sequencing with storyboards `Storyboard::add_transition` adds a transition and returns a `Keyframe` marking its end. `add_transition_at_keyframe` starts another transition at that point. A keyframe can coordinate a later transition on the same variable or another variable. Build the entire storyboard before calling `schedule(start_time)`. Its time is absolute in the manager's clock domain. The `storyboard` sample sequences a rise and fall on one variable; the same pattern can start a fade after a movement finishes. ## Frame-loop and error pitfalls - Update a manager once per frame before reading its variables. Reading first returns the value from the previous update. - Use a monotonic high-resolution clock. Wall-clock changes must not move animation time backward. - Schedule and update with the same time origin. `0.0` is valid for a deterministic offline timeline, while a live app commonly uses seconds since renderer startup. - The crate does not report whether more frames are required. The application owns invalidation and its stop condition. - Do not block the UI thread between updates in an interactive application; missed updates appear as skipped visual frames even though interpolation remains time-correct. - Treat a failed creation, transition, schedule, update, or value read as an application error. Do not continue rendering with a stale value unless that is an explicit fallback. ## DirectComposition `Variable::copy_curve` copies the variable's curve to an object implementing `IDCompositionAnimation`. DirectComposition can then evaluate it on its own composition thread, without the application reading `Variable::value` each frame. This API targets Win32 DirectComposition, not the Windows.UI.Composition engine used by WinUI and Reactor. The two animation object models are not interchangeable. ## Samples Run the headless sample with: ```text cargo run -p animation-storyboard ``` The sample schedules one transition directly and chains two more through a storyboard keyframe. It initializes COM explicitly and prints deterministic values using the absolute-time update pattern. The [`canvas/clock`](../../crates/samples/canvas/clock) sample applies the same API in a live per-frame rendering loop. --- ## Internal documentation This section is for contributors to `windows-animation`. `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/animation.txt`. The hand-written `Manager`, `TransitionLibrary`, `Storyboard`, `Transition`, `Keyframe`, and `Variable` wrappers expose the selected Windows Animation Manager 2 interfaces. `Manager::new` and `TransitionLibrary::new` create their COM classes with `windows_core::create_instance`. Manager methods delegate scheduling and updates to `IUIAnimationManager2`. Storyboards add an explicit keyframe after each transition so the returned opaque `Keyframe` can anchor another transition. `Variable::copy_curve` casts the supplied interface to `IDCompositionAnimation` before copying the curve. Keep the generated filter and the hand-written surface aligned. The headless examples are also the clearest end-to-end checks of COM creation, direct scheduling, keyframe sequencing, and updates. --- ### Crates Windows Bindgen (`docs/crates/windows-bindgen.md`) # windows-bindgen > Generate Rust bindings for the Windows APIs your project needs. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-bindgen) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-bindgen) - ๐Ÿš€ [Getting started](../../crates/libs/bindgen/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/bindgen) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/bindgen) Use `windows-bindgen` to generate a focused binding set from Windows metadata (`.winmd`). It includes default Win32 and WinRT metadata and can also read custom metadata. For broad pre-generated bindings, use [`windows`](windows.md) or [`windows-sys`](windows-sys.md). The [README](../../crates/libs/bindgen/readme.md) shows dependency setup, generation from `build.rs`, and inclusion of the generated file. This guide covers API selection and generation options. ## Generate bindings Configure the builder, then call `write()`: ```rust,no_run windows_bindgen::builder() .output("src/bindings.rs") .filters(["GetTickCount", "GetTickCount64"]) .flat() .sys() .write(); ``` The command-line-style adapter does the same thing: ```rust,no_run windows_bindgen::bindgen([ "--out", "src/bindings.rs", "--flat", "--sys", "--filter", "GetTickCount", "GetTickCount64", ]); ``` Both forms require an output path and at least one include filter. Paths are relative to the generator's working directory. For a published library, run generation from a separate tool and commit `src/bindings.rs`. Consumers then need only the generated code's runtime dependencies. Applications can instead generate into `OUT_DIR` from `build.rs`, as shown in the README. ## Select APIs Start with the function, constant, or type name in the Windows API documentation. For example, `.filter("GetTickCount")` selects [`GetTickCount`][get-tick-count]. Include any `A` or `W` suffix in the metadata name; filters do not expand C preprocessor aliases. [get-tick-count]: https://learn.microsoft.com/windows/win32/api/sysinfoapi/nf-sysinfoapi-gettickcount Signature dependencies are included automatically. You do not need to list every parameter and return type. Select an interface or its members explicitly when you also need to call its methods. The bundled Win32 metadata places APIs in `Windows.Win32`. Bare names such as `GetTickCount` and qualified names such as `Windows.Win32.GetTickCount` both work. The subsystem paths used by `windows` and `windows-sys` package features, such as `Win32_System_Com`, are not metadata namespaces: do not turn them into filters such as `Windows.Win32.System.Com`. Filters accept dots or `::` between path segments and `{...}` for grouped names: | Filter | Selects | | --- | --- | | `GetTickCount` | A function by name. | | `HWND` | A type by name. | | `Windows.Win32.GetTickCount` | A function with its metadata namespace. | | `Windows::Win32::{GetTickCount, GetTickCount64}` | A group of functions. | | `Windows.Foundation` | A WinRT namespace and its children. | | `Windows.Storage.Streams.IDataReader::ReadByte` | One interface method. | | `Windows.Storage.Streams.IDataReader::{ReadByte, ReadUInt32}` | A group of methods. | | `Windows.Storage.Streams.IDataReader::ByteOrder` | A property's getter and setter. | | `Windows.Storage.Streams.IDataReader::{}` | The interface type without callable methods. | Bare names search all input namespaces; qualify a name when you need to distinguish matching definitions. For custom metadata, use the namespaces declared in that metadata. Interface shells do not expose iteration. Iteration helpers require `First`, or `Current`, `HasCurrent`, and `MoveNext` for an iterator. For runtime classes, select the instance, static, or factory methods you need. For example, `Windows.Foundation.Uri::CreateUri` selects a factory method; a class name alone does not select its factory methods. Member filters select methods on a type, not free functions in a subsystem namespace. Property and event names select their accessor pairs. For type and namespace selections, prefix a filter with `!` to exclude it. More specific rules take precedence; exclusions win ties regardless of argument order. Prefer narrow filters to generating a namespace and removing items from it. ### Keep longer filter lists in a file Create `apis.txt` with one filter per line: ```text // APIs used by this project. GetTickCount GetTickCount64 ``` Use `.filter_file("apis.txt")` or `--filter-file apis.txt`. Blank lines and lines beginning with `//` are ignored. A file containing the entire argument list can be read with `--etc`. ## Choose the output Style controls the generated API. Layout controls where it is written. | Builder option | Argument | Use | | --- | --- | --- | | Default style | No flag | Rich wrappers using `windows-core`. | | `sys()` | `--sys` | Raw bindings using `windows-link`. | | `minimal()` | `--minimal` | Bindings for hand-written wrappers, without most conveniences. | | Default layout | No flag | Nested Rust modules matching metadata namespaces. | | `flat()` | `--flat` | One flat file, suitable for a private bindings module. | | `package()` | `--package` | A Cargo package with namespace files and features. | `sys` and `minimal` are mutually exclusive, as are `flat` and `package`. Narrow filters are needed in every style. Generated APIs may also use focused support crates such as `windows-numerics`; add the dependencies referenced by the generated source. ### Bit-field accessors For native bit fields, default and minimal bindings provide getters and setters over the backing integer fields. Sys bindings keep the backing fields without accessors. ## Common options The [builder reference] documents all methods, and [`bindgen`] lists the command-line-style arguments. [builder reference]: https://docs.rs/windows-bindgen/latest/windows_bindgen/struct.Bindgen.html [`bindgen`]: https://docs.rs/windows-bindgen/latest/windows_bindgen/fn.bindgen.html | Builder method | Argument | Purpose | | --- | --- | --- | | `input(path)` | `--in path` | Read a custom `.winmd` file or directory. | | `input_default()` | `--in default` | Add the bundled Windows metadata. | | `output(path)` | `--out path` | Set the output file or package directory. | | `filter(name)` / `filters(names)` | `--filter names...` | Select APIs. | | `filter_file(path)` | `--filter-file path` | Read filters from a text file. | | `implement(name)` | `--implement name` | Generate interface implementation traits. | | `implement_all()` | `--implement` | Generate implementation traits for all interfaces in scope. | | `derive(name)` | `--derive name` | Add a derived trait to generated types. | | `rustfmt(options)` | `--rustfmt options` | Pass comma-separated formatter configuration. | | `extern_fns()` | `--extern` | Use extern declarations instead of link macros with `sys`. | | `compose(name)` | `--compose name` | Select a WinRT class for composition with `minimal`. | | `dead_code()` | `--dead-code` | Use `pub(crate)` visibility to detect unused callable bindings. | For `compose`, also filter the class and its composable factory methods, and select its override interfaces with `implement`. With no explicit input, generation uses the bundled metadata. Adding a custom input replaces that default; add `input_default()` if it also needs Windows definitions. Compile RDL with [`windows-rdl`](windows-rdl.md), or scrape headers with [`windows-clang`](windows-clang.md), before passing the resulting `.winmd` to bindgen. Formatting uses `rustfmt` from `PATH` and is best effort: unavailable or failed formatting leaves the output unformatted without a warning. `rustfmt("max_width=120")` sets configuration, not an executable path. Install `rustfmt` when generating checked-in source. ## Samples | Sample | Shows | | --- | --- | | [VSS backup](../../crates/samples/bindgen/vss_backup) | Rich COM bindings in `OUT_DIR`. | | [Context](../../crates/samples/bindgen/context_alignment) | Flat sys bindings. | | [Robot component](../../crates/samples/robot/component) | Custom RDL and implementation support. | | [Robot client](../../crates/samples/robot/client) | Custom and default metadata together. | ## Contributing The generator reads metadata through [`windows-metadata`](windows-metadata.md). `test_bindgen` contains the fixtures; run `cargo test -p test_bindgen` and `cargo test -p windows-bindgen`. After changing generation logic, run the affected `tool-*` generators and inspect the output diffs. `tool-bindings` generates focused library bindings; `tool-package` generates the published `windows` and `windows-sys` packages. --- ### Crates Windows Canvas (`docs/crates/windows-canvas.md`) # windows-canvas > Safe 2D drawing over Direct2D, Direct3D 11, DXGI, DirectWrite, and WIC. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-canvas) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-canvas) - ๐Ÿš€ [Getting started](../../crates/libs/canvas/readme.md) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples/canvas) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/canvas) - [Reactor guide](windows-reactor.md) - [Composition guide](windows-composition.md) ## When to use it Use Canvas for custom 2D graphics, charts, diagrams, image processing, text layout, geometry hit testing, or animation. It is a drawing API rather than a control toolkit. Combine it with Reactor when the app also needs WinUI controls. Use Composition when the scene is primarily a retained tree of visuals that Windows animates and composes. Use Canvas when the app draws pixels and paths for each requested frame. The two can be combined by drawing Canvas content into a composition surface. Canvas is host-neutral by default. Enable `system` for the typed `windows-window` swap-chain helper and system Composition, or `reactor` for Reactor controls and lifted Composition. Enable `composition` with the selected host to draw into Composition surfaces. The host adapters can coexist when `composition` is not enabled; the Composition backends cannot. ## The basic idea Canvas is an immediate-mode drawing API. The application receives a drawing session and describes the current frame with commands such as `clear`, `fill_rect`, `draw_text`, and `draw_bitmap`. ```text begin a frame -> issue drawing commands -> finish the frame -> present it ``` There is no retained scene tree. If a shape should still be visible in the next frame, draw it again. Keep application state - points, colors, text, images - in normal Rust data and turn that state into drawing commands. The simplest host is Reactor. It creates the graphics device and swap chain, tracks size and display scale, and handles device recovery. Enable the feature in `Cargo.toml`: ```toml windows-canvas = { version = "0.100.0", default-features = false, features = ["reactor"] } windows-reactor = "0.100.0" ``` ## Your first canvas `canvas` draws once when the surface is ready and again when its size or display scale changes: ```rust,ignore use windows_canvas::*; use windows_reactor::App; fn draw(ctx: &DrawContext) -> Result<()> { ctx.clear(ColorF::DARK_SLATE_BLUE); let brush = ctx.create_solid_brush(ColorF::CORNFLOWER_BLUE)?; let center = Vector2::new(ctx.width / 2.0, ctx.height / 2.0); let radius = ctx.width.min(ctx.height) * 0.3; ctx.fill_ellipse(&Ellipse::circle(center, radius), &brush); Ok(()) } fn main() -> Result<()> { App::run(canvas(draw)) } ``` The callback receives a `DrawContext`. Its `width` and `height` are the available size in device-independent pixels. It dereferences to `DrawingSession`, so drawing methods and resource creation are available directly on `ctx`. Clear the surface, or fully cover it, unless keeping pixels from the previous frame is intentional. ## Draw shapes with brushes A brush supplies paint. Create it once within a frame and reuse it for as many operations as needed: ```rust,ignore let brush = ctx.create_solid_brush(ColorF::CORNFLOWER_BLUE)?; ctx.fill_rect(&Rect::from_xywh(20.0, 20.0, 160.0, 100.0), &brush); ctx.draw_ellipse( &Ellipse::circle(Vector2::new(260.0, 100.0), 60.0), &brush, 4.0, ); brush.set_color(ColorF::WHITE); ctx.draw_line( Vector2::new(20.0, 160.0), Vector2::new(320.0, 160.0), &brush, 2.0, ); ``` `Rect`, `RoundedRect`, and `Ellipse` are lightweight geometry values. Use `fill_*` for a solid interior and `draw_*` for an outline. Gradient brushes use the same drawing methods. ## Apply a temporary transform `with_transform` applies translation, rotation, or scale only while its closure runs, then restores the previous transform: ```rust,ignore let transform = Matrix3x2::rotation_around(15.0, Vector2::new(ctx.width / 2.0, ctx.height / 2.0)); ctx.with_transform(&transform, || { ctx.fill_rect( &Rect::from_xywh(ctx.width / 2.0 - 80.0, ctx.height / 2.0 - 40.0, 160.0, 80.0), &brush, ); }); ``` Scoped transforms make helper functions easier to combine because one drawing operation cannot leave a transform behind for the next one. ## Build a custom path For a polygon, `PathBuilder::polygon` is the shortest route: ```rust,ignore let points = [ Vector2::new(160.0, 40.0), Vector2::new(280.0, 240.0), Vector2::new(40.0, 120.0), Vector2::new(280.0, 120.0), Vector2::new(40.0, 240.0), ]; let star = PathBuilder::new(ctx.device())?.polygon(points)?; let brush = ctx.create_solid_brush(ColorF::new(1.0, 0.8, 0.0, 1.0))?; ctx.fill_path(&star, &brush); ``` Use `begin`, `line_to`, and `bezier_to` when the path needs individual segments: ```rust,ignore let curve = PathBuilder::new(ctx.device())? .begin_hollow(Vector2::new(40.0, 160.0)) .bezier_to( Vector2::new(120.0, 20.0), Vector2::new(240.0, 300.0), Vector2::new(320.0, 160.0), ) .end_open() .build()?; ctx.draw_path(&curve, &brush, 3.0); ``` Paths also support bounds and fill or stroke hit testing, which is useful for diagrams and editors. ## Draw text For ordinary text, create a `TextFormat` and draw into a rectangle: ```rust,ignore let format = TextFormat::new("Segoe UI", 32.0)? .with_alignment(TextAlignment::Center) .with_paragraph_alignment(ParagraphAlignment::Center); let brush = ctx.create_solid_brush(ColorF::WHITE)?; ctx.draw_text( "Hello, Canvas!", &format, &Rect::new(0.0, 0.0, ctx.width, ctx.height), &brush, ); ``` Use `TextLayout` when text is drawn repeatedly or needs measurement, reflow, caret bounds, or hit testing. Cache the layout and rebuild it when its text, format, size, or device changes. The [`text_layout`](../../crates/samples/canvas/text_layout) sample shows that pattern. ## Load and draw an image `load_bitmap` decodes an image file: ```rust,ignore let bitmap = ctx.load_bitmap("assets/photo.png")?; let destination = Rect::from_xywh(20.0, 20.0, bitmap.width(), bitmap.height()); ctx.draw_bitmap(&bitmap, &destination, 1.0); ``` For generated image data, `create_bitmap` accepts tightly packed premultiplied BGRA pixels: ```rust,ignore let bitmap = ctx.create_bitmap(&pixels, width, height)?; ctx.draw_bitmap( &bitmap, &Rect::from_xywh(0.0, 0.0, width as f32, height as f32), 1.0, ); ``` Bitmaps, brushes, paths, and text layouts depend on the graphics device. Creating them inside the draw callback is the easiest starting point. Cache expensive resources only when profiling shows the need, and rebuild cached resources when `ctx.device_changed()` is true. ## Redraw when state changes Use `canvas` when content changes only because the surface was created or resized. Use `animated_canvas` for motion that needs every display frame: ```rust,ignore animated_canvas(|ctx| { draw_frame(ctx, elapsed_time()) }) ``` For input-driven content, use `canvas_invalidated`. Store an `Invalidator` with the component, change the drawing data in `update`, and request one new frame: ```rust,ignore struct Sketch { points: Rc>>, invalidator: Invalidator, } fn update(&mut self, point: Vector2, _context: &ComponentContext) { self.points.borrow_mut().push(point); self.invalidator.invalidate(); } fn draw_points(ctx: &DrawContext, points: &[Vector2]) -> Result<()> { ctx.clear(ColorF::BLACK); let brush = ctx.create_solid_brush(ColorF::WHITE)?; for &point in points { ctx.fill_ellipse(&Ellipse::circle(point, 3.0), &brush); } Ok(()) } fn view(&self, _input: &(), _context: &mut ViewContext) -> View { let points = Rc::clone(&self.points); canvas_invalidated(&self.invalidator, move |ctx| { draw_points(ctx, &points.borrow()) }) } ``` Invalidation keeps the app idle between changes. Do not use continuous animation for a chart, drawing, or diagram that changes only after input. ## Drive a standalone swap chain Without Reactor, the application creates a `GpuDevice` and `SwapChain` and owns the frame loop. The essential sequence is: ```rust,no_run use windows_canvas::*; fn draw_frame(chain: &mut SwapChain) -> Result { let session = chain.begin_draw()?; session.clear(ColorF::DARK_SLATE_BLUE); let brush = session.create_solid_brush(ColorF::CORNFLOWER_BLUE)?; session.fill_rect(&Rect::from_xywh(20.0, 20.0, 200.0, 120.0), &brush); drop(session); chain.present() } ``` The drawing session borrows the swap chain, so finish and drop it before `present`. A standalone host must also resize the swap chain, update display scale, schedule frames, and recreate the device, swap chain, and dependent resources when `present` returns `Ok(false)`. The [`standalone`](../../crates/samples/canvas/standalone) sample connects those pieces to `windows-window`. Its resize callback redraws the existing swap chain because the outer render loop is suspended while Windows runs its modal interactive-sizing loop. ## What to read next | Sample | What it shows | | --- | --- | | [`circles`](../../crates/samples/canvas/circles) | Drawing, animation, and resize handling | | [`clock`](../../crates/samples/canvas/clock) | Continuous animation | Browse [`crates/samples/canvas`](../../crates/samples/canvas) for focused drawing and hosting examples. --- ## Internal documentation The remainder of this page describes how the crate is built and maintained. Applications do not need it to use Canvas. ### Architecture The safe wrappers are hand-written and include `GpuDevice`, `SwapChain`, `DrawingSession`, geometry, brushes, text, bitmaps, effects, and render targets. `GpuDevice` owns the shared Direct3D, Direct2D, DXGI, DirectWrite, and WIC objects. A swap chain owns one D2D device context and is rendered on its owning thread. WARP allows tests and callers to render without a physical GPU. `device_lost.rs` classifies D2D and DXGI loss codes. Standalone callers perform recovery. The Reactor host rebuilds its device, swap chain, and cached state after loss. The Reactor integration lives behind this crate's `reactor` feature. The dependency direction is `windows-canvas[reactor] -> windows-reactor`. Canvas owns rendering resources and receives only typed panel metrics, rendering notifications, deferred frame callbacks, and attachment completion through `ElementRef`. The `system` feature enables `windows-window` and `GpuDevice::create_swap_chain_for_window`. Reactor-only builds do not compile `windows-window`; raw `create_swap_chain_for_hwnd` remains available without either host. Continuous mode uses WinUI's `CompositionTarget::Rendering` for its normal animation clock. Layout and scale changes also request a coalesced dispatcher frame because composition rendering can be delayed while WinUI processes interactive resize input. Demand mode stays idle until layout, scale, or `Invalidator` requests a frame. Panel binding, swap-chain, and attachment-request generations reject stale completion callbacks. Resizing buffers preserves the existing panel attachment; only panel replacement or swap-chain rebuilding requires `SetSwapChain`. `Canvas::on_error` reports initialization, attachment, resize, drawing, presentation, and failed recovery through `IntegrationError`. `CanvasImageSource` uses a borrowed drawing session over a WinUI `SurfaceImageSource`. `CanvasCompositionExt` uses a borrowed drawing session over `ICompositionDrawingSurfaceInterop`. Both pair every successful `BeginDraw` with `EndDraw`, including panic cleanup. If a composition-surface draw reports device loss, create a replacement `GpuDevice`, call `GpuDevice::replace_graphics_device` to rebind the existing `CompositionGraphicsDevice`, and retry the draw. The Composition surfaces and visuals remain in place during recovery. ### Code generation `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/canvas.txt`. It contains minimal flat bindings for Direct2D, Direct3D 11, DXGI, DirectWrite, and WIC, plus referenced WinRT numerics types. `src/reactor_bindings.rs` is generated by `tool-reactor` for the WinUI bridge. Generated files are committed and must not be edited by hand. After changing `crates/tools/reactor/src/canvas.txt` or the generator, run the corresponding tool and verify `cargo check -p windows-canvas --quiet`. ### Testing Canvas tests use the WARP software rasterizer and do not require a physical GPU. The integration suite is in `test_canvas`: ```text cargo test -p test_canvas ``` Use `RenderTarget` for off-screen drawing tests. Repeated presents on a composition swap chain without a visual consumer can leave WARP waiting for queued work during device destruction. Reactor integration behavior is also covered by Reactor's recording and live surface tests. The Composition Canvas sample covers the system bridge, and the Stacker Reactor sample covers the lifted bridge. --- ### Crates Windows Clang (`docs/crates/windows-clang.md`) # windows-clang > Generates RDL from C/C++ headers using libclang. - [crates.io](https://crates.io/crates/windows-clang) - [docs.rs](https://docs.rs/windows-clang) - [Getting started](../../crates/libs/clang/readme.md) - [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/clang) `windows-clang` is the header-facing stage of the Windows metadata pipeline: ```text headers -> windows-clang -> RDL -> windows-rdl -> WinMD ``` It extracts declarations and source annotations from C and C++ headers. Compile the resulting RDL with [`windows-rdl`](windows-rdl.md), then use [`windows-bindgen`](windows-bindgen.md) to generate Rust bindings. ## Setup The [README](../../crates/libs/clang/readme.md) shows the Cargo dependency. Install a compatible libclang and set `LIBCLANG_PATH` to its directory if it is not discoverable on your system. The crate loads libclang at runtime; it does not install it or the headers you want to process. Supply compiler arguments for the language, target architecture, include directories, and preprocessor definitions your headers require. Metadata references do not supply C/C++ headers or compiler include paths. ## Generate RDL Configure the builder, then call `write()`: ```rust,no_run windows_clang::clang() .input("Example.h") .args(["-x", "c++", "--target=x86_64-pc-windows-msvc"]) .reference_default() .namespace("Example") .library("example.dll") .output("Example.rdl") .write() .unwrap(); ``` At least one input, a namespace, and an output path are required. Paths are relative to the generator's working directory. | Builder method | Purpose | | --- | --- | | `input(path)` / `inputs(paths)` | Read header files as separate translation units. | | `input_text(source)` | Add an in-memory translation unit. | | `args(arguments)` | Pass compiler arguments to libclang. | | `filter(suffix)` | Include declarations from included headers matching a path suffix. | | `symbols(names)` | Restrict emitted free functions to the supplied names. | | `reference(path)` | Resolve existing declarations from a WinMD file. | | `reference_default()` | Use the bundled Windows metadata as references. | | `namespace(name)` | Set the output RDL namespace. | | `library(name)` | Set the DLL name attached to emitted functions. | | `output(path)` | Set the output RDL file. | Declarations from input headers are output roots. Included headers can supply dependencies without having all their declarations emitted; use `filter` to include their declarations as roots too. This is a header-path filter, not a function-name filter. References let generated RDL use existing types without redefining them. Use `reference_default` when your headers depend on Windows APIs and `reference` for your own metadata. The [builder reference](https://docs.rs/windows-clang/latest/windows_clang/struct.Clang.html) documents all methods. ## Inspect extraction results Use `Input`, `extract`, and `EmitOptions` directly when a generator needs to inspect declarations, assign different DLLs to functions, or emit separate header partitions. ```rust,no_run let input = windows_clang::Input::new( "Example.h", std::fs::read_to_string("Example.h").unwrap(), ); let snapshot = windows_clang::extract( [input], &["-x", "c++", "--target=x86_64-pc-windows-msvc"], ) .unwrap(); ``` The resulting `Snapshot` owns translation-unit-local facts and constants. `facts`, `constants`, `unsupported`, and `dump` expose the extraction result for diagnostics and validation. `Input::new(name, source)` treats `name` as a root. The following methods control which included headers contribute output roots: | Method | Selects | | --- | --- | | `with_roots(paths)` | Individual header paths. | | `with_root_dirs(paths)` | Headers under directory prefixes. | | `with_root_suffixes(suffixes)` | Headers matching path suffixes. | | `with_excluded_roots(paths)` | Headers excluded from output ownership. | ## Configure emission Use `Snapshot::emit(namespace)` for one namespace, `emit_with_library` to attach one DLL to all functions, or `emit_with_options` for generator policy. `emit_by_header_with_options` returns a map of defining-header names to RDL partitions. `EmitOptions` controls: | Option | Purpose | | --- | --- | | `namespace` | RDL namespace. | | `library` / `libraries` | Default or per-function DLL mappings. | | `references` | External types and enum members available to the projection. | | `excluded_types` | Types excluded from root selection. | | `excluded_functions` | Functions omitted from the local output. | | `excluded_constants` | Constants omitted from the local output. | | `functions` | Optional free-function allowlist. | References are explicit `TypeReference` values classified as `Type`, `Interface`, or `Enum`. Referenced enum member names let an overlay emit an enum only when it adds members to the base. `MetadataReferences` builds that map from WinMD files and records existing type, function, and constant names for exclusion. `apply_reference_exclusions` excludes only types with an unambiguous external reference, while `apply_exclusions` is available for overlays that must omit every item from a known base. Exclusions filter root declarations; they do not establish that a dependency has an external definition. Supply references for external types; required local dependencies are still emitted. The caller owns DLL selection, architecture merging, and RDL-to-WinMD compilation. Extraction does not discover import libraries or combine target architectures automatically. ## Known limits - RDL cannot represent mixed raw pointer-chain mutability. If any level in a raw pointer run is const, every level in that run is emitted as const. - Coverage is limited to declarations reachable from configured roots. - Conflicting declarations can fail emission as ambiguous; extraction is not a general C++ binding generator. - SAL projection supports only a subset of annotations and size relationships. - Non-finite floating-point constants and interface-valued constants cannot be emitted. - Header extraction cannot infer curated handle cleanup, last-error, or documentation policy. - Stable Rust has no function-pointer ABI corresponding to every native calling convention. ## Contributing Run `cargo test -p windows-clang` and `cargo test -p test_clang`. Header fixtures and expected RDL live in `crates/tests/libs/clang`; tests regenerate the expected output, and CI rejects output changes that are not committed. After changing extraction or emission, run the affected `tool-*` generators and review the output diffs. Repository tooling provisions its pinned libclang with `cargo run -q -p tool-clang -- path`. Set `LIBCLANG_PATH` to the reported directory before running tests. --- ### Crates Windows Collections (`docs/crates/windows-collections.md`) # windows-collections > Stock WinRT collection types backed by Rust containers. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-collections) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-collections) - ๐Ÿš€ [Getting started](../../crates/libs/collections/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/collections) ## When to use this crate Use `windows-collections` when a WinRT API expects a collection interface and your data starts as a Rust `Vec` or `BTreeMap`. The crate supplies stock implementations of the standard WinRT interfaces, so application and component code do not need to implement their vtables. This is an ABI adapter, not a replacement for Rust collections. Keep data as `Vec` or `BTreeMap` while it remains inside Rust, and convert at the boundary where a WinRT collection is required. ## Getting started The crate [README](../../crates/libs/collections/readme.md) contains the dependency declaration and minimal vector and map examples. The stock implementations require the default `std` feature. For a first workflow: 1. Identify the exact interface in the receiving API's signature. 2. Build the values in a `Vec` or `BTreeMap`. 3. Convert the container with `InterfaceType::from`. 4. Pass or return the projected interface and handle its methods as fallible operations. ```rust use windows_collections::IVector; fn numbers() -> IVector { let values = IVector::::from(vec![1, 2, 3]); values.Append(4).unwrap(); values } ``` In application code, propagate the `Result` returned by collection methods instead of unwrapping when the operation can fail. ## Choosing a collection interface | Interface | Backing input | Choose it when the consumer needs | | --- | --- | --- | | `IIterable` | `Vec` | Forward iteration only | | `IVectorView` | `Vec` | Indexed, read-only access | | `IVector` | `Vec` | Indexed mutation | | `IObservableVector` | `Vec` | Mutation notifications | | `IMapView` | `BTreeMap` | Read-only lookup | | `IMap` | `BTreeMap` | Insert, remove, and lookup | | `IObservableMap` | `BTreeMap` | Map mutation notifications | `T::Default` is the Rust storage form defined by the type's `RuntimeType` implementation. For ordinary value types it is usually `T`. Projected nullable or interface types may use an `Option` storage form, so let the compiler guide the concrete container type. The mutable interfaces own their Rust containers behind synchronization. View conversions own read-only values, and `GetView` on a mutable collection returns a snapshot rather than a live view. ## Common tasks ### Build and read a map ```rust use std::collections::BTreeMap; use windows_collections::IMapView; use windows_strings::{h, HSTRING}; fn main() { let values = BTreeMap::from([ (HSTRING::from("one"), 1), (HSTRING::from("two"), 2), ]); let values = IMapView::::from(values); assert!(values.HasKey(h!("one")).unwrap()); assert_eq!(values.Lookup(h!("two")).unwrap(), 2); } ``` Missing keys and invalid vector indexes return the WinRT `E_BOUNDS` error. Check with `HasKey` or `Size` when absence is expected rather than using an error as normal control flow. ### Iterate projected values Generated `IntoIterator` implementations allow a borrowed or owned collection to be used in a `for` loop. Each item is still a projected value, and map iteration yields `IKeyValuePair`: ```rust # use windows_collections::IIterable; let values = IIterable::::from(vec![1, 2, 3]); for value in &values { println!("{value}"); } ``` Iteration uses `GetMany` in blocks instead of making one iterator ABI call for each item. Reading each map pair's `Key` and `Value` remains a separate ABI operation. ### Publish collection changes Convert a container to `IObservableVector` or `IObservableMap` when consumers need `VectorChanged` or `MapChanged`. Register the projected event handler, retain its token, and pass that token to the corresponding remove method when the subscription ends. Mutating through the observable interface raises insertion, removal, replacement, or reset notifications. ## Important choices and pitfalls - Convert to the interface the API asks for. A mutable `IVector` is unnecessary when the API accepts `IIterable` or `IVectorView`. - Conversion consumes the Rust container. Clone it first only when Rust must retain an independent copy. - `GetView` snapshots the current contents. Later writes to the mutable source are not reflected in that view. - Map iteration snapshots entries when `First` is called. It does not hold a live traversal of the backing `BTreeMap`. - Calls cross a WinRT ABI and return `Result`; repeated fine-grained lookups can cost more than processing the original Rust container before conversion. ## Samples and next steps The [`collections-collections`](../../crates/samples/collections/collections) sample converts a `Vec` and a `BTreeMap`, mutates the projected interfaces, and iterates their values. Continue with the [docs.rs API](https://docs.rs/windows-collections) for the methods on the interface required by your Windows API. [`windows-reference`](windows-reference.md) covers boxed WinRT values that can also appear as collection elements. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-collections`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/collections.txt`; the collection adapters are hand-written. Used internally by the `windows` crate. Iterating a collection (`for x in &vector`) yields through `BufferedIterator` (`src/buffered_iterator.rs`), which fetches elements a block at a time via `GetMany` rather than one `IIterator::next` ABI call per element. `windows-bindgen` generates the `IntoIterator` impls that reference it. The block is sized to keep the buffer near 2 KB regardless of element size. This batching applies to **maps too**: `IMap`/`IMapView`/`IObservableMap` implement `IIterable>`, so `for pair in &map` drives the same `BufferedIterator` (yielding `IKeyValuePair` items) - there is no separate, slower map path. A map iteration still costs more than a vector of scalars, but not because of the iterator: `GetMany` over `IVector` bulk-copies the values inline, whereas over a map it returns a block of `IKeyValuePair` COM objects (one `AddRef` each) and reading every `pair.Value()`/`Key()` remains a per-pair ABI crossing - the `IMap` ABI offers no bulk key/value read. Separately, the *component-side* stock map iterator snapshots its entries once at `First()` so each step is O(1) rather than re-walking the tree, keeping a full traversal linear. ### Testing Run `cargo test -p windows-collections`; see also the workspace test crates. --- ### Crates Windows Composition (`docs/crates/windows-composition.md`) # windows-composition > Safe wrappers for the Windows retained-mode composition engine. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-composition) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-composition) - ๐Ÿš€ [Getting started](../../crates/libs/composition/readme.md) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples/composition) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/composition) - [Reactor hosting samples](../../crates/samples/composition) - [Canvas guide](windows-canvas.md) - [Window guide](windows-window.md) ## When to use it Use Composition for a retained tree of lightweight visuals, brushes, shapes, and animations. It is a good fit for animated backgrounds, overlays, game boards, transitions, and scenes where Windows should retain and compose objects between updates. Composition does not provide controls, text input, accessibility behavior, or layout panels. Use [`windows-reactor`](windows-reactor.md) for WinUI controls. Use [`windows-canvas`](windows-canvas.md) when custom drawing is easier as immediate-mode 2D commands. Composition can host Canvas-drawn surfaces. ## The basic idea Composition is a retained graphics API. You create a tree of visual objects, change their properties when application state changes, and let Windows draw and animate the result. ```text create visuals -> attach them to a tree -> update properties -> Windows composes the scene ``` This differs from Canvas, where the application issues drawing commands for each frame. A Composition visual stays in the tree until it is removed. Changing its offset, size, brush, or animation is enough to change what appears on screen. A `Compositor` creates every object in a scene. The most common visual types are: | Type | Purpose | | --- | --- | | `ContainerVisual` | Groups child visuals without drawing content | | `SpriteVisual` | Draws a rectangular brush and can contain children | | `ShapeVisual` | Draws retained vector shapes | Start with sprite visuals. They are enough for backgrounds, cards, overlays, game pieces, and many animations. ## Choose how to host the scene The crate supports two Composition stacks: | Feature | Use it when | | --- | --- | | `system` (default) | The app owns a `windows-window` window | | `reactor` | The scene belongs inside a Reactor view | The two stacks use different Windows APIs and their objects cannot be mixed. Cargo features are mutually exclusive, so applications selecting Reactor must disable the default `system` feature: ```toml windows-composition = { version = "0.100.0", default-features = false, features = ["reactor"] } ``` Both stacks can create a graphics device and drawing surface for `windows-canvas`. Enable Canvas's `composition` feature and select its matching `system` or `reactor` feature. The examples below begin with the default system stack because it shows the visual model with the least framework code. ## Your first visual tree This complete program creates a window and fills it with a dark sprite: ```rust,no_run use windows_composition::*; use windows_window::*; fn main() -> Result<()> { let _queue = DispatcherQueueController::create_on_current_thread()?; let compositor = Compositor::new()?; let window = Window::new("Composition") .size(800, 600) .create()?; let target = compositor.create_desktop_window_target(&window, false)?; let root = compositor.create_sprite_visual(); root.set_relative_size_adjustment(Vector2::new(1.0, 1.0)); root.set_brush(&compositor.create_color_brush(CompositionColor::rgb(30, 30, 46))); target.set_root(&root); run(); Ok(()) } ``` The dispatcher queue and target must stay alive while the scene is displayed. Declaring them in `main` keeps their lifetimes clear. The `Compositor` creates both the visual and its brush. Composition objects in one tree should come from the same compositor. ## Build a scene from nested visuals Visuals form an ordered tree. Insert a child at the top to draw it in front of existing children, or at the bottom to draw it behind them: ```rust,ignore let card = compositor.create_sprite_visual(); card.set_size(240.0, 160.0); card.set_offset(40.0, 40.0, 0.0); card.set_brush(&compositor.create_color_brush(CompositionColor::rgb(0, 120, 215))); let badge = compositor.create_sprite_visual(); badge.set_size(32.0, 32.0); badge.set_offset(192.0, 16.0, 0.0); badge.set_brush(&compositor.create_color_brush(CompositionColor::rgb(255, 255, 255))); card.children().insert_at_top(&badge); root.children().insert_at_top(&card); ``` The badge's offset is relative to the card. Moving the card moves both visuals. Keep handles to visuals that the application will change later; attached visuals remain in the scene even if a local clone is dropped. Use the child collection to change the tree: ```rust,ignore root.children().remove(&card); root.children().remove_all(); ``` ## Size and position visuals `set_size` uses width and height. `set_offset` uses x, y, and z: ```rust,ignore visual.set_size(200.0, 120.0); visual.set_offset(24.0, 48.0, 0.0); ``` Composition does not lay out a scene like WinUI. Either update exact sizes when the host changes or make a child track its parent: ```rust,ignore background.set_relative_size_adjustment(Vector2::new(1.0, 1.0)); ``` A relative size of `(1.0, 1.0)` fills the parent. Relative adjustments can be combined with an exact size or offset, which is useful for margins: ```rust,ignore panel.set_relative_size_adjustment(Vector2::new(1.0, 1.0)); panel.set_size(-32.0, -32.0); panel.set_offset(16.0, 16.0, 0.0); ``` Coordinates are device-independent pixels. The host is still responsible for reporting its own size changes when exact dimensions are used. ## Animate a property Animations are retained objects too. Create an animation, add key frames, and start it on a visual: ```rust,ignore use std::time::Duration; let pulse = compositor.create_vector3_key_frame_animation(); pulse.insert_key_frame(0.0, Vector3::new(1.0, 1.0, 1.0)); pulse.insert_key_frame(0.5, Vector3::new(1.2, 1.2, 1.0)); pulse.insert_key_frame(1.0, Vector3::new(1.0, 1.0, 1.0)); pulse.set_duration(Duration::from_millis(800)); pulse.set_iterate_forever(); card.start_animation("Scale", &pulse); ``` Windows advances the animation without an application frame loop. Use `ScalarKeyFrameAnimation` for one-number properties such as `"Opacity"` and `Vector3KeyFrameAnimation` for properties such as `"Scale"` and `"Offset"`. Property names are exact, case-sensitive Composition strings. Rust cannot catch a misspelling in `"Scale"`. ## Draw retained shapes Use a `ShapeVisual` when the scene needs an ellipse or another vector shape rather than a rectangular sprite: ```rust,ignore let visual = compositor.create_shape_visual(); visual.set_size(200.0, 200.0); let geometry = compositor.create_ellipse_geometry(); geometry.set_radius(Vector2::new(80.0, 80.0)); let circle = compositor.create_sprite_shape(&geometry); circle.set_offset(Vector2::new(100.0, 100.0)); circle.set_fill_brush(&compositor.create_color_brush(CompositionColor::rgb(0, 120, 215))); visual.shapes().append(&circle); root.children().insert_at_top(&visual); ``` Shapes remain editable after they are attached. Change the geometry, brush, or visual properties instead of rebuilding the scene for every update. ## Put Composition inside Reactor With the `reactor` feature, a Reactor `Grid` provides the host. The flow is: 1. Attach an `ElementRef` to the grid. 2. Observe the composition host from `use_effect`. 3. On `CompositionHostEvent::Ready`, adopt the supplied compositor with `Compositor::from_host`. 4. Build a visual tree and attach it with `request_set_child_visual`. 5. Update its size on `Ready` and `Metrics` events. The important bridge calls look like this: ```rust,ignore let compositor = Compositor::from_host(compositor)?; let root = compositor.create_sprite_visual(); root.set_relative_size_adjustment(Vector2::new(1.0, 1.0)); root.set_brush(&compositor.create_color_brush(CompositionColor::rgb(30, 30, 46))); let _ = host.request_set_child_visual(Some(root.host_visual()), |result| { if let Err(error) = result { eprintln!("failed to attach composition visual: {error:?}"); } }); ``` The observation must live until the effect is cleaned up. The [`host`](../../crates/samples/composition/host) sample contains the complete component lifecycle; start there rather than copying only the bridge calls. ## What to read next | Sample | What it shows | | --- | --- | | [`circles`](../../crates/samples/composition/circles) | A larger shape scene | | [`minesweeper`][composition-minesweeper] | Input, layout, shapes, and animation | [composition-minesweeper]: ../../crates/samples/composition/minesweeper Browse [`crates/samples/composition`](../../crates/samples/composition) for focused hosting and animation examples. `CompositionScopedBatch::on_completed` returns an event revoker that must remain alive until the tracked work finishes. In a Reactor component, have the callback send a message and update the retained scene from `Component::update`. --- ## Internal documentation The remainder of this page describes how the crate is built and maintained. Applications do not need it to use Composition. ### Dependencies and feature model The crate depends on `windows-core`, `windows-numerics`, `windows-collections`, and `windows-time`, not the umbrella `windows` crate. Visual offsets and sizes reuse `Vector2` and `Vector3`. Shape collections use `IVector`, implicit animation collections use `IMap`, and animation timing uses `TimeSpan`. The `system` feature also depends on `windows-window` and enables dispatcher queue, HWND target, graphics-device, and drawing-surface support. The `reactor` feature selects lifted bindings and exposes host conversions. Compile errors reject zero or two selected stacks. Cargo unifies features across a build graph. Unified CI jobs that build Reactor exclude system-stack consumers, then check those consumers in a separate step. Add new consumers to the matching CI groups. `tool-yml` generates the stack-specific MSRV and feature checks. ### Wrapper model Each safe type is a newtype over one owned COM interface. Concrete visual types dereference through their base hierarchy. `Brush`, `Shape`, and `Animation` are sealed traits that keep private generated binding types out of public signatures. Constructors and immediate recoverable operations return `windows_core::Result`. Retained-object property and factory conveniences fail fast on COM errors. `CompositionColor` wraps the flat `Windows.UI.Color` ABI value. | Module | Contents | | --- | --- | | `compositor.rs` | Factories for graph objects and stack-specific hosts | | `visual.rs` | Visual hierarchy, properties, and child collections | | `brush.rs` | Brush hierarchy and implementations | | `shape.rs` | Shape visuals, geometry, shapes, and collections | | `animation.rs` | Key frames, easing, groups, and implicit animations | | `batch.rs` | Scoped batches and batch kinds | | `surface.rs` | System and lifted graphics devices and drawing surfaces | | `stack.rs`, `target.rs` | System dispatcher queue and HWND hosting | | `color.rs` | Public color value | ### Code generation Composition uses `tool-composition` because it needs system and non-default lifted metadata. The tool first uses `windows-rdl` to generate the lifted native interop metadata from `interop.rdl`, then runs `windows_bindgen` twice with `--flat --minimal --dead-code`. - System bindings read the repository's Windows and Win32 metadata and include `Windows.UI.Composition`, dispatcher queue, desktop interop, and surface interop APIs. - Lifted bindings read the pinned Microsoft UI and Graphics metadata used by Reactor, the repository's Windows and Win32 metadata, and the generated interop metadata. They include `Microsoft.UI.Composition` with shared foundation, color, DirectX, and native interop types. `crates/tools/composition/src/composition.txt` is the shared filter. System-only regions are omitted from lifted generation. Composition, DirectX, and native interop entries are rewritten for the lifted stack. `lib.rs` selects `bindings.rs` or `bindings_lifted.rs`. Generated binding files are committed and must not be edited by hand. After changing the filter, metadata inputs, or tool, run: ```text cargo run -p tool-composition --quiet cargo check -p windows-composition --quiet ``` Run `cargo run -p tool-yml` after changing feature-matrix generation. ### Reactor bridge Reactor reports `CompositionHostEvent` through a typed `ElementRef`. A ready event contains an application-safe compositor capability and layout metrics. `Compositor::from_host` adopts that capability. `Visual::host_visual` exports only an application-owned lifted visual for attachment. Both crates generate lifted bindings from the same pinned Microsoft UI metadata. Host attachment and observation commands exist in Reactor's native and recording runtimes. Window and node identities reject late events and completions. Reactor also consumes lifted key-frame, group, easing, and implicit-animation wrappers for element lifecycle transitions. ### Canvas bridge Each stack exposes matching compositor, graphics-device, and drawing-surface interop interfaces. A Canvas device becomes a `CompositionGraphicsDevice`, which creates a premultiplied BGRA drawing surface. A composition surface brush paints that surface onto a visual. `windows-canvas` implements the drawing half behind its `composition` feature. It borrows the Direct2D context returned by `begin_draw`, applies the backing-atlas offset, and pairs the operation with `end_draw`. ### Testing `test_composition` includes pure value tests and live headless tests. The live tests create a dispatcher queue and real compositor, then exercise visual, brush, shape, collection, and animation wrappers without a window. Getter checks also verify that wrapper methods route to the intended versioned COM interface. Run: ```text cargo test -p test_composition ``` Window hosting is covered by the standalone sample. Reactor host behavior is covered by Reactor's recording tests and live self-test fixtures. --- ### Crates Windows Core (`docs/crates/windows-core.md`) # windows-core > Core COM and WinRT type support shared by the windows-* crates. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-core) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-core) - ๐Ÿš€ [Getting started](../../crates/libs/core/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/core) ## When to use this crate Use `windows-core` directly when you need the common types behind generated Windows bindings, author a COM or WinRT interface in Rust, or work with COM identity, apartments, factories, or references. It provides `IUnknown`, `IInspectable`, `Interface`, `GUID`, `RuntimeType`, and the support used by generated projections. Most code should start with a focused windows-* crate instead. Those crates already depend on and re-export the core types they need. Binary applications may use the broad [`windows`](windows.md) projection. Add a direct `windows-core` dependency when your own public API names these types or when no higher-level crate owns the operation. ## Getting started The crate [README](../../crates/libs/core/readme.md) has the dependency declaration and a minimal example using strings and results. For a first COM or WinRT workflow: 1. Select or generate bindings for the Windows API you want to call. 2. Initialize the calling thread's COM apartment when the API requires it. 3. Keep projected interface values as owned Rust values and propagate `windows_core::Result`. 4. Use `Interface::cast` when you need another interface implemented by the same object. For apartment-agnostic command-line code, `init_mta` initializes an uninitialized calling thread as MTA and keeps the process MTA alive: ```rust use windows_core::Result; fn main() -> Result<()> { windows_core::init_mta()?; // Create and use projected COM or WinRT objects here. Ok(()) } ``` If a UI framework or host initializes COM for you, follow its apartment model instead. `init_mta` does not change a thread that is already initialized in another apartment. For a standalone UI thread, `init_sta` initializes COM as a single-threaded apartment. Keep the returned value alive until after the apartment's COM interface values are dropped: ```rust use windows_core::Result; fn main() -> Result<()> { let _apartment = windows_core::init_sta()?; // Create and use apartment-bound COM objects here. Ok(()) } ``` ## Core API model | API | Role | | --- | --- | | `IUnknown` | Owning pointer to the base COM interface | | `IInspectable` | Base interface for WinRT objects | | `Interface` | Interface identity, vtable access, casts, and raw-pointer interop | | `GUID` | Interface IDs and other Windows GUID values | | `create_instance` | Activates an in-process COM class as a requested interface | | `init_mta`, `init_sta` | Initializes COM using the required apartment model | | `StaApartment` | Keeps an STA initialized on its owning thread | | `Result`, `Error`, `HRESULT` | Re-exported Windows error model | | `HSTRING`, `PCWSTR`, `PCSTR` | Re-exported Windows string model | | `AgileReference` | Reference that resolves an apartment-valid proxy | | `Weak` | Non-owning reference that can be upgraded while the object is alive | | `EventRevoker` | Event registration that unregisters when dropped | | `#[interface]`, `#[implement]` | Declare an interface and implement it with a Rust type | Projected interface values are reference-counted owners. Cloning one performs the corresponding COM reference-count operation, dropping it releases the reference, and `cast` performs `QueryInterface`. Prefer these operations over manual `AddRef`, `Release`, or pointer casts. `create_instance::(&class_id)` wraps the common non-aggregated `CoCreateInstance(..., CLSCTX_INPROC_SERVER, ...)` call. The caller remains responsible for COM apartment initialization and for choosing a class that supports the calling apartment. ## Common tasks ### Moving between interfaces Use `cast` to request another interface from the same COM identity: ```rust use windows_core::{Interface, IInspectable, IUnknown, Result}; fn as_inspectable(value: &IUnknown) -> Result { value.cast() } ``` A failed query is returned as an `Error`. A Rust type conversion is not a replacement for `QueryInterface` unless the generated API provides that conversion. ### Sharing an apartment-bound object Do not assume that every interface can be sent to another apartment. Create an `AgileReference`, move or clone that reference, and call `resolve` in the apartment where the object will be used: ```rust use windows_core::{AgileReference, Interface, Result}; fn make_agile(value: &T) -> Result> { AgileReference::new(value) } ``` `Weak` serves a different purpose: it avoids keeping an object alive and returns `None` from `upgrade` after the object has been destroyed. ### Declaring and implementing an interface The default `proc-macros` feature re-exports `#[interface]` and `#[implement]`: ```rust use windows_core::*; #[interface("7e75ffe0-2f8c-4040-953e-b1f83a48f77b")] unsafe trait IValue: IUnknown { unsafe fn value(&self) -> i32; } #[implement(IValue)] struct Value { value: i32, } impl IValue_Impl for Value_Impl { unsafe fn value(&self) -> i32 { self.value } } fn main() -> Result<()> { let object: IValue = Value { value: 42 }.into(); assert_eq!(unsafe { object.value() }, 42); let unknown: IUnknown = object.cast()?; let object: IValue = unknown.cast()?; assert_eq!(unsafe { object.value() }, 42); Ok(()) } ``` `#[interface]` generates the vtable, caller wrappers, and implementation trait. `#[implement]` generates the wrapper that owns the vtables and reference count. The implementation methods remain responsible for the interface contract and any safety requirements in the ABI. ## Important choices and pitfalls - The default features are `std` and `proc-macros`. Disable `proc-macros` when avoiding the `syn`, `quote`, and `proc-macro2` build dependencies matters; the narrower `interface_decl!` and `implement_decl!` macros remain available. - Raw interface pointers do not carry an owning lifetime. Use `from_raw`, `from_raw_borrowed`, `into_raw`, and related `Interface` operations only when the ownership contract is known. - COM apartment initialization is per thread. Initializing one thread does not initialize worker threads. - `EventRevoker` unregisters on drop. Keep it alive for as long as the handler should run; use `into_token` only when another owner will remove the registration. - The `imp` module supports generated code and crate internals. Application code should prefer the public projected types and traits. ## Samples and next steps There is no standalone `windows-core` sample group. The [`windows` samples](../../crates/samples/windows) show `Result`, `init_mta`, strings, and projected interfaces in complete API calls. The [`robot` sample](../../crates/samples/robot) shows a Rust component implementing generated COM and WinRT interfaces for multiple clients. Continue with [`windows-result`](windows-result.md) for error propagation and [`windows-strings`](windows-strings.md) for ABI string choices. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-core`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/core.txt`. The hand-written modules (`agile_reference`, `com_object`, `compose`, `event`) provide the COM runtime support. The `#[implement]`/`#[interface]` proc macros are re-exported from the [`windows-implement`](windows-implement.md)/[`windows-interface`](windows-interface.md) crates behind the `proc-macros` feature, and the `implement_macro`/`interface_macro` modules supply the `implement_decl!`/`interface_decl!` declarative equivalents used when that feature is off. ### Testing Run `cargo test -p windows-core`; see also the workspace test crates. --- ### Crates Windows Default (`docs/crates/windows-default.md`) # windows-default > The default Windows metadata used by the build-time crates. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-default) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-default) - ๐Ÿš€ [Getting started](../../crates/libs/default/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/default) `windows-default` embeds the canonical Windows Runtime and Windows API metadata as byte slices. Build tools use `WINRT` and `WIN32` when they need the standard metadata without locating separate `.winmd` files. Applications should use a focused crate, `windows-bindgen`, or, for binaries that want a broad pre-generated surface, [`windows`](windows.md) or [`windows-sys`](windows-sys.md). Most code generators should use `input_default` or `reference_default` on the builder they already use. Use `windows-default` directly only when implementing a metadata tool that accepts in-memory winmd bytes. The crate exposes two static byte slices: | Static | Embedded file | Contents | | --- | --- | --- | | `WINRT` | `Windows.winmd` | Windows Runtime contracts | | `WIN32` | `Windows.Win32.winmd` | Windows SDK and WDK APIs | Both files are included in the published crate and embedded with `include_bytes!`. The crate does not extract files or perform I/O. ## First workflow: add standard metadata to a custom index 1. Construct `windows_metadata::reader::File` values from `WINRT` and `WIN32`. 2. Add component-specific winmd files. 3. Build one `windows_metadata::reader::Index` over the combined files. 4. Query or transform the index without locating an SDK installation. `tool-reactor-metadata` uses this pattern when its metadata resolver combines WinUI winmds with the standard definitions. If you are compiling RDL or generating Rust, use the neighboring builder methods instead; they already perform the byte-to-file conversion. ## Integration The build crates depend on `windows-default` and expose the metadata through their own builders. Callers therefore do not need a separate dependency or a path into the Windows SDK. | Crate | Default behavior | | --- | --- | | [`windows-bindgen`](windows-bindgen.md) | Implicit with no input; explicit with `input_default`. | | [`windows-rdl`](windows-rdl.md) | `reference_default` or writer `input_default`. | | [`windows-clang`](windows-clang.md) | `reference_default` and WinRT-only `resolution_default`. | | [`windows-metadata`](windows-metadata.md) | Construct `reader::File` values from the slices. | The `windows-bindgen` textual adapter accepts `--in default`. The bindgen, RDL, and Clang builders use explicit default methods instead; their path-style input methods treat `"default"` as an ordinary path. Byte-input APIs remain available for custom metadata that is already in memory. Programs that link one of these build crates include both metadata payloads in the binary. These crates are intended for build tools rather than runtime dependencies. ## Pitfalls - `WIN32` is one flat `Windows.Win32` metadata set. Published `windows` and `windows-sys` feature namespaces are created later by `tool-package`. - Adding any explicit bindgen input disables the implicit default input. Call `input_default` when the custom metadata references standard types. - `reference_default` and `resolution_default` are not synonyms in `windows-clang`. The former can suppress already-defined declarations; the latter only classifies WinRT ABI projections. - Linking this crate embeds both payloads even if the tool reads only one static. - The bytes are build inputs. They do not provide Windows DLLs or make an API available on the running operating system. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-default`**. ### How it's built The crate has no dependencies. `src/lib.rs` exposes each committed `.winmd` through `include_bytes!`. | File | Generator | Reviewable source | | --- | --- | --- | | `Windows.winmd` | `cargo run -p tool-winrt` | `metadata/winrt` | | `Windows.Win32.winmd` | `cargo run -p tool-win32` | `metadata/win32` and `metadata/wdk` | `tool-winrt` merges the Windows SDK contract metadata, writes canonical RDL, and compiles that RDL back to `Windows.winmd`. `tool-win32` scrapes the Windows SDK and WDK headers for X64, Arm64, and X86, merges the architecture-specific RDL, and writes `Windows.Win32.winmd`. For missing SDK coverage, add the declaring header to `tool-win32`'s header list and check that its exports have an import library in the existing list. Regenerate the metadata with `tool-win32`, then run `tool-package` and `tool-features` to update the published bindings and feature index. Do not hand-edit the generated RDL or metadata. See [Dependencies](../dependencies.md#windows-sdk-wdk-and-winrt-contracts) for the package versions and provenance. ### Packaging The repository `.gitignore` normally excludes `.winmd` files, with an exception for this crate's two committed payloads. Cargo packages tracked files by default, so `Cargo.toml` does not need a separate `include` list. `cargo package -p windows-default` must contain both `.winmd` files. ### Testing The metadata is exercised through its consumers: - `test_bindgen`, `test_rdl`, and the `windows-clang` integration tests cover default and byte inputs. - `tool-winrt`, `tool-win32`, and `tool-roundtrip` verify deterministic metadata generation. - The `tool-yml` generated workflows build and document `windows-default` like the other library crates. After changing the payloads or their generators, run the owning generator and confirm that the other generators remain output-neutral. --- ### Crates Windows Future (`docs/crates/windows-future.md`) # windows-future > Stock async types for Windows APIs. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-future) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-future) - ๐Ÿš€ [Getting started](../../crates/libs/future/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/future) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/future) `windows-future` provides `IAsyncOperation` and the related WinRT async interfaces, with conveniences for producing and consuming them from Rust. ## When to use Use this crate when an API returns one of the four WinRT async interfaces, or when your own WinRT API must return one: - `IAsyncAction` - `IAsyncOperation` - `IAsyncActionWithProgress

` - `IAsyncOperationWithProgress` Use an async runtime's native task type for Rust-only work that does not cross a WinRT boundary. `windows-future` adapts WinRT operations to Rust futures; it is not an async executor. ## Getting started The [crate README](../../crates/libs/future/readme.md) has the dependency declaration and a minimal `ready`/`spawn` example. A typical first workflow is to receive an `IAsyncOperation` from a Windows API, choose how the surrounding code should wait for it, and propagate its `windows_core::Result`: ```rust,ignore async fn consume(operation: windows_future::IAsyncOperation) -> windows_core::Result { let value = operation.await?; Ok(value + 1) } ``` The operation begins according to the WinRT API's rules; converting it into a future does not create or schedule the operation. ## Consuming an operation Choose one completion style and let it own the operation's completion handler: | Style | Use it when | | --- | --- | | `.await` | The caller is already async and the default `std` feature is enabled. | | `join()` | Synchronous code may block the current thread until completion. | | `when(callback)` | Completion should invoke a `Send + 'static` callback without blocking. | All three paths return or receive a `Result`, including failures reported by the WinRT operation. Avoid `join()` on a UI thread or another thread that must continue pumping work. ## Producing an operation `ready` wraps a result that is already available. `spawn` runs a `Send + 'static` closure on the Windows thread pool and exposes its result as a WinRT async object. Pick `IAsyncAction` for `()` and `IAsyncOperation` for a value. The progress variants provide the corresponding interface shape, but closures passed to `spawn` do not report intermediate progress. The `std` feature is enabled by default and supplies `ready`, `spawn`, and the `IntoFuture` implementation used by `.await`. Without it, the interface types and the `join`/`when` consumption helpers remain available. ## Platform constraints and pitfalls - The crate targets Windows and WinRT async interfaces. - A WinRT completion handler can be assigned only once. These helpers may assign that handler while an operation is running, so do not combine them or a direct `SetCompleted` call on one operation. - `spawn` is for blocking or synchronous work that is safe on a pool thread. It does not make thread-affine UI or COM work safe to move off its owning thread. - `ready` and `spawn` expose `Cancel` and `Close` through `IAsyncInfo`, but these constructors do not interrupt the supplied closure. ## Sample and next steps The [`spawn` sample](../../crates/samples/future/spawn) contrasts an immediately ready operation with work submitted to the Windows thread pool. Next, inspect the API that produces your operation to determine its result type, error behavior, cancellation support, and any thread affinity. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-future`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/future.txt` and `future_impl.txt`; the `Future` bridge is hand-written. ### Testing Run `cargo test -p windows-future`; see also the workspace test crates. --- ### Crates Windows Implement (`docs/crates/windows-implement.md`) # windows-implement > The procedural macro that exposes a Rust type through COM or WinRT interfaces. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-implement) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-implement) - ๐Ÿš€ [Getting started](../../crates/libs/implement/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/implement) `windows-implement` provides `#[implement]`. The macro builds the vtables, identity object, reference count, `QueryInterface` routing, and conversions needed to expose a Rust struct through one or more generated interfaces. ## Intended audience Use this macro when Rust is the implementation side of COM or WinRT: a component, callback, activation factory, shell extension, test object, or another object passed to an API as an interface. Calling an existing interface does not require `#[implement]`. Application and component code normally imports `windows_core::implement`. The separate `windows-implement` dependency is an implementation detail of `windows-core`'s default `proc-macros` feature. Its generated code also depends on `windows-core`, so direct consumption offers no standalone runtime. Interfaces usually come from a focused crate or custom [`windows-bindgen`](windows-bindgen.md) output. A binary application may instead use the broad [`windows`](windows.md) projection. Pair this macro with [`#[interface]`](windows-interface.md) only for a manually owned or missing interface definition. See [`windows-core`](windows-core.md) for a compact end-to-end example. ## Implementation model For `#[implement(IValue)] struct Value`, the interface declaration or generated bindings provide an `IValue_Impl` trait. The macro creates a `Value_Impl` wrapper. Implement the generated trait for that wrapper, then convert the original `Value` into an interface type. For an inherited interface, implement the `*_Impl` traits required by the interface and its parent chain. List each independently exposed interface in `#[implement(...)]`; do not list a base merely to compensate for a missing parent relationship in the interface definition. The resulting interface value owns a COM reference. Cloning an interface increments the reference count, dropping it decrements the count, and `cast` uses `QueryInterface`. The original Rust value is dropped when the final COM reference is released. Implementation methods use the projected signatures generated for the interface. Return `windows_core::Result` when offered by that trait, and return a precise `HRESULT` when the trait uses raw status values. The generated thunk translates `Result` errors at the ABI boundary. ## Threading and agility Implementations are agile by default. The macro exposes `IAgileObject` and an agile marshaler unless the attribute includes `Agile = false`. This is a COM promise, not a convenience flag. Before accepting the default, verify that: - method calls may arrive from the apartments and threads allowed by the interface contract; - shared mutable state is synchronized correctly; - borrowed thread-affine resources never escape their owning apartment; - destruction is valid on the thread that releases the final reference. Use `Agile = false` for an apartment-affine object. Add an interface such as `IAgileObject` explicitly only when the object implements that contract itself. For WinRT implementations, `TrustLevel = Partial` or `TrustLevel = Full` controls the value reported by `IInspectable::GetTrustLevel`; omit it unless the component's contract requires a nondefault trust level. ## Errors, panics, and pointers Treat every generated implementation method as an FFI boundary: - Validate raw pointers before dereferencing them when the ABI permits validation. - Initialize required out parameters on every success path and on failure paths required by the interface contract. - Convert expected failures into `Error`, `Result`, or the documented HRESULT. - Do not let a panic cross the generated external function. Remove panic paths from boundary code or catch them at a layer that can map them to a defined failure. - Keep interface references alive for as long as stored raw pointers derived from them are used. `Error::new` or `Error::from_hresult` preserves an HRESULT for projected `Result` methods. Use the error code specified by the interface contract; an arbitrary failure code makes native callers hard to diagnose. Reference-counted interface fields can form cycles. COM reference counting does not collect them. Use weak references where the interface model supports them or define an explicit teardown path. ## Practical component workflow 1. Generate or declare the interfaces and inspect their `*_Impl` traits. 2. Design a Rust state type with explicit synchronization and apartment assumptions. 3. Add `#[implement]` with only the interfaces the object must expose. 4. Implement every required `*_Impl` trait on the generated wrapper. 5. Convert the value to the narrowest interface returned to the caller. 6. Test `cast` for each supported and unsupported interface, not just direct method calls. 7. Test failure HRESULTs, out-parameter initialization, final release, and any cross-thread use promised by agility. For static factories and exported components, the repository's robot component sample shows `StaticComObject`, activation factory output, `OutRef`, and generated implementation traits. The implementation test crates contain smaller examples for identity, inheritance, generic WinRT interfaces, agility, and error propagation. ### Pitfalls - Implementing the Rust trait does not make an incorrect interface declaration ABI-safe. - Interior mutability without synchronization can violate the default agile contract. - Returning an interface to native code transfers a reference-counted ownership interest; avoid temporary raw pointers that outlive their owner. - `cast` success is governed by the interface list and inheritance graph generated into `QueryInterface`. - Generic constraints from the annotated struct are carried into the generated wrapper. Keep them compatible with every generated `*_Impl` trait. When procedural macros are disabled, `windows-core::implement_decl!` covers the common always-agile case with a more explicit and narrower declarative syntax. Use its module documentation as the grammar reference. --- ## Internal documentation `windows-implement` is a `syn`/`quote` procedural macro crate. `src/lib.rs` parses the annotated struct, interface list, generics, `Agile`, and `TrustLevel` options. `src/gen.rs` emits the wrapper, vtable chains, identity and reference-counting implementation, interface conversions, and `QueryInterface` routing. The crate depends on the `*_Impl` traits and vtable constructors emitted by `windows-interface` or `windows-bindgen`. Generated paths target `::windows_core`; the proc macro crate is separated only to satisfy Rust's procedural macro packaging model. Run `cargo test -p windows-implement`; the `test_implement` and `test_implement_core` crates cover the runtime contract more broadly. --- ### Crates Windows Interface (`docs/crates/windows-interface.md`) # windows-interface > The procedural macro that turns a Rust trait declaration into a COM interface. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-interface) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-interface) - ๐Ÿš€ [Getting started](../../crates/libs/interface/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/interface) `windows-interface` provides the `#[interface]` attribute used to declare a COM interface that can be called or implemented from Rust. ## Intended audience Prefer interfaces from a focused crate or generated with [`windows-bindgen`](windows-bindgen.md). Binary applications may also use interfaces from the broad [`windows`](windows.md) projection. Declare an interface manually only when the ABI is owned by the project, the interface is missing from metadata, or a focused interoperability test needs an independent declaration. The macro is normally consumed as `windows_core::interface`, not by depending on this crate directly. `windows-core` re-exports it through its default `proc-macros` feature and supplies every runtime type referenced by the generated code. The separate crate exists because procedural macros must be compiled as a `proc-macro` crate. See [`windows-core`](windows-core.md) for the paired declaration and implementation example. Use the lower-level `interface_decl!` macro from `windows-core` only when the procedural macro feature is disabled and its narrower grammar is sufficient. ## Designing a declaration An interface declaration records an ABI, not an ordinary Rust trait design. Verify these items before writing it: 1. Use the interface's exact IID. Reusing or mistyping an IID can make `QueryInterface` return an object with an incompatible vtable. 2. Name the direct base interface after `:`. Use `IUnknown` for a base COM interface. 3. Preserve method order, including every inherited method represented by the parent. 4. Match parameter types, pointer constness, return types, and Windows integer widths exactly. 5. Mark the trait `unsafe`; callers and implementors must uphold the ABI contract. The accepted trait form is intentionally restricted. Methods take `&self`; async methods, generics, explicit ABI declarations, variadics, default bodies, and non-documentation attributes are rejected. One parent path describes the vtable inheritance chain. For COM methods that return only an HRESULT status, `Result<()>` provides a projected caller and implementor shape while the vtable entry returns `HRESULT`. An explicit `HRESULT` return preserves the raw status. Do not replace an ABI out parameter with `Result` by analogy: declare the parameter shape expected by the macro and ABI. `Ref` and `OutRef` are supported for interface input and output parameters and project to the corresponding `Param` and `OutParam` caller forms. ## What the macro generates For an interface named `IValue`, `#[interface]` generates: - the transparent `IValue` interface wrapper; - an `Interface` implementation containing the IID and vtable type; - `Deref` to the declared parent interface; - caller methods that dispatch through the vtable; - the `IValue_Vtbl` layout; - the `IValue_Impl` trait used by `#[implement]`; - conversions and `QueryInterface` support needed by `windows-core`. Caller methods remain `unsafe` because the declaration cannot prove pointer validity or API-specific invariants. The wrapper handles COM identity and reference counting through `windows-core`; it does not validate a hand-written ABI. ## Practical workflow and pitfalls Keep a manual interface declaration next to a citation or checked-in definition of its ABI. Add a test that exercises both a known implementation and `QueryInterface` through the expected IID when possible. Common failures are severe: - A wrong method order or signature dispatches through the wrong machine-level contract. - A wrong parent produces an invalid inherited vtable layout. - A correct IID paired with an incorrect layout can corrupt memory. - Rust references in an ABI are valid only when their representation and lifetime are part of the agreed Rust-to-Rust contract. Public COM ABIs normally use Windows ABI types and pointers. - `Result<()>` translates an error into HRESULT at the boundary; panics are not COM errors and must not unwind across an external call. Prefer generating the declaration from `.winmd` with `windows-bindgen` when metadata can describe the interface. That keeps caller and implementation projections aligned and avoids maintaining a vtable by hand. --- ## Internal documentation `windows-interface` is a `syn`/`quote` procedural macro crate. `src/lib.rs` parses the restricted trait and GUID. `src/generation.rs` emits the interface wrapper, vtable, implementation trait, inheritance traversal, and `Ref`/`OutRef` parameter adapters. `src/guid.rs` parses the IID. The generated paths are rooted at `::windows_core`, which is why direct use still requires a compatible `windows-core` dependency. The implementation macro consumes the generated `*_Impl` traits and vtable constructors; changes to either macro must preserve that contract. Run `cargo test -p windows-interface`; the `test_interface` and implementation test crates cover cross-crate behavior. --- ### Crates Windows Link (`docs/crates/windows-link.md`) # windows-link > A macro for declaring Windows DLL imports without an import library. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-link) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-link) - ๐Ÿš€ [Getting started](../../crates/libs/link/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/link) `windows-link` provides the `link!` macro. It emits a raw external function declaration using Rust's `raw-dylib` linking mode and a function-pointer type alias with the same name. ## Intended audience This crate is for binding generators and authors of narrow low-level bindings. The generated `windows` and `windows-sys` crates already declare and link the Windows APIs they expose, so application code should not redeclare those functions. Use `windows-link` directly when: - an exported Windows function is absent from the available metadata; - a project owns a small reviewed raw binding; - generated `--sys` bindings use `link!` as their runtime link mechanism; - the function-pointer type emitted beside the declaration is useful to an abstraction. Use [`windows-bindgen`](windows-bindgen.md) when several metadata-backed declarations are needed. A binary application may use [`windows`](windows.md) or [`windows-sys`](windows-sys.md) when the published umbrella crates already contain the API. Reusable libraries should prefer focused crates and narrow generated bindings. Unlike `#[interface]` and `#[implement]`, `link!` is not a procedural macro normally re-exported for application use. Rich generated bindings invoke it through `windows-core`; raw generated bindings depend on `windows-link` directly. Most users therefore encounter this crate as binding infrastructure rather than as an application dependency. ## Declaration contract The README shows the macro grammar and its function-pointer alias. Every token in a declaration is part of the ABI contract: - The library literal must name the DLL that exports the symbol on supported Windows versions. - The ABI literal must match the export, commonly `"system"` for Windows APIs. - The optional link-name literal maps the Rust identifier to a differently named export. - Parameter and return types must match the export exactly, including pointer constness and integer width. - The declaration is unsafe even when a particular function happens to accept only integers. On x86 Windows, the macro requests undecorated import names. On other Windows architectures it uses a verbatim raw-dylib import. Do not add architecture-specific spelling to compensate without checking the actual exported symbol and Rust's ABI behavior. The type alias has the same identifier as the function because Rust has separate value and type namespaces. This permits code such as `let callback: GetTickCount = GetTickCount;`. The alias is an `unsafe extern` function pointer and carries the same caller obligations as the direct declaration. ## Practical workflow Before adding a declaration: 1. Search the `windows` and `windows-sys` API reference for the symbol. 2. Confirm the DLL, export name, calling convention, and exact signature from an authoritative Windows definition. 3. Decide which Windows versions and architectures the surrounding crate supports. 4. Put the declaration in a private FFI module. 5. Add a safe wrapper only if its preconditions, ownership, result convention, and cleanup can be expressed correctly. 6. Test on each supported architecture when decoration, variadics, or unusual ABI types are involved. `link!` only arranges static import resolution. It is not delayed loading and does not make an optional export safe to call on older systems. For optional APIs, resolve the symbol dynamically and keep the module loaded for at least as long as the function pointer can be called. ### Pitfalls - A successful link does not prove the Rust signature is ABI-compatible. - DLL forwarding and API-set names are Windows implementation details; use the library contract documented for the API. - The macro does not generate feature gates. Add the surrounding `cfg` and Cargo feature policy in the binding crate. - A declaration produced on a non-Windows target does not make the Windows export available there. - Variadic and uncommon calling conventions have Rust and architecture restrictions. Prefer metadata-backed `windows-sys` output when it supports the declaration. - Do not duplicate a symbol declaration with a different signature in the same program. --- ## Internal documentation The crate is hand-written and `no_std`. `src/lib.rs` contains the three `link!` expansions: x86 Windows, other Windows architectures, and non-Windows parsing support. The Windows expansions use `kind = "raw-dylib"` and `+verbatim`; x86 also sets `import_name_type = "undecorated"`. `windows-bindgen` emits this macro for sys-style bindings unless `--extern` is selected. `windows-core` re-exports the macro for rich and minimal generated bindings, while `windows-sys` calls it through its direct dependency. Run `cargo test -p windows-link`; generated binding tests exercise its wider use. --- ### Crates Windows Metadata (`docs/crates/windows-metadata.md`) # windows-metadata > A low-level reader and writer for the ECMA-335 metadata format. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-metadata) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-metadata) - ๐Ÿš€ [Getting started](../../crates/libs/metadata/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/metadata) `windows-metadata` reads and writes the ECMA-335 metadata format used by .NET, WinRT, and the Win32 metadata. It is the foundation [`windows-bindgen`](windows-bindgen.md) builds on. The `reader::Index` type loads one or more `.winmd` files and lets you query namespaces, type definitions, and their members. Applications should start with a focused crate or `windows-bindgen`; binary applications may use [`windows`](windows.md) or [`windows-sys`](windows-sys.md) when they want a broad pre-generated surface. Use `windows-metadata` directly when writing a metadata inspector, generator, merger, or namespace transformation. The API exposes metadata facts; it does not project them into a safe Rust API. Start with the crate [README](../../crates/libs/metadata/readme.md) for dependency setup and a focused type query. ## First workflow: inspect an API definition 1. Load a file with `reader::Index::read`, or construct `reader::File` values and pass them to `Index::new`. 2. Locate a type with `get` when duplicates are possible or `expect` when exactly one definition is an invariant. 3. Inspect `category`, `extends`, fields, methods, signatures, attributes, and nested types. 4. Keep rows borrowed from the index; use `leak` or `read_static` only when a tool requires process-lifetime rows. For methods, match ECMA-335 parameter rows with `MethodDef::params_by_sequence(signature.types.len())`. Sequence 0 belongs to the return value; nonzero sequences are one-based signature positions. `params()` instead returns physical table order and is appropriate for lossless copying, not semantic parameter association. `tool-reactor-metadata` provides a larger example. Its metadata resolver loads WinUI winmd files, adds `windows-default` byte inputs, indexes classes and interfaces, then uses method signatures and attributes to drive generated UI code. `tool-features` uses `Index::iter_items` to enumerate types, free functions, and constants. ## Input and output model `reader::File` owns one winmd byte stream. `reader::Index` combines files into searchable namespace, type, nested-type, and expanded Win32 `Apis` indexes. A zero architecture selector keeps all rows; `Index::new_for_architecture` selects neutral rows plus one of X86 (1), X64 (2), or Arm64 (4). The writer API is lower-level. `writer::File` builds ECMA-335 rows and `into_stream` returns the finished bytes. Prefer [`windows-rdl`](windows-rdl.md) when a reviewable source format is useful; use the writer directly when a tool is copying or synthesizing table rows. ## Common tool tasks | Task | API | | --- | --- | | Read one winmd | `reader::File::read` or `reader::Index::read` | | Read bytes already in memory | `reader::File::new` | | Query several files together | `reader::Index::new` | | Select one architecture | `reader::Index::new_for_architecture` | | Merge ordinary winmds | `merge().input(...).output(...).merge()` | | Merge per-architecture winmds | `merge().arch_input(path, bits)` | | Union compatible duplicate enums | `Merger::union_enums` | | Remap flat namespaces | `remap().source(...).routes(...).fallback(...)` | | Author metadata tables | `writer::File` | The merger accepts files or directories. Architecture merge retains one neutral definition only when the same shape is present on every merged architecture; divergent shapes are tagged and kept. The remapper rewrites definitions and references together and splits Win32 `Apis` members across their routed target namespaces. ## Integration and pitfalls - [`windows-default`](windows-default.md) supplies the standard WinRT and Win32 files as byte slices. Construct `reader::File` values from those bytes when a custom tool needs them. - [`windows-rdl`](windows-rdl.md) provides a higher-level text authoring and decompilation path. - [`windows-bindgen`](windows-bindgen.md) applies Rust projection policy to these raw metadata facts. - A metadata parameter marked neither In nor Out is `ParamDirection::Unspecified`. Do not infer input direction in the metadata layer. - Optional, reserved, retval, and buffer-count annotations are independent facts. Consumers decide how those facts affect their public API. - Duplicate type definitions can be valid in an unfiltered multi-architecture index. Do not call `expect` unless uniqueness is guaranteed. - Preserve physical row order when copying malformed or sparse metadata; use semantic helpers when interpreting it. The focused fixtures in `crates/tests/libs/rdl` and `crates/tests/libs/bindgen` show metadata shapes. The main tool consumers are `tool-winrt`, `tool-win32`, `tool-package`, `tool-features`, and `tool-reactor-metadata`. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-metadata`**. ### How it's built Consumed by `windows-bindgen`. `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/metadata.txt`; the ECMA-335 tables and readers are hand-written. ### Multi-arch merge `windows-metadata`'s `merge` module coalesces the per-architecture winmds that `tool-win32` scrapes (x64, arm64, x86) into a single winmd. A type identical across every arch is emitted once as arch-neutral; a type that diverges is split into per-arch copies, each tagged with a `SupportedArchitectureAttribute` (spelled `#[arch(X86|X64|Arm64)]` in RDL). `reader::Index::new_for_architecture` selects one of those copies while retaining neutral rows. Its bit values match the metadata attribute: 1 for X86, 2 for X64, and 4 for Arm64. Plain `Index::new` keeps every copy for tools that need to inspect or merge the complete metadata. The collapse-or-split decision is structural, driven by `type_sig()` - a hash of everything that can legitimately differ between architectures: - **fields** - name, type, and constant value (so an enum whose members hold different per-arch values splits instead of silently dropping the divergent values); - **method signatures** - Win32 callbacks and WinRT delegates have no fields and diverge *only* in their `Invoke` signature, so a fields-only signature would wrongly collapse arch-divergent callbacks into one untagged copy; - **layout** - `#pragma pack` and `ClassLayout`; - **`AlignmentAttribute`** - `__declspec(align(N))` raised alignment is encoded *only* by that attribute (`ClassLayout` can only *lower* alignment), so a type that differs solely in forced over-alignment must fold the attribute into the signature or the divergent copy is lost; - **flags** - the type's attribute flags. Types present on only a *subset* of arches still go through the same structural split, so a type that is present on x64+arm64 (but not x86) and *diverges* between those two is split per arch rather than collapsing to whichever copy happened to be first. A group is emitted arch-neutral only when its signature spans every arch in the run. Unmanaged callbacks have one narrow semantic reconciliation before that split. If at least one architecture explicitly uses `isize` or `usize` and every other copy uses the same native-sized integer for its architecture (`i32`/`u32` on x86, `i64`/`u64` on x64 or arm64), the callback keeps one native-sized signature. It becomes arch-neutral when present on every merged architecture; otherwise it keeps its subset arch tag. This handles SDK declarations such as `FARPROC`, whose return is spelled `INT_PTR` on 64-bit but legacy `int` on x86. A plain `i32`/`i64` pair does not qualify: the explicit native-sized spelling is required as semantic evidence. The merge is deterministic: it stages through `BTreeMap`s and insertion-ordered `Vec`s, with no `HashMap` reaching the output. The merger and namespace remapper accept strings, `Path`, or `PathBuf` for input and output paths and retain them as `PathBuf`. The remapper provides singular/plural `input`/`inputs`, `source`/`sources`, and `route`/`routes` methods. ### Nested type identity Decoded signature `TypeName` values retain the outermost namespace and a slash-separated name, such as `Test` and `Outer/Child`. `TypeDef::full_name`, `TypeRef::full_name`, and `TypeDefOrRef::full_name` expose that identity; their `name` and `namespace` accessors still return the raw table columns. TypeDef names follow `NestedClass`, while TypeRef names follow enclosing TypeRef scopes. The writer turns the qualified name into an enclosing-TypeRef chain. Merge preserves that chain, and namespace remapping routes its outermost type without changing the nested path. A `NestedClass` row alone does not resolve an unqualified, module-scoped reference to a nested type (ECMA-335 II.7.3 and II.22.38). Nested generic instantiations are outside the writer's supported input. Both signature and TypeSpec emission assert against them rather than derive a nested name's arity from the total generic argument count. Top-level generics and non-generic nested records remain supported. `test_metadata::nested_references` checks physical scope chains, signature decoding through both TypeRef and TypeDef tokens, repeated leaf names under different parents, rejection of nested generic instantiations, merge, and namespace remapping. ### Method parameter association ECMA-335 `Param` rows are not positional. `Param.Sequence == 0` describes the return value, and a nonzero sequence identifies a one-based signature parameter. Rows may be absent, sparse, or stored out of order. `reader::MethodDef::params_by_sequence(parameter_count)` returns a separate optional return row and one `Option` per signature position. It reports duplicate sequences and nonzero sequences outside the signature as `MethodParamSequenceError`; consumers do not choose a first-wins or last-wins interpretation. If several rows are invalid, the first invalid physical row is reported. `MethodDef::params()` still iterates physical table order. The merge and remap writers use that physical iterator on purpose so lossless copying preserves row order, sparse rows, and malformed input for a later validator. `MethodParam::direction()` decodes only the `In` and `Out` bits into `ParamDirection::{Input, Output, InputOutput, Unspecified}`. `is_optional`, `is_reserved`, and `is_retval_attribute` expose their independent metadata facts. These helpers do not inspect pointer mutability, infer a default for an unspecified direction, combine `ReservedAttribute` with `Optional`, or decide whether a parameter should become a language return value. Array and byte-count attributes remain available through `attributes()` because each projection validates different public-surface shapes. ### Determinism and the winmd writer The writer is the foundation of the pipeline's reproducible builds. It stages `Constant` / `Attribute` / `GenericParam` (and the bindgen `TypeTree`) in `BTreeMap`s / `BTreeSet`s, and the module MVID is a fixed zero GUID, so regenerating a winmd is byte-for-byte identical across platforms (CI validates the committed winmds on Linux). Notable invariants in the ECMA-335 tables: - The `HasSemantics` coded index and the `Property`/`Event`/`MethodSemantics` tables are emitted only when non-empty, and `MethodSemantics` rows are sorted by `Association` - strict readers reject an unsorted table. - `write_index` asserts on the run-list one-past-end sentinel rather than silently wrapping to `0` for a target table with exactly 65535 rows (the guard lives on the write side so the reader's width threshold stays ECMA-conformant for external winmds). - `Value::Bool` constants round-trip symmetrically (the reader maps `ELEMENT_TYPE_BOOLEAN`); the CLR element-type vocabulary (`ELEMENT_TYPE_*`) is hand-authored in `src/clr.rs` because its defining header (`corhdr.h`) ships only in the .NET SDK and cannot be scraped. ### Testing Run `cargo test -p windows-metadata`; see also the workspace test crates. The arch-merge collapse/split rules are pinned by `arch_roundtrip.rs` (divergent fields, callbacks, forced alignment, enum constant values, subset-present divergence) and `merge.rs` (native-sized callback reconciliation). `method_params.rs` authors metadata directly with `writer::File` and covers dense, absent, return, sparse, out-of-order, duplicate, and out-of-range parameter rows. It also covers all four raw directions and verifies that optional, reserved, retval, and count attributes remain independent facts. `remap.rs` covers explicit and fallback namespace routing, singular/plural builder methods, missing outputs, and invalid inputs. --- ### Crates Windows Numerics (`docs/crates/windows-numerics.md`) # windows-numerics > Graphics-oriented vector and matrix math from `Windows.Foundation.Numerics`. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-numerics) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-numerics) - ๐Ÿš€ [Getting started](../../crates/libs/numerics/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/numerics) `windows-numerics` provides the POD math value types used by Direct2D, composition, and other graphics APIs: `Vector2`, `Vector3`, `Vector4`, `Matrix3x2`, and `Matrix4x4`. Each is a plain `#[repr(C)]` struct with inherent methods and operator overloads layered on top. ## When to use Use this crate when a Windows graphics or composition API accepts `Windows.Foundation.Numerics` values. The structs have the expected Windows ABI layout, so vectors and matrices can cross those API boundaries without conversion. For a Rust-only math engine, consider a general-purpose math crate if you need quaternions, planes, SIMD-specific operations, or a larger set of transforms. `windows-numerics` focuses on the five value types projected by this crate. ## Getting started The [crate README](../../crates/libs/numerics/readme.md) contains the dependency declaration and minimal vector and matrix examples. A useful first workflow is to calculate with the same types that the target Windows API expects: ```rust use windows_numerics::{Matrix3x2, Vector2}; let position = Vector2::new(20.0, 30.0); let offset = Vector2::new(5.0, -10.0); let translated = position + offset; let transform = Matrix3x2::translation(translated.x, translated.y); assert_eq!((transform.m31, transform.m32), (25.0, 20.0)); ``` Keep values as `f32`; these Windows numeric types do not provide `f64` variants. ## Vectors `Vector2`, `Vector3`, and `Vector4` provide constructors, zero/one and axis vectors, dot products, length and distance operations, and normalization. `Vector3` also provides a cross product. Arithmetic operators work with owned or borrowed vectors; multiplication and division between vectors are component-wise. Scalar multiplication and division use `f32`. Use `length_squared` or `distance_squared` when only a comparison is needed, avoiding a square root. Check for a zero-length vector before calling `normalize`, since normalization divides by the length. ## Matrices and transforms `Matrix3x2` represents 2D affine transforms. It provides identity, translation, scale, rotation, and skew constructors, including variants around a center point. Rotation and skew angles are in degrees. `Matrix4x4` provides 3D translation, Y-axis rotation in degrees, and perspective projection. Matrix multiplication composes transforms; preserve the order expected by the Windows API and test the result with representative points rather than assuming another math library's convention. ## Platform constraints and pitfalls - The types are plain `#[repr(C)]` structs with public fields. Initialize every field when using a struct literal, or prefer the constructors. - Equality is exact floating-point equality. Use an application-appropriate tolerance for computed values. - Normalizing a zero vector and constructing invalid projection inputs can produce non-finite values. - The default `std` feature supplies square root and trigonometric methods used by length, distance, normalization, rotation, and skew. Basic value types and arithmetic remain available without it. ## Samples and next steps The canvas, composition, Direct2D, and DirectComposition samples use these types in real graphics workflows. Start with the [`canvas transform` sample](../../crates/samples/canvas/transform) for a 2D matrix and the [`composition animation` sample](../../crates/samples/composition/animation) for vectors passed to composition APIs. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-numerics`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/numerics.txt`; the inherent methods and operator trait impls are hand-written. ### Testing Run `cargo test -p windows-numerics`; see also the workspace test crates. --- ### Crates Windows Pickers (`docs/crates/windows-pickers.md`) # windows-pickers > File and folder pickers backed by the Windows Common Item Dialog. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-pickers) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-pickers) - ๐Ÿš€ [Getting started](../../crates/libs/pickers/readme.md) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples/pickers) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/pickers) - [Reactor guide](windows-reactor.md) - [Window guide](windows-window.md) ## When to use it Use `windows-pickers` when a Windows desktop application needs the system file-open, folder, or file-save dialog. The crate returns filesystem `PathBuf` values and uses the Windows Shell for navigation, filtering, recent locations, and overwrite confirmation. The crate wraps the common picker workflows rather than every `IFileDialog` extension point. Use raw Windows bindings when an application needs custom dialog controls, dialog events, non-filesystem Shell items, or other advanced Common Item Dialog APIs. ## The basic idea Choose a picker, configure it with consuming builder methods, and show or request it: | Type | Result | | --- | --- | | `OpenFilePicker` | One file, or several files through `show_multiple` | | `FolderPicker` | One folder, or several folders through `show_multiple` | | `SaveFilePicker` | A filesystem path at which to save a file | Showing a picker is synchronous. `IFileDialog::Show` runs a nested modal message loop and returns after the user confirms or cancels the dialog. The crate does not read, create, or modify the selected file. ## Choose how to host the picker The default `system` feature accepts a borrowed `windows_window::Window`: ```toml [dependencies] windows-core = "0.100" windows-pickers = "0.100" windows-window = "0.100" ``` Applications that own an HWND through another windowing library can disable default features and use `show_for_hwnd`: ```toml windows-pickers = { version = "0.100", default-features = false } ``` Enable `reactor` to request a picker from a Reactor component: ```toml windows-pickers = { version = "0.100", default-features = false, features = ["reactor"] } windows-reactor = "0.100" ``` The `system` and `reactor` features are additive. An application may enable both when it uses both host types. ## Pick your first file This complete program initializes COM, creates an owner window, and shows an open-file picker: ```rust,no_run use windows_pickers::{OpenFilePicker, Result}; use windows_window::Window; fn main() -> Result<()> { let _apartment = windows_core::init_sta()?; let window = Window::new("Open a file").create()?; let path = OpenFilePicker::new() .title("Open a Rust source file") .filter_extensions("Rust source", ["rs"]) .filter_all() .show(&window)?; if let Some(path) = path { println!("{}", path.display()); } Ok(()) } ``` The calling UI thread must be a COM single-threaded apartment (STA). An application with an existing UI framework normally uses the apartment initialized by that framework rather than initializing COM again. Keep the owner window alive until `show` returns. ## Pick files and folders `OpenFilePicker::show` and `FolderPicker::show` return one selected path: ```rust,ignore let file = OpenFilePicker::new().show(&window)?; let folder = FolderPicker::new().show(&window)?; ``` Use `show_multiple` when the user may select more than one item: ```rust,ignore let files = OpenFilePicker::new() .title("Attach files") .commit_label("Attach") .filter_all() .show_multiple(&window)?; let folders = FolderPicker::new() .title("Add search folders") .show_multiple(&window)?; ``` `commit_label` changes the confirmation button for a task-specific action such as "Attach", "Import", or "Choose". ## Choose a save path `SaveFilePicker` configures the proposed file name, extension, filters, and overwrite behavior: ```rust,ignore let path = SaveFilePicker::new() .title("Save report") .filter_extensions("Text", ["txt"]) .suggested_name("report") .default_extension("txt") .overwrite_prompt(true) .show(&window)?; ``` `suggested_name` sets the initial name. `default_extension` supplies the extension when the user enters a name without one; a leading period is optional. Configured filters restrict the accepted file types. `overwrite_prompt` explicitly enables or disables replacement confirmation, while leaving it unset preserves the native dialog default. The returned path is only the user's choice. The application remains responsible for opening the file and handling races, permissions, sharing violations, and any final overwrite policy. ## Configure file filters Add extension filters directly to an open or save picker: ```rust,ignore let picker = OpenFilePicker::new() .filter_extensions("Images", ["png", "jpg", "jpeg"]) .filter_extensions("Portable Network Graphics", ["png"]) .filter_all() .initial_filter(0); ``` Extensions may include a leading period. Use `filter_patterns` for native wildcard patterns: ```rust,ignore let picker = OpenFilePicker::new() .filter_patterns("Reports", ["report-*.csv", "summary-*.csv"]) .filter_all(); ``` Each filter must have a nonempty name and at least one nonempty extension or pattern. `initial_filter` uses a zero-based index into the configured filters. An out-of-range index is reported as an error before the dialog opens. ## Set the initial location Each picker provides two path-based and two known-folder methods: | Method | Behavior | | --- | --- | | `default_folder(path)` | Used when the Shell has no remembered location | | `folder(path)` | Forces the initially displayed folder | | `default_location(location)` | Default using a `PickerLocation` | | `location(location)` | Forced location using a `PickerLocation` | `PickerLocation` supports Desktop, Documents, Downloads, Music, Pictures, Videos, Computer, and 3D Objects. When both a default and forced location are configured, the default is applied first and the forced location determines the initial view. Path-based locations must resolve to Shell items. An invalid or unavailable configured path is reported before the dialog opens. ## Preserve Shell state Pass a stable GUID to `client_id` when the Shell should remember state such as the last visited folder: ```rust,ignore let picker = OpenFilePicker::new() .client_id(GUID::from_u128(0x6d81d46c_77da_4874_8ca7_754546ba6803)); ``` Use the same GUID for picker uses that should share history and different GUIDs for independent histories. Without a client ID, the crate does not opt the dialog into this persistence mechanism. ## Handle cancellation and errors Single-selection pickers return `Result>`: | Value | Meaning | | --- | --- | | `Ok(Some(path))` | The user selected a path | | `Ok(None)` | The user cancelled | | `Err(error)` | Configuration, COM, or Shell operation failed | Multiple-selection methods return `Result>`. An empty vector means cancellation because the dialog cannot successfully confirm an empty selection. Only the native `ERROR_CANCELLED` result is translated into cancellation; other failures remain `windows_core::Error` values. ## Use a raw HWND The raw-handle methods work with another Win32 host: ```rust,ignore let path = OpenFilePicker::new().show_for_hwnd(hwnd)?; ``` The pointer must be a valid, non-null owner HWND on the calling UI thread and remain live until the method returns. The calling thread must be a COM single-threaded apartment (STA). The raw methods are available without the `system` feature. ## Request a picker from Reactor Picker methods cannot call `IFileDialog::Show` inline while Reactor is publishing component state. The `reactor` feature adds `request` and `request_multiple`, which stage the modal operation and map its result into a component message: ```rust,ignore enum Message { Open, Picked(windows_pickers::Result>), } fn update(&mut self, message: Message, context: &ComponentContext) { match message { Message::Open => { if !OpenFilePicker::new() .filter_all() .request(context, Message::Picked) { self.status = "Another window operation is pending".to_string(); } } Message::Picked(Ok(Some(path))) => { self.status = path.display().to_string(); } Message::Picked(Ok(None)) => { self.status = "Selection cancelled".to_string(); } Message::Picked(Err(error)) => { self.status = format!("Picker failed: {error}"); } } } ``` A `true` return means Reactor staged the request, not that the picker has already opened. Reactor runs it on the owning window's UI thread after the current publication commits and queues the mapped message for a later component update. It discards the operation if publication fails, the component retires, or the window starts closing. Each Reactor window accepts one pending native window operation at a time. Other Reactor windows remain independent. No additional COM initialization is needed in a Reactor application. The [`reactor/message-box`](../../crates/samples/reactor/message-box) sample uses the same `ComponentContext::run_window` support with another native modal API. ## Samples | Sample | What to study | | --- | --- | | [`standalone`](../../crates/samples/pickers/standalone) | All picker types with `windows-window` | | [`reactor`](../../crates/samples/pickers/reactor) | All picker types through component messages | Run an individual standalone workflow with: ```text cargo run -p pickers-standalone -- open cargo run -p pickers-standalone -- open-multiple cargo run -p pickers-standalone -- folder cargo run -p pickers-standalone -- folder-multiple cargo run -p pickers-standalone -- save ``` Run the Reactor sample with: ```text cargo run -p pickers-reactor ``` --- ## Internal documentation This section is for contributors to `windows-pickers`. `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/pickers.txt`. It contains the minimal Common Item Dialog, Shell item, COM activation, and string-allocation APIs used by the hand-written wrapper. Open and folder pickers create `FileOpenDialog`; the save picker creates `FileSaveDialog`. All preserve the native option defaults while adding `FOS_FORCEFILESYSTEM`. Folder selection adds `FOS_PICKFOLDERS`, multiple selection adds `FOS_ALLOWMULTISELECT`, and save dialogs with filters add `FOS_STRICTFILETYPES`. Shared configuration retains UTF-16 backing storage until `Show` returns. Filesystem locations are converted with `SHCreateItemFromParsingName`, known locations with `SHCreateItemInKnownFolder`, and selected `IShellItem` values with `SIGDN_FILESYSPATH`. Returned strings are copied into `PathBuf` values before `CoTaskMemFree`. Client identity is applied before folder configuration so a forced folder still determines the initial view. Requested option bits are merged with `GetOptions` rather than replacing unrelated native defaults. After changing the binding filter, run: ```text cargo run -p tool-bindings --quiet cargo check -p windows-pickers --quiet ``` Unit tests cover configuration and cancellation translation without opening modal Shell UI. --- ### Crates Windows Rdl (`docs/crates/windows-rdl.md`) # windows-rdl > A parser for RDL (Rust Definition Language) and an ECMA-335 metadata generator. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-rdl) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-rdl) - ๐Ÿš€ [Getting started](../../crates/libs/rdl/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/rdl) `windows-rdl` is the front of the metadata authoring pipeline. It parses RDL (Rust Definition Language), a small Rust-like syntax for Windows APIs. It emits ECMA-335 `.winmd` metadata for [`windows-bindgen`](windows-bindgen.md). It also writes canonical RDL from `.winmd` files. Most applications should use existing bindings rather than author metadata. Use `windows-rdl` when you are defining a custom WinRT or Win32 surface, adapting header output from [`windows-clang`](windows-clang.md), or maintaining reviewable text for a winmd generator. Start with the crate [README](../../crates/libs/rdl/readme.md) for setup and the two basic builder calls. The full language reference is in [`crates/libs/rdl/rdl.md`](../../crates/libs/rdl/rdl.md). ## First workflow: define a custom component surface 1. Create an `.rdl` file with one or more `#[winrt]` or `#[win32]` modules. 2. Add standard metadata as a reference if the declarations mention Windows types. 3. Compile the RDL to a winmd with `reader`. 4. Feed the winmd to [`windows-bindgen`](windows-bindgen.md) or C++/WinRT. 5. Treat the RDL as the reviewed source and regenerate the binary winmd. `crates/samples/robot/component` follows this path. Its build script compiles `src/robot.rdl`, references standard Windows metadata, then asks bindgen for the `Robotics` namespace and WinRT implementation support. `crates/samples/robot/component_cpp` sends the same kind of output to [`cppwinrt`](cppwinrt.md). ## Input and output model | Direction | Builder | Inputs | Output | | --- | --- | --- | --- | | RDL -> winmd | `reader()` | `.rdl` files, directories, or text | One `.winmd` file | | winmd -> RDL | `writer()` | `.winmd` files, directories, or bytes | One file or partition | Reader references resolve names but are not emitted as definitions. Use `reference_default` for the bundled standard metadata, or the path and byte reference methods for custom dependencies. Writer inputs are definitions to render; `input_default` renders the bundled metadata. Writer filters accept namespace prefixes, qualified or unqualified names, and `!` exclusions. `split` writes one file per namespace. `partition` accepts an item-name -> file-stem map and writes one file per defining header. `item_names` reads the names declared under one namespace without compiling the file. ## RDL syntax RDL uses Rust tokens and module syntax, but it describes metadata rather than executable Rust. A top-level `mod` is a metadata namespace. Tag it `#[winrt]` or `#[win32]` to select the type system. Items include classes, interfaces, delegates, callbacks, enums, structs, unions, typedefs, constants, and imported functions. ```text #[win32] mod Example { #[repr(i32)] enum Color { Red = 1, Green = 2, Blue = 3, } struct Point { x: i32, y: i32, } const MAX: u32 = 42; #[library("example.dll")] extern fn GetPoint() -> Point; #[guid(0x00000001_0002_0003_0004_000000000005)] interface ICustom : Windows::Win32::System::Com::IUnknown { fn Method(&self, value: i32) -> i32; } } ``` Most attributes name a metadata attribute type directly. Some attributes use short pseudo-attribute names. The reader expands those names to full metadata attributes. See `PSEUDO_ATTRS` in `windows-rdl`. Struct bit fields use their own syntax. A run of bit fields packed into one backing integer is written as a C-like block on that field. Each member uses `Name: width`. Anonymous padding uses `_: width`. ```text struct D3D11_VIDEO_PROCESSOR_COLOR_SPACE { _bitfield: u32 { Usage: 1, RGB_Range: 1, YCbCr_Matrix: 1, YCbCr_xvYCC: 1, Nominal_Range: 2, Reserved: 26, }, } ``` Member offsets are implicit. Each offset is the total width of earlier members, including padding. The reader writes one `Windows.Win32.Metadata.NativeBitfieldAttribute(name, offset, width)` custom attribute per named member. The writer renders it back to block form. See [`windows-clang`](windows-clang.md#bit-field-member-scraping) for how the scraper emits bit fields. See [`windows-bindgen`](windows-bindgen.md#bit-field-accessors) for the accessors they drive. WinRT types use the `#[winrt]` namespace flavor. They also add runtime-class and property syntax. ```text #[winrt] mod Robotics { #[Activatable(1)] class Robot { IRobot, } #[ExclusiveTo(Robot)] interface IRobot { fn Speak(&self, message: String); Name: String; } } ``` The `crates/tests/libs/rdl/input` directory has focused `.rdl` files for syntax examples. It covers structs, flags, delegates, generic interfaces, unions, and more. ## Common tasks and neighboring crates The complete source-to-binding path is: ```text C/C++ headers -- clang() --> .rdl -- reader() --> .winmd -- bindgen() --> bindings.rs (windows-clang) (windows-rdl) (windows-bindgen) ``` - Skip RDL when a suitable winmd already exists. - Use `windows-clang` to create RDL from headers; `tool-webview` demonstrates the full path. - Use `windows-metadata` for table-level inspection, merge, and namespace remapping. - Use `writer().split()` to maintain namespace-partitioned reviewable metadata. - Use `merge_arch_rdl` only for generators that have per-architecture RDL directories and winmds. It merges structural differences and restores the defining-header partition. - `tool-reactor-metadata` compiles hand-authored `extras.rdl` to fill metadata gaps before binding WinUI. ## Pitfalls - RDL references must be supplied separately; naming an external type does not locate its winmd. - The reader rejects unsupported types, constants, callback ABIs, variadic callback parameters, and function ABIs instead of dropping them. - Pointer chains have one constness bit plus depth. Uniform `*mut *mut T` and `*const *const T` chains work; mixed chains do not. - `len_param` and `size_param` store raw zero-based signature positions. Update the attribute when parameters move. - RDL cannot spell a metadata parameter with neither In nor Out. Omitting direction invokes the type-based default. - Attributes on a void return row cannot round-trip because there is no return type to carry them. - `split` and `partition` clear existing `.rdl` files in the output directory before writing. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-rdl`**. ### How it's built The RDL grammar uses `syn`, `quote`, and `proc-macro2`. It reuses Rust's tokenizer so the syntax stays Rust-shaped. The `reader` lowers the syntax tree to ECMA-335 and emits `.winmd` through [`windows-metadata`](windows-metadata.md). The `writer` reads metadata through the same crate and writes canonical RDL. The `clang` path uses `clang-sys` to parse C or C++ translation units. It projects the declarations into the RDL syntax tree. The header path and hand-authored RDL path share the same lowering code. The `formatter` module pretty-prints generated RDL. ### Testing Dedicated test crates cover the crate: - `test_rdl` covers RDL to winmd round trips with `input/*.rdl` fixtures and invalid input with `errors/input/*.rdl` and `errors/expected/*.txt` diagnostic fixtures. - The `windows-clang` integration tests cover header-to-RDL output. - `tool-roundtrip` re-derives committed RDL files from committed winmd files. The `gen` workflow enforces a clean `git diff`. - `test_bindgen` covers the `.winmd` to Rust step that consumes this crate's output. Run targeted tests with: ```sh cargo test -p test_rdl cargo test -p windows-clang ``` ### Default metadata files `windows-rdl` builds the default metadata files used by the in-repo generators and library crates. | File | Source | Writer | |------|--------|--------| | `crates/libs/default/Windows.winmd` | Merged SDK contract winmds | `tool-winrt` | | `crates/libs/default/Windows.Win32.winmd` | Scraped SDK and WDK headers | `tool-win32` | The committed RDL files are the reviewable source for these metadata files: - `metadata/winrt/*.rdl` is partitioned by namespace. - `metadata/win32/*.rdl` is partitioned by defining header. - `metadata/wdk/*.rdl` is partitioned by defining header. The binary winmd files are derived artifacts. Generation is deterministic. The metadata writer stages tables in `BTreeMap`s and uses a fixed zero GUID for the module MVID. Every maintained crate that needs Win32 metadata resolves against the in-repo `Windows.Win32.winmd`. Minimal-binding crates and `windows-reactor` use it directly. The `windows` and `windows-sys` crates use it through `tool-package`. ### Multi-arch merge `tool-win32` scrapes x64, arm64, and x86 into separate RDL sets. Then `merge_arch_rdl` combines them into one winmd. A type with the same shape on every architecture is emitted once. A type that differs by architecture is split into per-architecture copies tagged `#[arch(X86|X64|Arm64)]`. The merge compares type structure through [`windows-metadata`](windows-metadata.md). `merge_arch_rdl` handles orchestration. It reads each architecture's RDL, runs the merge, and writes the combined output. `ArchInput` stores its RDL directory and winmd as `PathBuf`. ### Published crates and namespace remap The in-repo Win32 and WDK metadata lives in flat namespaces. Published `windows` and `windows-sys` APIs are partitioned behind many Cargo features. `tool-package` remaps the flat metadata into header-stem namespaces under `target/package/`. It uses the committed `metadata/win32` RDL directory as the routing signal. Then it runs `windows-bindgen` over that partition. `tool-features` uses the same remap so feature search reports the same header stems. The in-repo WinRT `Windows.winmd` is projected with the remapped Win32 and WDK metadata. ### Round-trip rules RDL is the reviewable source for WinRT, Win32, and WDK metadata. The `.winmd` files are derived artifacts. The `gen` workflow runs the generators and `tool-roundtrip`. It fails when regeneration changes tracked files. | Family | External source | RDL layout | Winmd build path | |--------|-----------------|------------|------------------| | WinRT | SDK winmds | `metadata/winrt`, per namespace | merge -> RDL -> winmd | | Win32 | SDK headers | `metadata/win32`, per header | scrape -> arch merge -> winmd | | WDK | WDK headers | `metadata/wdk`, per header | scrape -> arch merge -> winmd | `tool-roundtrip` validates the reverse direction: - WinRT uses `writer(Windows.winmd).split()` to write `metadata/winrt`. - Win32 and WDK cannot recover header files from flat winmd alone. The tool reads the committed RDL layout to map type names back to header stems. Then it writes `metadata/win32` or `metadata/wdk` with `writer(winmd).partition(map)`. ### Current normalization rules Some metadata forms have canonical RDL spellings. These rules are intentional. They keep generated RDL stable. | Form | RDL spelling | Reason | |------|--------------|--------| | WinRT `System.Char` | `Char16` | Keeps the type distinct from `u16`. | | Property setter parameter | `value` | Shorthand does not retain its original name. | | Event add parameter | `handler` | Shorthand stores the event shape. | | Event remove parameter names | `token` | The remove accessor takes an event token. | | Property and event accessors | Shorthand | The writer tracks consumed accessor methods. | | Other interface methods | Full method form | Non-accessor methods stay explicit. | | Input direction | `#[in]` | The reader accepts `#[r#in]`; the formatter emits `#[in]`. | | Raw identifiers, GUIDs, delegate ABIs | Canonical output | Equivalent text has one spelling. | The reader rejects unsupported forms with errors. It does not silently drop them. Examples include unsupported types, constants, callback ABIs, variadic callback parameters, and function ABIs. ### Inline nested records Inline structs and unions have nested TypeDefs linked by `NestedClass` rows. Their field signatures reference those definitions through enclosing-TypeRef chains, including every level of nesting. The writer matches the qualified identity to the containing record and renders the same inline syntax. It also accepts the unscoped leaf references in existing metadata. `test_rdl::nested_references` checks physical TypeRef scopes before and after the text round trip, alongside the canonical `struct_nested_anon.rdl` fixture. `test_metadata::nested_references` independently covers the underlying signature reader, merge, and namespace remapper. ### Method parameter rows The winmd writer uses `MethodDef::params_by_sequence` from [`windows-metadata`](windows-metadata.md). Sequence 0 supplies return-type attributes. Nonzero rows are matched to one-based signature positions, so sparse or out-of-order metadata cannot rename or reflag another parameter. Every signature parameter is emitted; a missing row uses `pN` with no explicit direction or optional marker, which the RDL reader lowers with its existing type-based direction default. Duplicate and out-of-range sequences stop the write with a diagnostic. Direction and optionality come from `MethodParam::direction()` and `is_optional()`. Reserved, retval, and count attributes remain independent pseudos or custom attributes. The writer applies RDL's format boundary only when spelling them: In+Out emits both markers, while Unspecified emits the input spelling because RDL has no literal unspecified-direction syntax. `test_rdl::method_params` authors sparse and out-of-order rows directly, checks parameter and return pseudos in the generated RDL, and compiles the RDL back to dense metadata with the same associations. It also checks that every non-return `Param` row in the committed WinRT, Win32, and WDK metadata has at least one representable direction flag. ### Lossless round-trip limits - **Direction flags:** RDL has no spelling for a `Param` row with neither In nor Out. Omitting both invokes the type-based default, so a metadata row with neither flag reads back as In. - **Void return rows:** Return attributes are written after `->`. A void method has no return type to carry them, so attributes on its sequence 0 row are not represented. - **Count relationships:** `#[len_param(N)]` and `#[size_param(N)]` store raw zero-based signature positions. Reordering parameters without updating `N` changes the relationship. - **Pointer constness:** `metadata::Type` stores one constness bit with a pointer depth. Uniform chains such as `*mut *mut T` and `*const *const T` round-trip. Mixed chains are rejected before metadata is written, including chains nested inside a reference. --- ### Crates Windows Reactor Setup (`docs/crates/windows-reactor-setup.md`) # windows-reactor-setup > Build-time staging for self-contained Windows Reactor applications. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-reactor-setup) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-reactor-setup) - ๐Ÿš€ [Getting started](../../crates/libs/reactor-setup/readme.md) - ๐Ÿงฉ [Self-contained sample](../../crates/samples/reactor/self_contained) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/reactor-setup) ## When to use it Use `windows-reactor-setup` only when a [`windows-reactor`](windows-reactor.md) executable must carry a private Windows App SDK runtime beside the executable. It is a build dependency called from `build.rs`; it is not a runtime API and does not belong in `[dependencies]`. Do not use it for a framework-dependent Reactor application. `windows-reactor` already contains the framework bootstrap that resolves an installed Windows App SDK framework package at startup. That deployment model stages no private runtime files. Do not use it for a plain `windows-webview` `HWND` host. The WebView2 Evergreen runtime supplies that COM-only path. Reactor's XAML WebView2 control has an additional projection DLL requirement, which this setup helper handles for self-contained Reactor apps. ## Prerequisites - The Cargo target OS must be Windows. - The build needs network access the first time each pinned NuGet package is staged. - `%SystemRoot%\System32\curl.exe` and `tar.exe` must be available. - The target must use MSVC, or the LLVM-based GNU ABI supported by the manifest linker arguments. - Supported target architecture mappings are `x86` -> `x86`, `aarch64` -> `arm64`, and other Rust target architectures -> `x64`. The README contains the build-dependency declaration and one-line `build.rs`. ## First workflow: produce a self-contained build 1. Add `windows-reactor-setup` under `[build-dependencies]`. 2. Create `build.rs` and call `windows_reactor_setup::as_self_contained()`. 3. Build the application normally with Cargo. 4. Run the executable from its Cargo profile output directory to confirm the staged runtime is used. 5. Package the executable together with all staged DLLs and runtime directories from that output directory. Preserve their relative layout. 6. Test the packaged directory on a machine that does not provide the framework package expected by a framework-dependent build. The [`reactor/self_contained`](../../crates/samples/reactor/self_contained) sample is the reference project layout. The [`webview/reactor`](../../crates/samples/webview/reactor) sample shows the same setup for a Reactor app containing the XAML WebView2 control. ## What the build step does `as_self_contained` performs these operations during the application build: 1. Resolve Cargo's profile output directory from `OUT_DIR` and `PROFILE`. 2. Download and cache the pinned `Microsoft.WindowsAppSDK.Runtime` NuGet package. 3. Extract the MSIX for the target architecture. 4. Copy the allow-listed Windows App Runtime files to the profile output directory. 5. Download and cache the pinned `Microsoft.Web.WebView2` NuGet package. 6. Copy the target architecture's `native_uap/Microsoft.Web.WebView2.Core.dll` beside the executable. 7. Write an application manifest containing the self-contained deployment marker. 8. Pass linker arguments that embed the manifest in binary targets. Downloads and extracted packages are cached under `%LOCALAPPDATA%\windows-reactor-setup\temp\v1` when `LOCALAPPDATA` is available. Cargo may rerun the build script, but the cached package and extraction directories avoid downloading on every build. The versioned cache does not reuse unchecked entries in the parent `temp` directory. Its first use requires a fresh download. MSIX extraction caches are separate for each target architecture. ## Deployment and shared target directories The Cargo profile directory can contain outputs from several packages. Stage the application from a clean, known build profile and copy every runtime file and subdirectory required beside the executable. Copying only the `.exe` does not produce a self-contained deployment. A destination-owned file lock serializes runtime and WebView2 copying by build scripts sharing the same Cargo profile directory. Cache locks alone do not protect this shared output. The embedded manifest includes a `windows-reactor-self-contained` description marker. Reactor reads that marker to select the private runtime. A framework-dependent executable ignores private files left by a self-contained build in the same Cargo target directory and uses its inlined framework bootstrap instead. `Microsoft.Web.WebView2.Core.dll` is always staged. This allows a self-contained app to add `windows-webview`'s `reactor` feature without another deployment step. It is the WinRT projection assembly used by the XAML control, not the `webview2loader.dll` used by COM-only hosting. ## Failures and cleanup `as_self_contained` has no `Result` return. Unsupported target configuration, missing Cargo environment variables, and staging errors panic during the build. Download, extraction, directory access, and copy errors stop staging before the helper emits manifest linker arguments. Diagnostics include the failing path or command. Cache entries are published only after extraction succeeds and required files are present. Failed or interrupted staging leaves an unpublished `.partial` directory, which the next attempt discards and rebuilds. A failed copy can leave some files in the Cargo output directory, but the build fails and the next attempt copies the runtime again. The first build therefore requires reliable NuGet access. In offline build environments, populate the helper's package cache before disconnecting or use a build environment with the required cache. Do not delete the cache while another build is using it. Staged files live in the Cargo profile output directory, outside the package's `OUT_DIR`. `cargo clean` removes the target output but not the package cache under `LOCALAPPDATA`. Remove that specific cache directory manually only when forcing a fresh package download. The helper copies fixed package versions. Update the crate rather than replacing staged files by hand so the manifest, runtime allow-list, and WebView2 projection stay compatible. --- ## Internal documentation This section is for contributors to `windows-reactor-setup`. `as_self_contained` validates `CARGO_CFG_TARGET_OS`, derives the target directory from the nearest ancestor matching `PROFILE`, and falls back to the conventional ancestor depth. The unit tests cover standard and split-package `OUT_DIR` layouts. `stage_pkg` downloads a `.nupkg` inside a staging directory, extracts it, verifies the requested architecture's MSIX or WebView2 DLL, and removes the archive before publishing the directory. Runtime MSIX extraction uses `.msix_extract-` and checks for the core runtime and XAML DLLs before publication. `cached_dir` holds a file lock for each cache entry while checking, populating, and publishing it. Extraction happens in a sibling `.partial` directory, followed by a rename to the final name. The lock is released when its file handle is dropped, including after a failed or terminated build. Concurrent builds share the completed entry rather than modifying the same staging directory. `copy_runtime_to` copies only top-level entries named in `assets/runtime.txt`, then recursively preserves any selected directory. Keep that allow-list in sync with the pinned Windows App SDK runtime. Filesystem tests cover architecture isolation, failed extraction and retry, required-file checks, concurrent cache publication, concurrent deployment processes, and copy failures. Archive tests use local ZIP fixtures and the system `tar.exe`; they do not download packages or launch WinUI. The application manifest template is `assets/app.manifest`. The function inserts the deployment marker after the opening assembly element, writes the result to `OUT_DIR`, and emits binary-only manifest linker arguments for MSVC or LLVM GNU targets. `deploy_webview2` copies `Microsoft.Web.WebView2.Core.dll` from the pinned WebView2 package's per-architecture `native_uap` directory. Keep its package version compatible with the WinRT metadata and XAML WebView2 bridge used by `windows-webview` and Reactor. --- ### Crates Windows Reactor (`docs/crates/windows-reactor.md`) # windows-reactor > A declarative WinUI 3 library built around components, typed messages, and native controls. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-reactor) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-reactor) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples/reactor) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/reactor) Windows Reactor lets Rust state drive native WinUI 3 controls. Start with a counter, then add editable state, child components, and background work. Later sections cover common application tasks and link to complete samples. Reactor is currently a preview, so releases may still refine public APIs. ## Create a project Create a binary crate and add Reactor: ```text cargo new counter cd counter cargo add windows-reactor@0.100 ``` Use the default features. An installed Windows App SDK runtime is required for the default deployment model; see the [setup guide](windows-reactor-setup.md) for prerequisites. For a GUI executable that should not open a console window, add this to the top of `main.rs`: ```rust,ignore #![windows_subsystem = "windows"] ``` Leave it out while diagnosing startup problems so console output remains visible. ## Add a component Replace `main.rs` with: ```rust,no_run use windows_reactor::*; #[derive(Clone, Copy)] enum Message { Increment, Reset, } struct Counter { count: i32, } impl Component for Counter { type Input = (); type Message = Message; fn create(_input: &(), _context: &ComponentContext) -> Self { Self { count: 0 } } fn update(&mut self, message: Message, _context: &ComponentContext) { match message { Message::Increment => self.count += 1, Message::Reset => self.count = 0, } } fn view(&self, _input: &(), context: &mut ViewContext) -> View { let content = StackPanel::new().spacing(8.0).children(( format!("Count: {}", self.count), Button::new() .on_click(context.message(Message::Increment)) .content("Increment"), Button::new() .on_click(context.message(Message::Reset)) .content("Reset"), )); context.window_frame("Counter", content) } } fn main() { App::run_component::(()).unwrap(); } ``` Run it: ```text cargo run ``` The component loop is: ```text native event -> typed message -> update state -> describe the next view ``` | Method | Purpose | | --- | --- | | `create` | Build the initial state | | `update` | Handle a message and change the state | | `view` | Describe the controls for the current state | `view` uses typed builders. `StackPanel::children` accepts a tuple of different control types, and strings convert directly to text views. The button callbacks enqueue messages for `update`; they do not mutate state inside the native event callback. `context.window_frame` publishes the window title and returns the standard title-bar layout. For a static view with no state or events, call `App::run(view)` instead. ## Add editable state To drive an editable control from component state, declare its current value and send changes back as messages. ```rust,ignore TextBox::new().text(self.name.clone()) .placeholder_text("Type your name") .on_text_changed(context.callback(Message::SetName)) ``` Handle `Message::SetName(name)` in `update` by assigning `self.name = name`. Reactor suppresses feedback from its own writes while still delivering user edits. Only declared properties are controlled; subscribing to changes does not take ownership. Omitting a previously declared property clears its native assignment once. An explicit `None` is a declared value, not an omitted property. Store values in component state when they must survive control replacement. The [`controlled`](../../crates/samples/reactor/controlled) sample shows the complete pattern. ## Split up the view Use a function returning `View` for a stateless piece. Use a child component when a subtree needs its own state or lifecycle: ```rust,ignore View::component::(GreetingInput { name: self.name.clone(), }) ``` Component input must implement `Clone + PartialEq`. Children at fixed positions keep identity by position and type. Items that can move need stable application keys: ```rust,ignore StackPanel::new().keyed_children( self.tasks .iter() .map(|task| (task.id, task.title.clone())), ) ``` Do not use list indices as keys when items can move. Stable keys keep state and focus attached to the correct item. ## Do work without blocking the window Rendering and component updates run on the UI thread. Use `set_timeout` for delayed messages and `spawn_background` for blocking or CPU-intensive work. Background work returns a message rather than touching controls or component state directly. Use an effect when an external subscription or resource should exist only while part of the view is present. See the [`use-effect`](../../crates/samples/reactor/use-effect) and [`async-state`](../../crates/samples/reactor/async-state) samples for complete lifecycle patterns. ## Application state and notification icons Use `App::run_application::(input)` for application state that must survive closing individual windows. Implement `Application` with `create`, `update`, and `view`, using typed messages and callbacks as with `Component`. An `ApplicationView` declares windows and notification icons without requiring a hidden application window. | Declaration or command | Behavior | | --- | --- | | `view.window::("main", input)` | Registers a reopenable window without opening it. | | `context.show_window("main")` | Opens, restores, or activates that window; repeated requests coalesce. | | Updated window input | Reaches the existing component without recreating its state. | | User closes a window | Drops its component state; the declaration remains available to reopen. | | Omit a window key | Closes its instance and removes its declaration. | | `view.notify_icon("tray", icon)` | Creates or updates the keyed Shell registration. | | Omit an icon key | Removes its registration and dismisses its menu. | | `context.exit()` | Ends the application and releases all owned resources. | Keys must be unique within each resource kind. A live window key must retain its component type. Only keys declared in the application's view can be opened. Construct a notification declaration with `NotifyIcon::new(path)`, then attach `tooltip`, `on_activate`, and `menu`. The icon path names an `.ico` file. Activation callbacks receive a `ScreenPoint`; attaching a `Menu` handles both mouse and keyboard context-menu positioning without application-side coordinate conversion. Windows and notification icons have independent lifetimes. The application keeps running while either remains; registered but closed window slots do not keep it alive. The [notification icon sample](../../crates/samples/reactor/notifyicon) demonstrates independent window and icon lifetimes with typed inputs and callbacks. The [basic sample](../../crates/samples/reactor/notifyicon-basic) contains only a notification icon and an Exit menu. Notification menus follow the Windows taskbar theme. For a menu independent of a notification icon or control, `AppContext::show_menu_at` accepts a `Menu` and physical screen coordinates. ## Position and restore windows Publish startup placement through `context.window_visuals`. The first committed declaration is applied before the native window becomes visible, for both primary and secondary windows. | Setting | Meaning | | --- | --- | | `initial_position(ScreenPoint)` | Initial outer-window top-left in physical screen pixels | | `initial_placement(WindowPlacement)` | Restored outer bounds in physical screen pixels, plus maximized state | | `client_size(width, height)` | Client-area size in DIPs; later explicit changes still resize | | `constraints(WindowConstraints)` | Client-size limits in DIPs, including when restoring placement | Full placement takes precedence over initial position and initial client size. Later changes to either initial setting do not move or resize an open window. Load saved placement before opening the window; an asynchronous update after startup is too late. Negative coordinates are valid on a multi-monitor desktop. Windows adjusts fully off-screen bounds to an available monitor. ```rust,ignore context.window_visuals(WindowVisuals::new().initial_placement(saved_placement)); context.on_window_placement(context.callback(Message::Placement)); ``` `on_window_placement` reports the initial placement and native changes while subscribed. Notifications contain the restored outer bounds even when maximized and exclude minimized state. Applications own persistence: save observations in the message handler rather than waiting for a final shutdown notification. Keeping a saved value in `initial_placement` does not move the window back after a user move. `on_color_scheme` also reports the current value when subscribed; `on_window_size` reports changes only. Replacing an observer callback does not replay the current value. Observers end when omitted from the view or when their component closes. Use `WindowVisuals::theme` to choose System, Light, or Dark. With no backdrop, transparent content shows the window's themed background. Use `WindowVisuals::backdrop` to select Mica, MicaAlt, or Acrylic; an opaque application background covers the material. | Sample | Shows | | --- | --- | | [`window-placement`](../../crates/samples/reactor/window-placement) | Open a window at an observed placement | | [`window-placement-registry`](../../crates/samples/reactor/window-placement-registry) | Save placement across process restarts | | [`window-observers`](../../crates/samples/reactor/window-observers) | Subscribe to size, placement, and color-scheme changes | | [`window-theme`](../../crates/samples/reactor/window-theme) | Themes, backdrops, and application backgrounds | ## Display images `Image` and `ImageIcon` support these source builders: | Builder | Source | | --- | --- | | `source(uri)` | A URI; returns a `Result` | | `source_file(path)` | A file path; returns a `Result` | | `source_data(bytes)` | Encoded bitmap bytes | | `source_svg(bytes)` | SVG bytes | Use `EncodedImage::from_static` for embedded assets or `EncodedImage::new` for owned bytes. URI and file sources select SVG by the `.svg` extension. In-memory sources choose their decoder through the builder: ```rust,no_run # use windows_reactor::*; let svg = EncodedImage::from_static( br#" "#, ); StackPanel::new().children(( Image::new().source_svg(svg.clone()), AppBarButton::new().icon(Icon::image_svg(svg)), )); ``` Keep owned bytes in component state and clone the value when describing the view. Equal sources share native images within a runtime. `Image::on_opened` and `on_failed` report loading outcomes for each assignment, including when a shared source has already loaded. The [`image-sources`](../../crates/samples/reactor/image-sources) sample compares the source builders across images and icon slots. [`image-reuse`](../../crates/samples/reactor/image-reuse) shows page replacement with shared sources. ## Animate a visual `Border` pairs `opacity`, `scale`, and `translation(x, y)` with matching `opacity_transition`, `scale_transition`, and `translation_transition` durations. Translation uses DIPs and changes visual position without changing layout space. New or replaced visuals start at their declared values without animating from native defaults. Later transition settings apply before target changes in the same render, regardless of builder order. Removing a target restores its default using the current transition. Removing a transition affects future target changes; an animation already running can finish. Native transitions respect the Windows animation setting. See the [translation sample](../../crates/samples/reactor/translation-transition) for sliding and reversal. ## Add icon content Use `Icon` to supply a control's icon content: ```rust,no_run # use windows_reactor::*; StackPanel::new().children(( TitleBar::new() .title("Search") .icon(Symbol::Home) .left_header(TextBlock::new().text("Files")), AutoSuggestBox::new().query_icon(Icon::font("\u{E721}")), )); ``` Use `Icon::symbol`, `Icon::font`, `Icon::bitmap`, `Icon::image_*`, or `Icon::path` for control icon slots. Use `SymbolIcon`, `FontIcon`, `BitmapIcon`, `ImageIcon`, and `PathIcon` when the icon is a standalone visual that needs layout or other visual properties. ## Choose a deployment model A framework-dependent application uses an installed Windows App SDK framework package and needs only `windows-reactor`. For a self-contained application, add: ```toml [build-dependencies] windows-reactor-setup = "0.100" ``` Then create `build.rs`: ```rust,ignore fn main() { windows_reactor_setup::as_self_contained(); } ``` The [setup guide](windows-reactor-setup.md) covers prerequisites, WebView2, and packaging. ## Explore larger samples | Sample | What it demonstrates | | --- | --- | | [`calculator`](../../crates/samples/reactor/calculator) | State, messages, and Grid layout | | [`solitaire`](../../crates/samples/reactor/solitaire) | A larger application with keyed state | | [`stacker`](../../crates/samples/reactor/stacker) | Reactor, Canvas, and Composition together | | [`gallery`](../../crates/samples/reactor/gallery) | Available controls and navigation | Browse the [sample directory](../../crates/samples/reactor) for smaller examples of controlled input, context, effects, multiple windows, virtualization, WebView2, and deployment. The [navigation sample](../../crates/samples/reactor/navigation-view-properties) demonstrates pane content and visibility settings. ## Contributing Controls are generated from `crates/tools/reactor/src/schema.toml` and the committed WinUI metadata. Edit the schema or generator, not the generated files. `tool-reactor-metadata` refreshes the metadata; `tool-reactor` generates declarations, native adapters, bindings, and control coverage. The native binding filter is `crates/tools/reactor/src/bindings.txt`. Use metadata names unless a shared Reactor name matches the public value, role, and behavior. Container names distinguish one owned visual (`content`), ordered visuals (`children`), and item declarations (`items`). After a generator or schema change, regenerate and inspect the output: ```text cargo run -p tool-reactor --quiet cargo check -p windows-reactor --quiet cargo test -p windows-reactor --all-features --lib ``` Changes to the public API also require updating `public-api.txt`. --- ### Crates Windows Reference (`docs/crates/windows-reference.md`) # windows-reference > A stock implementation of the WinRT `IReference` interface. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-reference) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-reference) - ๐Ÿš€ [Getting started](../../crates/libs/reference/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/reference) ## When to use this crate Use `windows-reference` when a WinRT signature explicitly requires `IReference` and you need to box a Rust value for that call or component boundary. WinRT uses this interface for boxed value types, similar to `Nullable` in other projections. Do not use it for ordinary Rust borrowing. `&T`, `Box`, and `Option` express Rust ownership and optionality without creating a WinRT object. Add this crate only at an interop boundary that names `IReference`. ## Getting started The crate [README](../../crates/libs/reference/readme.md) has the dependency declaration and minimal boxing example. The public implementation is available on Windows with the default `std` feature. The value type must implement `RuntimeType + Clone + 'static`. The first workflow is to convert a value with `IReference::::from`, pass the resulting projected interface to the WinRT API, and call `Value` when reading one received from an API: ```rust use windows_reference::IReference; fn round_trip() -> i32 { let boxed = IReference::::from(42); boxed.Value().unwrap() } ``` In application code, propagate the `Result` from `Value` instead of unwrapping when the interface call can fail. ## Core API model `IReference` is a reference-counted WinRT object. Creating one clones or moves the Rust value into a stock implementation, and each call to `Value` returns a clone. Cloning the `IReference` itself clones the interface reference, not the boxed value. The object implements the WinRT identity and runtime type information for `Windows.Foundation.IReference`. It also supports `IPropertyValue` for scalar value types, but the public Rust wrapper exposes `Value` as the supported way to retrieve the boxed value. ## Common tasks ### Box scalar and string values ```rust use windows_reference::IReference; use windows_strings::HSTRING; let count = IReference::::from(3); assert_eq!(count.Value().unwrap(), 3); let label = IReference::::from("ready"); assert_eq!(label.Value().unwrap(), "ready"); ``` `IReference` accepts `HSTRING`, `&HSTRING`, `String`, and `&str`. Other supported value types use their normal `From` conversion. Add `windows-strings` directly when the surrounding crate does not already provide its string types. ### Use a boxed value in a component Keep `IReference` in the component signature when the metadata declares a boxed value. Accept the interface by the projected parameter form, call `Value` once, and continue with the plain Rust value. When returning one, construct it at the return boundary: ```rust use windows_reference::IReference; fn boxed_count(value: u32) -> IReference { IReference::from(value) } ``` This keeps WinRT reference counting at the boundary and avoids repeated ABI calls in the rest of the implementation. ## Important choices and pitfalls - `IReference` boxes a present value. Optionality is represented by whether the interface itself is present in the surrounding projected signature. - `Value` is fallible because it is a WinRT interface call, even for an object created locally. - The value is cloned into and out of the stock object. Avoid using it as a high-frequency wrapper for large values when a different API shape is under your control. - The generic type determines the interface IID and must match the receiving signature exactly. `IReference` and `IReference` are different WinRT interface types. - Array accessors on the object's internal `IPropertyValue` implementation are not supported. Use the typed `Value` method. ## Samples and next steps The [`reference-reference`](../../crates/samples/reference/reference) sample boxes scalar and string values and reads them through `IReference`. For related interop patterns, see [`windows-collections`](windows-collections.md) for collection interfaces and the [`robot` sample](../../crates/samples/robot) for a component boundary implemented in Rust. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-reference`**. ### How it's built `src/bindings.rs` is generated; the `IReference` implementation is hand-written. ### Testing Run `cargo test -p windows-reference`; see also the workspace test crates. --- ### Crates Windows Registry (`docs/crates/windows-registry.md`) # windows-registry > Simple, safe, and efficient access to the Windows registry. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-registry) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-registry) - ๐Ÿš€ [Getting started](../../crates/libs/registry/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/registry) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/registry) `windows-registry` wraps the Win32 registry APIs behind a small, safe surface. Start from one of the predefined roots, then open a key and work with typed values. ## When to use Use this crate when a Windows application must read or write registry configuration and wants owned keys, typed values, iteration, transactions, or explicit registry-view selection. Use a portable configuration format when settings must work on non-Windows systems or travel with the application. ## Getting started The [crate README](../../crates/libs/registry/readme.md) has the dependency declaration and minimal read/write and transaction examples. For a first workflow, read application settings under `CURRENT_USER` and propagate missing-key, access, type, and data errors to the layer that can decide how to handle them: ```rust,no_run use windows_registry::{CURRENT_USER, Result}; fn read_launch_count() -> Result { let key = CURRENT_USER.open(r"Software\Contoso\Widget")?; key.get_u32("LaunchCount") } ``` Create keys during installation or first-run setup, and remove test data when finished. ## Keys and access The predefined roots include `CLASSES_ROOT`, `CURRENT_CONFIG`, `CURRENT_USER`, `LOCAL_MACHINE`, and `USERS`. `open` requests read access. `create` opens or creates a key with read and write access. Both return an owned `Key` that closes its handle on drop. Use `options()` when the defaults are not appropriate: ```rust,no_run use windows_registry::{CURRENT_USER, Result}; fn open_for_update() -> Result { CURRENT_USER .options() .read() .write() .wow64_64() .open(r"Software\Contoso\Widget") } ``` The builder can add access rights, create a volatile key, or associate the operation with a `Transaction`. ## Reading, writing, and enumerating Typed helpers cover `u32`, `u64`, strings, expandable strings, multi-strings, and binary data. `get_value` and `set_value` preserve a value's registry `Type` when the typed helpers are not enough. `keys()` enumerates child names and `values()` enumerates names and values. Registry operations are not atomic as a group. To update several keys together, create a `Transaction`, open or create each key through options associated with it, and call `commit`. Dropping an uncommitted transaction rolls it back. ## Platform constraints and pitfalls - The crate is Windows-only. Access to protected locations such as parts of `LOCAL_MACHINE` depends on the process token and may require elevation. - A 32-bit process and a 64-bit process can see different redirected views. Select `wow64_32()` or `wow64_64()` when both processes must address a known view. They are mutually exclusive; the last call wins. - Expandable strings are returned as stored. Reading one does not expand environment variables. - Value names may be empty for a key's default value. - `remove_tree` is recursive. Scope the parent and path carefully before deleting. - Kernel Transaction Manager support and policy can vary by Windows environment. Surface transaction creation and commit failures to the caller. ## Samples and next steps The [`read-write` sample](../../crates/samples/registry/read-write) creates, reads, and removes a test key. The [`transaction` sample](../../crates/samples/registry/transaction) performs the write through a transaction. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-registry`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/registry.txt`; `Key`, `Value`, `OpenOptions`, and `Transaction` are hand-written safe wrappers. ### Testing Run `cargo test -p windows-registry`; see also the workspace test crates. --- ### Crates Windows Result (`docs/crates/windows-result.md`) # windows-result > Efficient Windows error handling and propagation for Win32, COM, and WinRT. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-result) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-result) - ๐Ÿš€ [Getting started](../../crates/libs/result/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/result) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/result) ## When to use this crate Use `windows-result` when code works directly with Windows status values or exposes Windows errors without depending on the larger `windows-core` crate. Generated windows-* APIs normally return these types through a re-export, so application code often does not need a separate dependency. Choose this model when callers need the original `HRESULT`, Win32 error code, or COM error information. Convert to a domain-specific error at your application boundary when callers do not need the Windows details. ## Getting started The crate [README](../../crates/libs/result/readme.md) contains the dependency declaration and a minimal example. A typical first workflow is to keep `windows_result::Result` as the return type, convert the status value immediately after a Windows call, and use `?` for propagation: ```rust use windows_result::{HRESULT, Result}; fn check_status(status: HRESULT) -> Result<()> { status.ok()?; Ok(()) } ``` On Windows, status-to-message conversion asks the operating system for descriptive text. The core status and error types also compile without `std`; integrations such as `std::error::Error` and `std::io::Error` require the default `std` feature. ## Core API model | Type | Success rule | Typical source | | --- | --- | --- | | `HRESULT` | Any value >= 0 | COM and WinRT methods | | `BOOL` | Any nonzero value | Win32 functions with `GetLastError` on failure | | `WIN32_ERROR` | Zero | `GetLastError` and Win32 error constants | | `NTSTATUS` | Any value >= 0 | Native system APIs | | `RPC_STATUS` | Zero | RPC APIs | | `Error` | Always represents an error | Rich Rust error with code and optional error info | | `Result` | `Result` | Windows operations exposed to Rust | The wrappers preserve the status representation until it needs to become an `Error`. Their `ok` methods apply the correct success rule, and conversions normalize failures to an `HRESULT`. ## Common tasks ### Convert a status and preserve its code ```rust use windows_result::{Error, Result, WIN32_ERROR}; fn cancelled() -> Result<()> { let code = WIN32_ERROR(1223); Err(Error::from(code)) } let error = cancelled().unwrap_err(); assert_eq!(WIN32_ERROR::from_error(&error), Some(WIN32_ERROR(1223))); ``` `WIN32_ERROR::to_hresult` uses the standard `FACILITY_WIN32` mapping. Use `WIN32_ERROR::from_error` when you need to recover a mapped Win32 code. ### Attach context to a failure Use `Error::new` when you are creating the failure and have a useful message: ```rust use windows_result::{Error, WIN32_ERROR}; let code = WIN32_ERROR(1223).to_hresult(); let error = Error::new(code, "operation cancelled"); assert_eq!(error.code(), code); assert_eq!(error.message(), "operation cancelled"); ``` `Error::from_hresult` stores only the code. Converting an `HRESULT` with `Error::from` can capture thread-local COM error information when it is available. `Error::message` falls back to the system description for the code. ### Work with last-error APIs Call `BOOL::ok`, `WIN32_ERROR::from_thread`, or `Error::from_thread` immediately after the failing Windows call. Another Windows call may overwrite the thread's last-error value. ```rust use windows_result::{BOOL, Result}; fn check_win32_result(value: BOOL) -> Result<()> { value.ok() } ``` Only use this pattern for APIs whose documentation says failure details come from `GetLastError`. Some Win32 functions use other return conventions. ## Important choices and pitfalls - `HRESULT(1)` is success, not failure. Test it with `is_ok` or `ok` rather than comparing with zero. - `BOOL(0).ok()` reads the current thread's last-error value. Do not construct a false `BOOL` later and expect it to retain the original error. - `Error` equality and ordering compare the `HRESULT`, not the message or COM error information. - Converting a mapped Win32 `Error` to `std::io::Error` recovers the underlying Win32 code. Other facilities retain the full `HRESULT` as the raw OS error. - `--cfg=windows_slim_errors` is a whole-program policy that stores only the four-byte `HRESULT`. It reduces error size but discards extended COM and WinRT error information. ## Samples and next steps The [`result-result`](../../crates/samples/result/result) sample creates an error with a message, propagates status failures, and inspects the resulting error. Run it from the workspace with: ```text cargo run -p result-result ``` For error handling alongside projected COM types, continue with [`windows-core`](windows-core.md). --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-result`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/result.txt`. The `com`, `bstr`, and `strings` modules add COM error-info support and are gated on `windows` (and disabled under the `windows_slim_errors` cfg). ### Testing Run `cargo test -p windows-result`; see also the workspace test crates. --- ### Crates Windows Services (`docs/crates/windows-services.md`) # windows-services > A simple, safe way to implement Windows services in Rust. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-services) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-services) - ๐Ÿš€ [Getting started](../../crates/libs/services/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/services) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/services) `windows-services` lets you write a Windows service process with a builder. Use `Service::new` to declare accepted controls, then `run` to connect the process to the Service Control Manager (SCM). ## When to use Use this crate to implement the runtime side of a Windows service: service startup, status changes, and control callbacks. It does not install, configure, start, or remove the service registration. Use the SCM command-line tools or an installer for that lifecycle. Use a normal console application for foreground tools and short-lived scheduled work. A service is appropriate when Windows must manage a long-running background process and deliver service control events. ## Getting started The [crate README](../../crates/libs/services/readme.md) has the dependency declaration and minimal builder example. The first practical workflow is: 1. Build a service executable. 2. Register its absolute path with the SCM. 3. Start it through the SCM, not by launching it directly. 4. Handle `Command::Start` and every control enabled on the builder. 5. Stop and remove the test registration when finished. The [`simple` sample](../../crates/samples/services/simple/src/main.rs) prints the corresponding `sc create`, `sc start`, `sc query`, `sc stop`, and `sc delete` commands when run outside the SCM. ## Commands and state `Service::new` accepts only startup by default. `can_stop` enables stop and shutdown controls. `can_pause` enables pause and resume. `can_accept(mask)` enables other SCM control classes, which arrive as `Command::Extended`. The callback receives `&Service` and a `Command`. The crate moves through the normal pending and stable states around start, stop, pause, and resume callbacks. Use `state()` to inspect the current state and `set_state()` only when the service needs to report a state outside that automatic flow. Keep the callback responsive. Start worker threads or signal existing workers instead of doing lengthy work on the control callback. On `Stop`, signal shutdown and release resources promptly. ## Running outside the SCM Without configuration, `run` returns an error when the process was not started by the SCM. `can_fallback` installs a closure for intentional console or development execution. In fallback mode the crate sends start and stop commands around that closure, allowing one executable to share service setup with a local test path. ## Platform constraints and pitfalls - The crate and service process are Windows-only. - Registering or changing a service normally requires administrative rights. - `run` owns the service dispatch lifecycle. Arrange application initialization before calling it. - Enable only controls the callback handles. Other accepted controls arrive with raw event data in `ExtendedCommand`; interpret that pointer only according to the matching Windows control code and during the callback. - A service normally has a different working directory, environment, account, and desktop access than an interactive process. Use absolute paths and avoid assumptions about an interactive user. - Log to the Windows Event Log or another service-safe destination rather than standard output. ## Samples and next steps Start with the [`simple` sample](../../crates/samples/services/simple). The [`time-change` sample](../../crates/samples/services/time) shows `can_accept`, an extended time-change control, and decoding its event data with the matching Win32 definitions. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-services`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/services.txt`; the service runtime and dispatch glue are hand-written. ### Testing Run `cargo test -p windows-services`; see also the workspace test crates. --- ### Crates Windows Strings (`docs/crates/windows-strings.md`) # windows-strings > The string types used across the Windows APIs. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-strings) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-strings) - ๐Ÿš€ [Getting started](../../crates/libs/strings/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/strings) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/strings) ## When to use this crate Use `windows-strings` when a Windows ABI requires a Windows string type and you do not otherwise need `windows-core`. Most projected APIs re-export these types, so use the type named by the function signature instead of converting every string to one preferred representation. The main choice is ownership: `HSTRING` and `BSTR` own their contents, while `PCSTR`, `PCWSTR`, `PSTR`, and `PWSTR` are pointer wrappers whose storage belongs elsewhere. ## Getting started The crate [README](../../crates/libs/strings/readme.md) has the dependency declaration and a minimal example for each common representation. Before the first API call, inspect its signature: 1. Use `HSTRING` for WinRT strings. 2. Use `BSTR` for COM Automation strings. 3. Use `PCWSTR` or `PCSTR` for borrowed, null-terminated input. 4. Use `PWSTR` or `PSTR` only when the API writes through the pointer. `HSTRING`, the pointer wrappers, and the literal macros are available across targets. `BSTR` is Windows-only because allocation and deallocation use the COM Automation ABI. Conversions involving `OsStr`, `OsString`, or `Path` require Windows and the default `std` feature. ## Core API model | Type or macro | Encoding and ownership | Common use | | --- | --- | --- | | `HSTRING` | Owned, immutable, reference-counted UTF-16 | WinRT parameters and results | | `BSTR` | Owned, length-prefixed UTF-16 | COM Automation parameters and results | | `PCWSTR` / `PWSTR` | Borrowed const / mutable UTF-16 pointer | Win32 wide-string ABIs | | `PCSTR` / `PSTR` | Borrowed const / mutable 8-bit pointer | Win32 8-bit string ABIs | | `h!` | Static `&HSTRING` literal | Reused WinRT string constant | | `w!` | Static null-terminated `PCWSTR` literal | Wide input constant | | `s!` | Static null-terminated UTF-8 `PCSTR` literal | 8-bit input constant | | `HStringBuilder` | Preallocated mutable UTF-16 buffer | Build one immutable `HSTRING` | Length-prefixed types can represent data independently of a trailing null. Pointer types depend on a null terminator and do not record a length or lifetime. ## Common tasks ### Create owned strings ```rust use windows_strings::{BSTR, HSTRING}; let runtime_name = HSTRING::from("Windows.Foundation.Uri"); assert_eq!(runtime_name, "Windows.Foundation.Uri"); #[cfg(windows)] { let automation = BSTR::from("report"); assert_eq!(automation, "report"); } ``` `HSTRING::from_wide` accepts UTF-16 code units directly. `to_string_lossy` and `display` are useful when diagnostics should continue through invalid UTF-16; equality against `str` compares the encoded contents without first allocating a Rust `String`. ### Pass string literals ```rust use windows_strings::{h, s, w, HSTRING, PCSTR, PCWSTR}; const UTF8_NAME: PCSTR = s!("name"); const WIDE_NAME: PCWSTR = w!("name"); let runtime_name: &HSTRING = h!("Windows.Foundation.Uri"); ``` The literal macros append the required terminator at compile time. `h!` returns a borrowed static `HSTRING`; clone it or construct `HSTRING::from` only when an owned value is required. ### Read a pointer returned by Windows Pointer conversion is unsafe because the wrapper cannot prove that the pointer is non-null, valid, terminated, or still alive: ```rust use windows_strings::PCWSTR; unsafe fn copy_wide(value: PCWSTR) -> Result { unsafe { value.to_string() } } ``` Check the producing API's ownership rules before reading or freeing its pointer. A null pointer is not an empty string: calling `len`, `as_wide`, `as_bytes`, or `to_string` on it is invalid. ### Fill an `HSTRING` buffer Use `HStringBuilder::new` when another operation fills a known number of UTF-16 code units. Write through its mutable slice, call `trim_end` if unused trailing elements remain zero, and convert the builder into `HSTRING`. ## Important choices and pitfalls - Prefer wide Windows APIs when both 8-bit and wide variants exist. A `PCSTR` type alone does not define which legacy code page a particular Win32 function applies. - `PCSTR`, `PCWSTR`, `PSTR`, and `PWSTR` do not own their buffers. Keep the backing allocation alive for the entire call. - Do not pass an immutable literal through `PSTR` or `PWSTR`; writable pointer types require writable storage sized as the API specifies. - Use `BSTR` only for APIs that transfer or borrow a COM Automation string according to the stated ownership contract. - The default `std` feature adds standard-library conversions. Disable it only if the remaining `alloc`-based API meets the target's needs. ## Samples and next steps The string samples cover `HSTRING`, `BSTR`, and the wide and 8-bit literal macros. Run them from the workspace with: ```text cargo run -p strings-hstring cargo run -p strings-bstr cargo run -p strings-wide-ansi ``` Continue with [`windows-core`](windows-core.md) when the string is part of a projected COM or WinRT call. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-strings`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/strings.txt`; the string types and macros are hand-written. ### Testing Run `cargo test -p windows-strings`; see also the workspace test crates. --- ### Crates Windows Sys (`docs/crates/windows-sys.md`) # windows-sys > Raw Windows API declarations, constants, and ABI types. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-sys) - ๐Ÿ“– [API reference](https://microsoft.github.io/windows-docs-rs/) - ๐Ÿš€ [Getting started](../../crates/libs/sys/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/windows-sys) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/sys) `windows-sys` projects Windows metadata as raw FFI. Functions keep pointer parameters and native integer conventions, structs are plain ABI values, and the crate does not provide owning COM or WinRT wrappers. ## When to use it Prefer a focused crate when one covers the task. For APIs not covered there, a reusable library should generate a narrow private binding set with [`windows-bindgen`](windows-bindgen.md). Choose `windows-sys` when a binary application wants a pre-generated broad API and its Rust layer should stay close to a C signature, such as: - sharing layouts and callbacks with existing C or C++ code; - writing a narrow wrapper where ownership and error translation are handled locally; - calling a raw API shape that the rich projection cannot represent. Choose [`windows`](windows.md) when a binary application needs a similarly broad projection with reference-counted interfaces, parameter conversion traits, and projected results. Reusable libraries should avoid both umbrella crates. They add dependency weight and version churn, and several libraries can bring incompatible versions into one dependency tree. Cargo features limit what compiles, but they do not remove those dependency-management costs. Do not choose `windows-sys` on the assumption that `windows` adds runtime overhead to every call. The meaningful difference is API shape and who must maintain the unsafe contract. ## Features and API discovery The same metadata drives `windows` and `windows-sys`, but raw Win32 feature names usually follow lowercase header groups. For example, a program using event handles may need `synchapi`, `handleapi`, and type features such as `winnt` or `minwinbase`. Use the [API reference](https://microsoft.github.io/windows-docs-rs/) and the generated signature: 1. Search for the native API name. 2. Confirm that the result is available in `windows-sys`; rich-only COM and WinRT projections do not have equivalent raw interface wrappers. 3. Enable the feature shown for the function and any feature needed by types in its signature. 4. Inspect compiler errors before adding broad features. Generated feature dependencies already include many prerequisites. 5. Verify operating-system availability separately from crate availability. Keep imports explicit at an FFI boundary. `windows_sys::Win32::*` is convenient in a small sample, but named imports make it clear which constants, structs, and extern functions a wrapper exposes. ## Raw ABI patterns The core aliases show the intended level of abstraction: - `BOOL`, `HRESULT`, `NTSTATUS`, and `RPC_STATUS` are integer aliases. - `PCSTR` and `PCWSTR` are const pointers. - `PSTR` and `PWSTR` are mutable pointers. - `BSTR` and `HSTRING` are raw ABI handles, not owning Rust strings. - `IUnknown_Vtbl` and `IInspectable_Vtbl` describe base vtable layouts. Generated functions do not add `Option`, slices, Rust `bool`, automatic out values, or resource guards. Pass null pointers, lengths, discriminants, and callbacks in the exact form required by the Windows documentation. Callback functions generally need `extern "system"` and must obey the documented lifetime and threading rules. Use `#[repr(C)]` for your own structs that cross the boundary. Do not transmute between `windows-sys` and `windows` types merely because their current layouts appear equal. Convert through documented raw representations at one reviewed boundary. ## Safety and ownership Treat each extern call as a three-part contract: 1. Inputs must remain valid for the duration documented by the API. 2. The return value must be interpreted using that API's success convention. 3. Every acquired resource must be paired with its documented release operation. Raw handle aliases are often pointers, but pointer shape does not establish ownership. A returned value may be borrowed, process-owned, closed with `CloseHandle`, released by another function, or compared with a special sentinel. Build a private RAII guard as soon as an owned resource enters Rust, and transfer ownership explicitly when the Windows API takes it. Keep `unsafe` inside a safe wrapper wherever the contract can be expressed and checked in Rust. Validate buffer sizes and integer conversions before the call. Avoid constructing slices from raw pointers until nullability, alignment, initialization, and element count have all been established. ## Errors `windows-sys` returns native status values. It does not translate them into `windows_core::Result`: - For `BOOL`, check against zero only when the API documents zero as failure. - For handles, distinguish null from `INVALID_HANDLE_VALUE`; different functions use different sentinels. - For HRESULT values, use the documented success and failure ranges rather than treating every nonzero value as an error. - For last-error APIs, read `GetLastError` immediately after the failing return and before another Windows call. - Some APIs set last error only for selected failures. Do not report a stale last-error value when the API does not promise one. A wrapper may translate these results into its own error type or use the focused [`windows-result`](windows-result.md) crate. Keep the native status available when callers need to make API-specific decisions. ## Strings and buffers The `s!` and `w!` macros create null-terminated literal pointers. They do not allocate dynamic storage. For runtime UTF-16 input, encode into a `Vec`, append a zero, and keep the vector alive and unchanged until the call returns. Reject or handle interior nulls according to the target API. Output strings require the pattern documented by the function. Common forms include a caller-owned buffer and length, a size query followed by allocation, or a pointer allocated by Windows and released by a specific function. Do not assume that `PWSTR` implies any one of these forms. Lengths may count bytes, code units, characters, or include the trailing null. Preserve the native unit in variable names and check conversions to the API's integer width. ## A practical boundary A maintainable raw wrapper usually follows this order: 1. Define the smallest public Rust operation needed by the application. 2. Import only the native items needed for that operation. 3. Convert Rust values and establish pointer lifetimes. 4. Make one or a small group of related calls inside a narrow `unsafe` block. 5. Capture status or last error immediately. 6. Put owned resources in guards before any fallible follow-up work. 7. Convert outputs into owned Rust values before returning. The `windows-sys` service sample is useful for callback and struct layout patterns, but production code should also check every fallible API result and guard each acquired handle. --- ## Internal documentation The remainder of this page is for repository contributors. ### How it is built `tool-package` generates the crate by driving `windows-bindgen` in `--sys --package` mode from `crates/tools/package/src/sys.txt`. `src/lib.rs` and the small `src/core` ABI module are hand-maintained; the Windows namespace files and Cargo feature graph are generated. Sys package generation prunes namespaces that would contain no raw items. In particular, a namespace containing only projected COM interfaces does not produce an empty module. Generated extern functions link through `windows-link`. Do not edit generated source under `crates/libs/sys/src/Windows`. Change metadata, filters, or the generator and run the appropriate repository tool. ### Testing Run `cargo test -p windows-sys`; the workspace test crates and `windows-sys` samples cover wider ABI usage. --- ### Crates Windows Threading (`docs/crates/windows-threading.md`) # windows-threading > Simple, safe access to the Windows thread pool. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-threading) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-threading) - ๐Ÿš€ [Getting started](../../crates/libs/threading/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/threading) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/threading) `windows-threading` exposes the Windows thread pool through a small, safe API. `submit` runs a closure on a pool thread, while `Pool` provides ownership and sizing controls. ## When to use Use this crate for CPU or blocking work that should run on the Windows thread pool without bringing in a Rust async runtime. It is also useful when scoped tasks need to borrow local data. Use `std::thread` when each task needs a dedicated thread, thread-local initialization, or a stable thread identity. Use an async runtime's task APIs when the application already depends on that runtime and the work is primarily asynchronous I/O. ## Getting started The [crate README](../../crates/libs/threading/readme.md) contains the dependency declaration and minimal examples for all three submission styles. For a first workflow, decide whether the caller must wait: ```rust,no_run let inputs = [2, 3, 4]; let outputs = std::sync::Mutex::new(Vec::new()); windows_threading::Pool::with_scope(|scope| { for input in inputs { let outputs = &outputs; scope.submit(move || outputs.lock().unwrap().push(input * input)); } }); assert_eq!(outputs.lock().unwrap().len(), inputs.len()); ``` `with_scope` does not return until its submissions finish, so the closures can borrow `inputs` and `outputs`. ## Choosing a submission API | API | Waiting and lifetime behavior | | --- | --- | | `submit` | Uses the process-wide default pool and returns immediately; the closure is `'static`. | | `for_each` | Submits every iterator item in parallel and waits for all of them. | | `Pool::submit` | Uses a private pool and returns immediately; the closure is `'static`. | | `Pool::scope` | Accepts borrowing closures and joins the pool before returning. | Dropping a `Pool` also waits for its outstanding submissions. Calling `join` waits explicitly. `scope` and `join` wait for all work on that private pool, including work submitted from another thread. ## Pool sizing and task design Windows chooses the private pool size unless `set_thread_limits(min, max)` is called. Set limits only when the workload has measured concurrency requirements. Keep pool closures finite, avoid waiting on other work queued to the same constrained pool, and protect shared mutable state with normal synchronization primitives. `thread_id()` returns the current Windows thread identifier. `sleep(milliseconds)` blocks the current worker; it does not schedule a timer or yield an async task. ## Platform constraints and pitfalls - This crate wraps the Windows thread-pool APIs and is for Windows targets. - `submit` and `Pool::submit` cannot borrow stack data because they may outlive the caller. Use `Pool::scope` for borrowed data. - A panic in a submitted closure crosses a system callback boundary and must not be used as an error-reporting strategy. Handle expected failures inside the closure. - Thread-pool allocation failures are treated as unrecoverable and panic. ## Samples and next steps The [`for-each` sample](../../crates/samples/threading/for-each) shows parallel aggregation. The [`pool` sample](../../crates/samples/threading/pool) shows thread limits, scoped borrowing, and how work is distributed among pool threads. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-threading`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/threading.txt`; `Pool` and the `submit`/`for_each` helpers are hand-written. ### Testing Run `cargo test -p windows-threading`; see also the workspace test crates. --- ### Crates Windows Time (`docs/crates/windows-time.md`) # windows-time > WinRT `TimeSpan` and `DateTime` with idiomatic Rust conversions. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-time) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-time) - ๐Ÿš€ [Getting started](../../crates/libs/time/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/time) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/time) `windows-time` provides the two WinRT time primitives as plain `#[repr(C)]` Rust types: `TimeSpan` (a duration) and `DateTime` (a point on the WinRT UTC timeline). ## When to use Use these types when exchanging time values with WinRT APIs or when code benefits from their signed, 100-nanosecond representation. Use `std::time::Duration` for nonnegative Rust-only durations and `std::time::SystemTime` when no Windows ABI value is needed. ## Getting started The [crate README](../../crates/libs/time/readme.md) has the dependency declaration and a minimal arithmetic example. A practical workflow is to keep calculations in `DateTime` and `TimeSpan`, use checked arithmetic at input boundaries, and convert only where another API requires a `std` type: ```rust use windows_time::{DateTime, TimeSpan}; let started = DateTime::now(); let timeout = TimeSpan::from_seconds(30); let deadline = started.checked_add(timeout).expect("deadline out of range"); assert!(deadline > started); ``` ## `TimeSpan` durations Construct spans from ticks, microseconds, milliseconds, seconds, minutes, hours, or days. Unit constructors saturate if multiplication exceeds the `i64` tick range. `TimeSpan` can be negative, so it can represent a difference that `std::time::Duration` cannot. Use `checked_add`, `checked_sub`, `checked_mul`, `checked_div`, and `checked_neg` when overflow is possible. The operator forms panic on overflow or division by zero. Saturating addition, subtraction, and negation are also available. Conversions to `std::time::Duration` reject negative spans. Conversion in either direction has 100-nanosecond precision, so finer source precision is truncated. ## `DateTime` points `DateTime` stores ticks since 1601-01-01 00:00:00 UTC. Use `from_unix_secs` or `from_unix_millis` for Unix timestamps, and `unix_secs`, `unix_millis`, or `unix_nanos` for the reverse direction. `DateTime::now()` and `SystemTime` conversions require the default `std` feature. Add or subtract a `TimeSpan` to move along the timeline. Subtract two `DateTime` values to obtain a signed `TimeSpan`. Prefer the checked methods for values from external input. `Display` emits an ISO-8601 UTC timestamp. `to_local()` shifts the stored ticks so the component methods return local calendar fields. Treat that result as a local-field carrier; it is not a new UTC instant to serialize with `Display` or convert back to `SystemTime`. ## Platform constraints and pitfalls - Both types use signed `i64` ticks, where one tick is 100 nanoseconds. - `TimeSpan` and `DateTime` are ABI values. Do not substitute `Duration` or `SystemTime` in a WinRT signature. - Unit and Unix constructors saturate on overflow. Use explicit range validation when saturation would hide invalid input. - `DateTime::now()` returns `DateTime::MAX` if the system clock cannot be represented. - Disable the default `std` feature only if `now`, `SystemTime` conversion, and the standard error implementation are not needed. Local-time conversion still calls a Windows API. ## Sample and next steps The [`time-time-types` sample](../../crates/samples/time/time-types) demonstrates duration construction, checked date arithmetic, Unix timestamps, and formatting. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-time`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/time.txt`; the conversion logic is hand-written. ### Why not substitute the type at the projection layer C++/WinRT replaces `TimeSpan` with `std::chrono::duration>` and `DateTime` with the matching `time_point`. That works only because those chrono types are a single `int64_t` and therefore bit-for-bit ABI-compatible with the WinRT struct. Rust has no equivalent. `core::time::Duration` is `{ u64 seconds, u32 nanos }` (96 bits, unsigned) - it can't represent negative `TimeSpan` values and isn't ABI-compatible with `i64`, and `std::time::SystemTime` is opaque and platform-defined. So the ABI struct stays a single `i64`, and `windows-time` provides explicit conversions to and from the `std` types instead of aliasing them. ### Testing Run `cargo test -p windows-time`; see also the workspace test crates. --- ### Crates Windows Version (`docs/crates/windows-version.md`) # windows-version > Reliable OS version information without an application manifest. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-version) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-version) - ๐Ÿš€ [Getting started](../../crates/libs/version/readme.md) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/version) `windows-version` reports the real operating system version even when the process has no version manifest. ## When to use Use this crate when Windows documentation gives an OS build requirement and the program must make a version decision that is not affected by application-manifest version virtualization. It also provides a workstation/server distinction and the update build revision (UBR). Prefer direct capability detection when Windows exposes it: attempt the API, query the interface, or check the feature itself. Version checks are appropriate when the platform contract is stated only in terms of a minimum Windows version or build. ## Getting started The [crate README](../../crates/libs/version/readme.md) contains the dependency declaration and a minimal comparison. In application code, name the required version and keep the decision next to the feature it guards: ```rust,no_run use windows_version::OsVersion; const REQUIRED: OsVersion = OsVersion::new(10, 0, 0, 22_000); fn feature_is_available() -> bool { OsVersion::current() >= REQUIRED } ``` This is easier to audit than scattering comparisons against individual fields. ## Reading version information `OsVersion::current()` returns `major`, `minor`, service-pack `pack`, and `build`. `OsVersion` implements `Ord`, with comparisons proceeding in that field order. Construct a threshold with `OsVersion::new`. `is_server()` distinguishes Windows Server from workstation releases. `revision()` reads the UBR from the registry. Treat the revision separately from `OsVersion`: it is not part of `Ord`. For diagnostics, report both values when the revision matters: ```rust,no_run let version = windows_version::OsVersion::current(); let revision = windows_version::revision(); println!( "{}.{}.{}.{}", version.major, version.minor, version.build, revision ); ``` ## Platform constraints and pitfalls - The crate is Windows-only. - A version threshold does not guarantee that an optional component, driver, policy, or hardware capability is present. Query those requirements separately. - `revision()` returns `0` when the registry query fails as well as when the stored revision is zero. Do not use it where those cases must be distinguished. - Windows product names are marketing labels, not API versions. Compare the documented numeric build rather than parsing a product name. - Do not use `is_server()` as a proxy for installed roles or individual server capabilities. ## Next steps Find the minimum supported build in the documentation for the Windows API or feature being used. Keep that requirement in one named constant, and add capability checks for requirements not captured by the OS build. The [`version-version`](../../crates/samples/version/version) sample prints the current version, revision, product type, and the result of a named build comparison. --- ## Internal documentation The remainder of this page covers how the crate is built and maintained. It is for contributors and is **not needed to use `windows-version`**. ### How it's built `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/version.txt`; `OsVersion` and the comparison logic are hand-written. ### Testing Run `cargo test -p windows-version`; see also the workspace test crates. --- ### Crates Windows Webview (`docs/crates/windows-webview.md`) # windows-webview > A safe Rust wrapper around the [WebView2](https://aka.ms/webview2) COM APIs for hosting > Microsoft Edge in a window. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-webview) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-webview) - ๐Ÿš€ [Getting started](../../crates/libs/webview/readme.md) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples/webview) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/webview) ## When to use it Use `windows-webview` when a Windows desktop application needs to host web content, exchange messages with JavaScript, or use browser facilities such as profiles, cookies, downloads, and the Chrome DevTools Protocol. The crate has no default UI framework. Enable `system` to host WebView2 through `windows-window`, or `reactor` to place the WinUI XAML WebView2 control in a [`windows-reactor`](windows-reactor.md) view. The features are additive. The crate wraps a selected WebView2 surface rather than exposing the complete SDK. Use raw WebView2 bindings when an application needs APIs that are not represented here. ## UI operation model Low-level WebView2 creation and script operations complete through callbacks. Starting an operation returns `Result<()>`: an error means the operation did not start, while success means its result may later be passed to the callback on the same UI thread. A callback runs at most once and may be dropped without running if its native operation or UI apartment ends first. No operation runs a nested message loop. Win32, WinUI, Reactor, and other UI hosts retain control of message preprocessing, dispatch, and shutdown. `WebViewWindowBuilder::run` is a separate convenience for applications that choose `windows-window` as their top-level host; it owns the one application message loop. This differs from [`windows-pickers`](windows-pickers.md): a Common Item Dialog is a synchronous native modal operation whose `Show` method owns its modal loop. Reactor stages such modal work with `ComponentContext::run_window`; it uses `ElementRef` requests for callback-completed control work. ## The basic idea A low-level WebView host has three main objects: | Type | Purpose | | --- | --- | | `Environment` | Owns the browser process and user-data context | | `Controller` | Places a browser inside a native parent window | | `WebView` | Navigates, runs scripts, exchanges messages, and exposes page events | | `WebViewHost` | Owns all three objects while another framework owns the parent | | `WebViewWindow` | Adds an owned `windows-window` parent and lifecycle handling | `WebViewHostBuilder` creates the first three as one callback-completed operation. Use the individual types when an application shares an environment or needs a custom creation sequence. The Microsoft Edge WebView2 runtime must be installed for native window hosting. Low-level hosts need a live message loop on a COM single-threaded apartment. Standalone applications initialize one with `windows_core::init_sta()`. `WebViewWindowBuilder::run` handles this for its owned loop. ## Host your first page The `system` feature provides a complete `windows-window` host: ```rust,no_run use windows_webview::*; fn main() -> Result<()> { WebViewWindow::new("WebView2") .size(1000, 700) .run(|host| { host.webview() .navigate("https://learn.microsoft.com/windows/apps/")?; Ok(()) }) } ``` The host resizes the controller with its parent and closes WebView2 before the HWND is destroyed. Call `host.retain` or `host.retain_all` for event registrations that should remain active for the host lifetime. `WebViewWindowBuilder::on_close` reports normal close processing, including programmatic closure, when another UI framework coordinates several windows. Direct destruction during drop does not call it. Use `WebViewHostBuilder` when a framework already owns the parent HWND and UI loop: ```rust,ignore WebViewHost::builder().create_for_hwnd(parent, move |result| { match result { Ok(host) => framework.attach_webview(host), Err(error) => framework.report_webview_error(error), } })?; ``` The builder chains environment and controller creation without blocking or pumping messages. `WebViewHost` owns the resulting environment, controller, browser, and retained event registrations. The framework stores that one value and remains responsible for parent lifetime, layout, position notifications, and shutdown. The raw `Environment` and `Controller` callback APIs remain available when a framework needs separate environment reuse or custom controller creation. ## Keep event registrations alive Every `on_*` method returns an `EventRegistration`. The registration unsubscribes when it is dropped, so store it for as long as the callback should run: ```rust,ignore let navigation = webview.on_navigation_completed(|args| { println!("navigation succeeded: {}", args.is_success()); })?; webview.navigate("https://github.com/microsoft/windows-rs")?; // Keep `navigation` alive while the message loop runs. ``` For several events, a vector is convenient: ```rust,ignore let registrations = vec![ webview.on_document_title_changed(|title| { println!("the title changed to {title}"); })?, webview.on_process_failed(|args| { eprintln!("browser process failed: {:?}", args.kind()); })?, ]; ``` Callbacks run on the UI thread. Keep them short so the window and page remain responsive. ## Navigate and observe page state The common navigation methods are direct: ```rust,ignore webview.navigate("https://example.com")?; webview.reload()?; webview.go_back()?; webview.go_forward()?; ``` Use `source` and `document_title` after navigation: ```rust,ignore let page = webview.clone(); let navigation = webview.on_navigation_completed(move |args| { if args.is_success() { println!("{} - {}", page.document_title(), page.source()); } })?; ``` `on_navigation_starting` can inspect or cancel a request before it begins: ```rust,ignore let starting = webview.on_navigation_starting(|args| { if !args.uri().starts_with("https://") { _ = args.set_cancel(true); } })?; ``` Keep a process-failure handler in a long-running host. A failed render process can usually be followed by `reload`; a failed browser process requires a new WebView. ## Exchange messages with the page Page JavaScript sends a value to Rust with: ```javascript window.chrome.webview.postMessage({ action: "save", value: 42 }); ``` The host receives it through `on_web_message_received`: ```rust,ignore let messages = webview.on_web_message_received(|args| { println!("{} sent {}", args.source(), args.web_message_as_json()); })?; ``` Inspect `source` before trusting messages from content that can navigate. Use `try_web_message_as_string` when the protocol accepts only strings. Rust sends a value in the other direction with: ```rust,ignore webview.post_web_message_as_json(r#"{"status":"saved"}"#)?; webview.post_web_message_as_string("refresh")?; ``` The page receives those values with: ```javascript window.chrome.webview.addEventListener("message", event => { console.log("host sent", event.data); }); ``` Use `execute_script` when Rust needs to run a specific expression: ```rust,ignore webview.execute_script("document.title", |result| { println!("title as JSON: {result:?}"); })?; ``` Script results are JSON encoded. The callback runs later on the UI thread. ## Add script before each document loads `add_script_to_execute_on_document_created` installs script before page JavaScript runs and returns its identifier through a callback: ```rust,ignore let page = webview.clone(); webview.add_script_to_execute_on_document_created( "document.documentElement.dataset.host = 'windows-rs';", move |result| { let script = result.unwrap(); println!("registered {}", script.as_str()); page.navigate("https://example.com").unwrap(); }, )?; ``` Save the returned `ScriptId` if the script may need to be removed later: ```rust,ignore webview.remove_script_to_execute_on_document_created(&saved_script)?; ``` Wait for successful registration before navigating when the script must apply to the first document. ## Host local files Map a folder to a virtual HTTPS host rather than navigating to a `file:` URL: ```rust,ignore let folder = concat!(env!("CARGO_MANIFEST_DIR"), "\\web"); webview.set_virtual_host_name_to_folder_mapping( "app.example", folder, HostResourceAccessKind::Deny, )?; webview.navigate("https://app.example/index.html")?; ``` The page can now load scripts, styles, and images relative to that origin. The access kind controls whether other origins may request the folder's content. For generated or embedded content, intercept a URL pattern and return a response: ```rust,ignore let resources = webview.on_web_resource_requested("https://app.example/*", |request| { if request.uri().ends_with("/style.css") { Some( WebResourceResponse::new("body { font-family: Segoe UI, sans-serif; }") .content_type("text/css"), ) } else { None } })?; ``` Returning `None` lets WebView2 continue the request normally. The callback is synchronous, so prepare expensive content outside it. ## Put a WebView inside Reactor Enable the `reactor` feature when the browser should participate in a Reactor layout: ```toml windows-webview = { version = "0.100.0", default-features = false, features = ["reactor"] } ``` `webview` returns a normal Reactor `View` and sends the initialized browser through a callback: ```rust,ignore use windows_reactor::*; use windows_webview::{EventRegistration, WebView, webview}; struct Browser { webview: Option, navigation: Option, } #[derive(Clone)] enum Message { Initialized(WebView), } fn update(&mut self, message: Message, _context: &ComponentContext) { let Message::Initialized(webview) = message; self.navigation = webview.on_navigation_completed(|_| {}).ok(); _ = webview.navigate("https://learn.microsoft.com/windows/apps/"); self.webview = Some(webview); } fn view(&self, _input: &(), context: &mut ViewContext) -> View { webview(context.callback(Message::Initialized)) } ``` These methods belong inside the corresponding `Component` implementation. Initialization happens after the XAML control enters a live visual tree, not during `Component::create`. The convenience function panics on a native initialization error. Use `webview_result` when the component should receive and display that error. A self-contained Reactor app must also deploy `Microsoft.Web.WebView2.Core.dll`; [`windows-reactor-setup`](windows-reactor-setup.md) stages it. The [`reactor`](../../crates/samples/webview/reactor) sample embeds a WinUI WebView2 control in a Reactor view and exercises navigation, scripts, messaging, DevTools, and events through the shared `WebView` API. The [`reactor-window`](../../crates/samples/webview/reactor-window) sample instead uses a Reactor window as a toolbar for a callback-driven `WebViewWindow`. It sets `quit_on_close(false)` so both windows share Reactor's UI thread and message loop, and uses `on_close` to keep the Reactor component synchronized with the external window. This sample also exercises controller zoom and parent-window lifecycle, which the WinUI WebView2 control does not expose through supported interop. ## What to read next Run an example with `cargo run -p webview-`. | Example | What it shows | | --- | --- | | [`minimal`](../../crates/samples/webview/minimal) | Complete `WebViewWindow` hosting | | [`reactor`](../../crates/samples/webview/reactor) | WebView2 embedded in a Reactor view | Browse [`crates/samples/webview`](../../crates/samples/webview) for focused browser features and other hosting models. --- ## Internal documentation This section is for contributors to `windows-webview`. The `system` feature enables the typed `windows-window` controller helpers. The `reactor` feature depends on `windows-reactor` and bridges its WinUI `WebView2` control to the shared browser API. Raw HWND controller methods remain available without either host feature. ### Binding generation WebView2 ships C/C++ headers rather than Windows metadata. `tool-webview` builds the committed bindings in three stages: | Stage | Implementation | Output | | --- | --- | --- | | Headers -> RDL | `windows_clang::clang()` | `target/webview/WebView2.rdl` | | RDL -> winmd | `windows_rdl::reader()` | `target/webview/WebView2.winmd` | | winmd -> Rust | `windows_bindgen` | `crates/libs/webview/src/bindings.rs` | The tool downloads the pinned `Microsoft.Web.WebView2` NuGet package. It parses `WebView2.h` and `WebView2Interop.h` as separate inputs because the collector emits declarations owned by each input, then merges both translation units. It uses `Windows.Win32.winmd` for referenced Win32 types and targets `x86_64-pc-windows-msvc` with Microsoft extensions. Regenerate with `cargo run -p tool-webview`; never edit `src/bindings.rs`. Bindings use `--flat --minimal` and the filter in `crates/tools/webview/src/webview.txt`. Filter method names are raw metadata names such as `put_Bounds` and `get_CoreWebView2`, not projected names. Implemented interfaces belong in `--implement`, without method filters. The `--dead-code` option keeps interface methods crate-private. The small Win32 filter supplies COM string allocation and memory-stream support without a dependency on the full `windows` crate. ### Wrapper implementation Completion handlers and event adapters in `handler.rs` use `implement_decl!`, avoiding the `windows-core` proc-macro dependencies. `OptionsObject` uses the same mechanism to implement the caller-provided environment options interfaces. Its string getters allocate with the COM task allocator because WebView2 takes ownership. All WebView2 completion operations use the same callback contract. Their public methods report immediate initiation failures and retain one-shot handlers for native completion. No operation owns or nests the host's message loop. Event adapters convert COM add/remove tokens into `EventRegistration`. Resource interception also removes its request filter when the registration drops. `protocol.rs` converts response bytes to an `IStream` with `SHCreateMemStream`, keeping streams out of the public API. `string.rs` handles borrowed UTF-16 input, borrowed WebView2 callback strings, owned `LPWSTR` results that must be freed with `CoTaskMemFree`, and task-allocator output strings returned by implemented interfaces. ### Reactor bridge The WinUI XAML control exposes a WinRT `CoreWebView2`, while this crate wraps the COM `ICoreWebView2`. `ICoreWebView2Interop2::GetComICoreWebView2` is the supported bridge; the two objects do not convert through a plain interface cast. With the `reactor` feature, `src/reactor.rs` requests initialization after the control is loaded, retains the loaded-event and asynchronous-operation state through Reactor, crosses the interop bridge, and reports one result. The canonical WinRT metadata is `winmd/Microsoft.Web.WebView2.Core.winmd`. Reactor setup supplies the matching projection DLL for self-contained deployment. ### Maintenance Generated bindings carry casing lint expectations and allow dead code only when the Reactor bridge is disabled. Keep those expectations synchronized with generator output. `test-webview` runs the raw host and browser feature fixtures against a live WebView2 runtime. The self-contained `test-reactor-integration` WebView fixture covers WinUI control initialization and the COM bridge. Both packages run with real windows and message pumps. `test-webview --headless` suppresses its interactive UI; the Reactor integration fixture manages and closes its own test windows. --- ### Crates Windows Window (`docs/crates/windows-window.md`) # windows-window > Minimal window creation and message-loop support for content hosted by a raw `HWND`. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows-window) - ๐Ÿ“– [docs.rs](https://docs.rs/windows-window) - ๐Ÿš€ [Getting started](../../crates/libs/window/readme.md) - ๐Ÿงฉ [Samples](https://github.com/microsoft/windows-rs/tree/master/crates/samples) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/window) - [Reactor application and notification icons](windows-reactor.md#application-state-and-notification-icons) ## When to use it Use `windows-window` when a Windows desktop application needs a small top-level window and message loop to host a swap chain, WebView2 controller, Direct2D or Direct3D renderer, or another API that accepts an `HWND`. It avoids depending on the full [`windows`](windows.md) crate or generating application-specific bindings for basic windowing. The crate is not a general UI toolkit. Menus, controls, input policy, multi-window coordination, and specialized message handling remain the application's responsibility. ## Prerequisites The crate targets Windows desktop applications. Create and drive a window on the thread that owns its message queue. Interop code receiving `Window::hwnd()` must not retain the handle beyond the `Window` lifetime. Window creation attempts to set process DPI awareness to per-monitor v2. Set any different process DPI policy before creating a `Window`. The README contains dependency setup and the minimal create-and-run example. ## First workflow: host resize-sensitive content Most integrations need the following sequence: 1. Put shared renderer or controller state behind `Rc>` or another UI-thread owner. 2. Build the window with `on_resize` and `on_close` closures that update and release the hosted content. 3. Call `create`, then use `client_size` for the initial content size. 4. Pass `hwnd` to the hosting API. 5. Choose `run` for an event-driven host or `run_with` for a render loop. 6. Drop hosted resources before the `Window` when their API requires the parent handle to remain valid. `on_resize` receives client-area width and height in physical pixels. The callback also handles the initial resize messages that arrive after the builder installs its state. ## Window creation and ownership `Window::new(title)` returns a `WindowBuilder`. `size` sets the initial outer window size, while `client_size` sets the size excluding non-client borders. `style` and `ex_style` replace the defaults with raw `WS_*` and `WS_EX_*` values. The defaults are `WS_OVERLAPPEDWINDOW` and no extended style. `no_redirection_bitmap` adds `WS_EX_NOREDIRECTIONBITMAP` for content supplied by composition. `visible(false)` creates a hidden top-level window that can receive messages for integrations such as notification-area icons. `on_message` receives `(hwnd, message, wparam, lparam)` and returns `Option`. Return `Some(result)` only when the application fully handled the message. Return `None` to use the crate's built-in handling and `DefWindowProcW`. `on_resize` and `on_move` are focused alternatives for `WM_SIZE` and `WM_MOVE`. If `on_message` handles either message, its focused callback does not run. `on_close` runs before default `WM_CLOSE` processing destroys the window. Use it to close or drop hosted resources whose APIs require a live parent HWND. If `on_message` handles `WM_CLOSE`, `on_close` does not run. `quit_on_close` controls whether closing the window posts `WM_QUIT`. It defaults to `true` for single-window applications. Dropping a window does not post `WM_QUIT`, so cleanup and failed creation cannot terminate an application-owned loop. Set the option to `false` when window lifetime and application lifetime differ, then call `quit` explicitly when the application should exit. `create` registers the shared window class, creates the window, shows it when configured as visible, and returns an error if creation fails. After native destruction, `Window::hwnd` returns null and `Window::client_size` returns `(0, 0)`. `Window::close` sends `WM_CLOSE` through the configured close and quit behavior. Dropping a live `Window` calls `DestroyWindow` directly without posting `WM_QUIT`. ## Choosing a message loop | API | Use it when | Behavior | | --- | --- | --- | | `run()` | Event-driven updates. | Blocks in `GetMessageW` until quit. | | `run_with(render)` | Consecutive frames may be needed. | Drains messages, then calls `render`. | | `pump()` | An external operation owns the wait. | Dispatches pending messages; never blocks. | | `quit()` | Application state requires loop termination. | Posts `WM_QUIT` to the current thread. | The `run_with` closure returns `Result`. Return `Ok(true)` to request another immediate frame, or `Ok(false)` to block until a message arrives. Propagating an error exits the loop. This lets a renderer switch between animation and an idle or occluded state without busy-waiting. `pump` returns `false` after consuming `WM_QUIT`; the caller should then stop its outer loop. Repeatedly calling `pump` without another wait mechanism spins the CPU. ## Messages, reentrancy, and panics Message dispatch is reentrant: a handler can call a Win32 API that sends another message before the first callback returns. The crate temporarily removes user handlers while one runs. Nested messages therefore use default processing instead of re-entering a closure or borrowing its captured `RefCell` again. A nested `WM_CLOSE` is deferred until the active handler returns so hosted resources can shut down before the native window is destroyed. This also means a nested `WM_SIZE` triggered inside a handler does not invoke `on_resize`. Apply any state update needed by that synchronous operation directly. Handlers run across an `extern "system"` window-procedure boundary without `catch_unwind`. A panic that escapes a handler aborts the process rather than unwinding through Win32. Return errors through captured application state or catch a panic inside the closure if recovery is required. Do not perform long blocking work in a message handler. It prevents painting, input, timers, and other components on the same UI thread from progressing. ## Interop and common options - Use `hwnd()` only with APIs that accept a borrowed parent or target handle. - Use `client_size()` after creation to size the initial swap chain or child content. - Forward resize callbacks to `Controller::set_bounds` for [`windows-webview`](windows-webview.md), or resize the relevant swap-chain buffers. - A composition host can use `no_redirection_bitmap()` to avoid allocating an unused DWM redirection surface. - Raw input, paint, keyboard, mouse, DPI, and position behavior can be implemented through `on_message`. This crate intentionally does not project message-specific argument types. ## Samples | Sample | What to study | | --- | --- | | [`window-message`](../../crates/samples/windows/window-message) | Creation and message handling. | | [`standalone`](../../crates/samples/canvas/standalone) | Swap-chain hosting and resize flow. | --- ## Internal documentation This section is for contributors to `windows-window`. `src/bindings.rs` is generated by `tool-bindings` from `crates/tools/bindings/src/window.txt`. It contains the minimal flat Win32 surface needed for class registration, creation, DPI setup, destruction, and message dispatch. The hand-written `window.rs` depends only on [`windows-core`](windows-core.md). One class is registered lazily for the process. A boxed state containing optional message, resize, move, and close handlers and a shared liveness bit is stored in `GWLP_USERDATA` after `CreateWindowExW`. `wndproc` clears the bit and removes the state on `WM_NCDESTROY`. `Window::drop` destroys only the original native window while it remains live. This prevents a late drop from acting on an HWND value that Windows has recycled for another window. Before invoking a callback, `wndproc` takes all handlers out of state. After the callback it reads `GWLP_USERDATA` again because synchronous handling may have destroyed the window and freed the state. It restores the handlers only when the state still exists. Keep this ordering when changing dispatch behavior. The crate does not catch panics in `wndproc`, add message-specific wrappers, or coordinate several top-level windows. Those boundaries keep the crate small and its ownership rules explicit. --- ### Crates Windows (`docs/crates/windows.md`) # windows > A broad projected Windows API for Rust binary applications. - ๐Ÿ“ฆ [crates.io](https://crates.io/crates/windows) - ๐Ÿ“– [API reference](https://microsoft.github.io/windows-docs-rs/) - ๐Ÿš€ [Getting started](../../crates/libs/windows/readme.md) - ๐Ÿงฉ [Samples](../../crates/samples/windows) - ๐Ÿ“ [Source](https://github.com/microsoft/windows-rs/tree/master/crates/libs/windows) The `windows` crate projects Win32, COM, and WinRT metadata into Rust. It keeps the Windows API shape while adding typed handles, COM reference counting, string and parameter conversions, and `Result`-returning wrappers where the metadata describes an HRESULT result. ## Choosing a binding crate | Need | Choose | Why | | --- | --- | --- | | Focused crate covers the task | That focused crate | Small, stable dependency and safer API | | Reusable library needs another API | [`windows-bindgen`](windows-bindgen.md) | Owned binding set | | Binary application needs broad rich bindings | `windows` | Pre-generated projected API | | Binary application needs broad raw bindings | [`windows-sys`](windows-sys.md) | Pre-generated FFI | Start with the focused crates listed in the [crate index](../readme.md). They provide smaller dependencies and APIs designed around a particular task. If a reusable library needs APIs they do not expose, generate a private, reviewed binding set with `windows-bindgen`. Use `windows` when a binary application benefits more from a pre-generated broad projection than from owning generated bindings. Cargo features limit what compiles, but the umbrella crate still adds dependency weight and version churn. Different libraries can otherwise bring incompatible versions of the same large crate into one dependency tree. It is possible to mix `windows` and `windows-sys`, but their similarly named types are distinct. Keep conversions at a small boundary rather than passing values from both crates throughout an application. ## Finding an API and its features Windows APIs retain their metadata organization: - WinRT namespaces use Rust modules such as `windows::Data::Xml::Dom`. - Win32 header groups are exposed below `windows::Win32`, such as `handleapi`, `synchapi`, and `winuser`. - Shared runtime types and traits are under `windows::core`. Use this workflow when adding an API: 1. Find the Windows API by its native name in the [API reference](https://microsoft.github.io/windows-docs-rs/). 2. Read the projected Rust signature rather than translating the C signature by hand. 3. Enable the feature shown for the item. WinRT features follow namespace names with `_` separators, such as `Data_Xml_Dom`. Win32 features usually follow lowercase header groups, such as `handleapi`. 4. Import narrowly while learning the API. A path such as `windows::Win32::CreateEventW` makes missing features and name collisions easier to diagnose than a glob import. 5. Add supporting features reported by the compiler or reference. Cargo feature dependencies pull in many prerequisite types automatically, but a function and the types in its signature may be gated separately. Keep the feature list near the code that motivates it. For a workspace, a shared dependency can centralize the version while each package selects only the features it calls. Avoid enabling every feature as a discovery shortcut: it slows builds and hides the intended API boundary. If a documented item does not appear after enabling its feature, check the target first. The `windows` crate is Windows-only, and availability in Windows metadata does not guarantee that an API exists on every supported Windows version. Runtime version checks and documented fallback behavior remain the application's responsibility. ## Reading projected signatures The Rust signature is the contract. Projection changes common ABI details in useful ways: - Nullable pointers may become `Option`. - C `BOOL` inputs may become Rust `bool`. - String and interface inputs may accept `Param` implementations rather than one exact type. - COM and WinRT out parameters may become return values. - HRESULT-returning methods may become `windows::core::Result`. - Slice-shaped pointer and length pairs may become Rust slices. These changes do not make every Windows call safe. Generated functions remain `unsafe` when the caller must uphold pointer, lifetime, threading, initialization, or API-specific invariants. Keep the `unsafe` block small and document the invariant in the safe wrapper around it. ### Ownership and types COM and WinRT interface values are owning, reference-counted wrappers. Cloning one calls `AddRef`, dropping one calls `Release`, and `Interface::cast` performs `QueryInterface`. Prefer those operations over manipulating raw interface pointers. Win32 handle types such as `HANDLE` and `HWND` improve type checking but do not imply ownership. The API documentation determines whether a returned handle is borrowed, owned, or a sentinel and which function releases it. Pair acquisition and release in one abstraction so early returns do not leak the resource. Generated structs follow the Windows ABI. Initialize them with `Default` when supported, then set required size, version, discriminant, or pointer fields exactly as the native API requires. Constants sometimes need a cast because the metadata preserves the native constant type while a function accepts another integer type. ### Errors `windows::core::Result` and `windows::core::Error` cover HRESULT-based failures. The `?` operator is the normal path for projected methods that return `Result`. Win32 APIs use several other failure conventions. A function may return `BOOL`, a null handle, `INVALID_HANDLE_VALUE`, zero, or another sentinel. Do not apply one check to every function: - Use `.ok()?` when a projected `BOOL` or `HRESULT` is documented as success/failure. - Check handle and integer sentinels exactly as documented. - Call `Error::from_thread()` immediately after an API reports a last-error failure. Another Windows call may overwrite the thread's last-error value. - Do not treat every zero as failure. Some APIs use zero as a valid result or require a separate status query. The getting-started example demonstrates both patterns: `CreateEventW` requires a null-handle check, while `SetEvent` and `CloseHandle` return values support `.ok()?`. ### Strings Choose a string representation from the parameter type and ownership contract: | Form | Use | | --- | --- | | `w!("text")` | Static null-terminated UTF-16 input (`PCWSTR`) | | `s!("text")` | Static null-terminated narrow input (`PCSTR`) | | `h!("text")` | Static WinRT `HSTRING` | | `HSTRING` | Owned WinRT string, including dynamic text | | `BSTR` | Owned Automation string | | `PCWSTR` / `PCSTR` | Borrowed const pointer with externally managed lifetime | | `PWSTR` / `PSTR` | Mutable pointer, commonly for caller-provided output storage | Prefer the `W` variant of a Win32 API for new code. The `A` variant uses an API-specific Windows code page, not Rust UTF-8. The literal macros include the required trailing null where applicable. For dynamic pointer strings, keep the backing buffer alive and immovable for the entire call and add a trailing null yourself. A pointer string has no ownership; never free it unless the API says the caller owns the allocation. ## A practical wrapper workflow When a binary application wraps an API from this crate: 1. Keep generated types and calls in a Windows-specific module. 2. Validate Rust inputs before entering `unsafe`. 3. Convert strings and buffers once, immediately before the call. 4. Check the API's documented success convention before making another Windows call. 5. Move owned handles or interfaces into a type whose `Drop` implementation uses the matching release function. 6. Return ordinary Rust values and `Result` from the public wrapper. This boundary makes API version checks, resource cleanup, and platform-specific tests visible. It also prevents raw pointers and similarly named `windows` and `windows-sys` types from spreading through the rest of the program. A reusable library should apply the same boundary to focused crates and private `windows-bindgen` output instead of depending on this umbrella crate. --- ## Internal documentation The remainder of this page is for repository contributors. ### How it is built The published crate is generated by `tool-package`, which drives `windows-bindgen` in `--package` mode from `crates/tools/package/src/windows.txt`. It emits `src/Windows/mod.rs` and one file per metadata namespace. `src/lib.rs` is hand-maintained and supplies the docs.rs stub that redirects to the external API reference. The generated Cargo features mirror namespaces and Win32 header groups. Feature dependency edges are generated from type and namespace dependencies. The crate re-exports `windows-core` as `windows::core` and depends on the focused collections, future, numerics, reference, and time crates used by the projection. Do not edit generated source under `crates/libs/windows/src/Windows`. Change metadata, filters, or the generator and run the appropriate repository tool. ### Testing Run `cargo test -p windows`; the workspace test crates and Windows samples cover broader API and projection behavior. --- --- METRICS --- - Files Extracted: 88 - Estimated Token Budget: ~86934 tokens - Canonical Reference: https://codewiki.google/github.com/microsoft/windows-rs
